Running a test sequence

Running a test sequence using the front panel

882 Video Test Instrument User Guide (Rev A.35)
Test sequences are initiated through the generator's front panel or the command line
interface. A sequence can run in one of three modes:
• Step and stop mode, where the progression of the sequence is under user control, and
the sequence halts after the final step.
• Step and wrap mode, where the progression of the sequence is under user control, and
it continuously loops (repeats the sequence steps).
• Automatic mode, which enables automatic progression through the sequence list with
continuous looping.
The instructions for running test sequences using the front panel and command line
interface are provided below.
To run a sequence using the front panel:
1. Press the Tools key. The Tools menu appears as shown below:
System
Sequence
Probe
AFC
2. Choose the Sequence item by pressing the adjacent soft key. To see all of the
sequences, press the + and - keys.
NewSeq
Myseq_01
Myseq_03
Myseq_05
Probe
Analog
Myseq_02
Myseq_04
Myseq_06
