882 Video Test Instrument User Guide (Rev A.35)
The table below describes the pull-down menus in the center panel of the General tab.
Field / Entity Description / Function
Sets the colorimetry of the format. The parameter is AVST or DVST. The
Color Encoding
following are the selections:
• Default
• Analog Grayscale YYY
• Analog Component RGB
• Analog Composite with Color Kill
• Analog Composite with Subcarrier
• Analog Component YPbPr SDTV
• Analog Component YPbPr HDTV Legacy
• Analog Component YPbPr HDTV Modern
• Analog Component YPbPr Betacam
• Analog Component Monochrome
• Digital Direct VI MDA
• Digital Direct RGB
• Digital Direct RGBI CGA
• Digital Direct RrGgBb EGA
• Digital Component YYY
• Digital Component RGB
• Digital Component YCbCr SDTV (ITU-R BT.601-5)
• Digital Component YCbCr HDTV Legacy (SMPTE 240M)
• Digital Component YCbCr HDTV Modern (ITU-R BT.709-5)
• Digital BT.601 xvYCC
• Digital BT.709 xvYCC
Sets the sync type of the format. The parameter is SSST. The following are
Sync Type
the selections:
• (0) None
• (1) DSS - Digital Separate Sync
• (2) DCS - Digital Composite Sync
• (3) ACS - Analog Composite Sync
• (4) ACS, DSS - Analog Composite Sync, Digital Separate Sync
• (5) ACS, DCS - Analog Composite Sync, Digital Composite Sync
• (6) ACS, DCS, DSS - Analog Composite Sync, Digital Composite Sync
and Digital Separate Sync
• (7) DPMS OFF
• (8) DPMS Suspend
• (9) DPMS Standby
• (10) DPMS ON
197
