Capturing and storing EDID from display device

882 Video Test Instrument User Guide (Rev A.35)
4. Write the EDID to connected display device using the following command:
EDA<n>:PDID
Where <n> is the HDMIoutput port(1 or 2). For example, the command below writes
the EDID out the HDMIOut 2 port.
EDA2:PDID
Follow the procedure to capture and store an EDID structure from a display device
connected to the 882's HDMI output (Tx) port.
To capture and store an EDID from a connected HDMI/DVI display device:
1. Establish a session with the 882 using either HyperTerminal over a serial connection or
Telnet over an Ethernet LAN. See
page 30 or "Establishing a Telnet session with the
2. Connect the 882 HDMI output (Tx) port to the display device whose EDID you wish to
capture.
3. Activate the HDMI-H or HDMI-D interface on the output port:
a. Press the Interface key to access the list of interfaces. A listing of signal interfaces
appears on the 882's display as shown below.
VGA
*
HDMI-D
HDMI-H
b. Choose the HDMI-H or HDMI-D item by pressing the adjacent soft key. The
interface is activated and the port outputs the currently selected image and format.
VGA
HDMI-D
*HDMI-H
c. Alternatively, to activate the interface through the command line interface, enter the
following commands:
XVSI 3 (or 4)
ALLU
4. Capture the EDID from the connected display device by entering the following
command:
"Establishing a terminal session with the
CVBS
S-VIDEO
SDI
CVBS
S-VIDEO
SDI
// Selects the HDMI-D (or HDMI-H) interface
// Applies the interface setting to the 882
882" on page 33.
882" on
