VESA DMT Formats
882 Video Test Instrument User Guide (Rev A.35)
Active
Format (HxV)
DMT0659 640 x 480
DMT0660 640 x 480
DMT0672 640 x 480
DMT0675 640 x 480
DMT0685 640 x 480
DMT0685D 640 x 400
DMT0685F 640 x 350
DMT0785H 720 x 400
DMT0856 800 x 600
DMT0860 800 x 600
DMT0872 800 x 600
DMT0875 800 x 600
DMT0885 800 x 600
DMT1043 1024 x 768
DMT1060 1024 x 768
DMT1070 1024 x 768
DMT1075 1024 x 768
DMT1085 1024 x 768
DMT1170 1152 x 864
DMT1175 1152 x 864
DMT1185 1152 x 864
DMT1243G 1280 x 1024
DMT1260A 1280 x 960
DMT1260G 1280 x 1024
DMT1275A 1280 x 960
DMT1275G 1280 x 1024
DMT1285A 1280 x 960
DMT1285G 1280 x 1024
DMT1648 1600 x 1200
DMT1660 1600 x 1200
DMT1665 1600 x 1200
DMT1670 1600 x 1200
DMT1675 1600 x 1200
DMT1680 1600 x 1200
DMT1685 1600 x 1200
DMT1760 1792 x 1344
DMT1775 1792 x 1344
DMT1860 1856 x 1392
DMT1875 1856 x 1392
DMT1960 1920 x 1440
DMT1975 1920 x 1440
DMT2060 2048 x 1536
DMT2075 2048 x 1536
Horizontal
Scan Rate (kHz)
Progressive 31.469
Progressive 31.500
Progressive 37.861
Progressive 37.500
Progressive 43.269
Progressive 37.861
Progressive 37.861
Progressive 37.927
Progressive 35.156
Progressive 37.879
Progressive 48.077
Progressive 46.875
Progressive 53.674
Interlace 35.522
Progressive 48.363
Progressive 56.476
Progressive 60.023
Progressive 68.677
Progressive 63.851
Progressive 67.500
Progressive 77.094
Interlace 46.433
Progressive 60.000
Progressive 63.981
Progressive 75.000
Progressive 79.976
Progressive 85.938
Progressive 91.146
Interlace 62.500
Progressive 75.000
Progressive 81.250
Progressive 87.500
Progressive 93.750
Progressive 100.000
Progressive 106.250
Progressive 83.640
Progressive 106.270
Progressive 86.333
Progressive 112.500
Progressive 90.000
Progressive 112.500
Progressive 95.820
Progressive 120.450
Vertical Pixel
Rate (Hz) Rate (MHz)
59.941 25.1752
60.000 25.200
72.809 31.500
75.000 31.500
85.008 36.000
85.080 31.500
85.080 31.500
85.039 35.500
56.250 36.000
60.317 40.000
72.188 50.000
75.000 49.500
85.061 56.250
86.957 44.899808
60.004 65.000
70.069 75.000
75.029 78.750
84.997 94.500
70.013 94.500
75.000 108.000
84.999 121.500
86.871 78.750
60.000 108.000
60.020 108.000
75.000 126.000
75.025 135.000
85.002 148.500
85.024 157.500
96.080 135.000
60.000 162.000
65.000 175.500
70.000 189.000
75.000 202.500
80.000 216.000
85.000 229.500
60.000 204.750
74.997 261.000
59.995 218.250
75.000 288.000
60.000 234.000
75.000 297.000
60.000 239.933008
75.000 319.915008
