(Keep) Safe Area Mode
Shrink coded frame to title area with opaque white
bar surround
Coded frame has shot-protected title area without
graticules or bars
Coded frame has shot-protected title area with
action graticules without bars
Coded frame has shot-protected title area with title
graticules without bars
Coded frame has shot-protected title area with
action and title graticules without bars
Coded frame has shot-protected custom area with-
out graticules or border
Coded frame has shot-protected custom area with
action graticules without border
Coded frame has shot-protected custom area with
title graticules without border
Appendix A Command Reference
654
"K" Field Code
Undo Bars BarContents
Bit 16 Bit 15 Bit 14
0 1 1
0 0 0
0 0 0
0 0 1
0 0 1
0 0 0
0 0 0
0 0 1
Source Save Area
Bit 13 Bit 12 Bit 11
0 0 1
0 0 1
1 0 1
0 0 1
1 0 1
0 0 1
1 0 1
0 0 1
Bit 10 Symbol
0 Ktwb
0 Ktsp
0 Ktspa
0 Ktspt
0 Ktspb
1 Kcsp
1 Kcspa
1 Kcspt
