Apple1
Description
Audio LR, AudioLRf, AudioRAT, Audio_L, Audio_Lf, Audio_R, Audio_Rf
Description
BarBlack
Description
Appendix B Image Reference
876
Special test image developed per customer specifications. A secondary version shows
reverse (black characters on white background).
Used to configure HDMI audio output signal. The AudioLR is shown below. For more
information, see
"Testing HDMI
Special test image developed per customer specifications.
audio" on page 290.
