Deleting an image catalog

882 Video Test Instrument User Guide (Rev A.35)
2. Press the Options key repeatedly until the Library folder appears on the generator's
display as shown below:
Library
3. Choose the Library item by pressing the adjacent soft key. The image library appears
as shown below. Each item in the image library is an image catalog.
-TVImages
4. Press the soft key adjacent to a catalog to enable or disable it. A + sign next to the item
indicates the item is enabled; a - sign indicates it is disabled.
5. Press the Content key to see the images in the selected catalogs.
SMPTE133
TVBar100
Regulate
To remove an image from a catalog:
1. Establish a session with the generator using either HyperTerminal over a serial
connection or Telnet over an Ethernet LAN.see
the 882" on page 30 or
2. To remove an image from a catalog, enter the following commands:
DIRL /tffs0/Library/ImageLib/TVImages // loads the TVImages catalog
DIRT ContentLib
DIRB
NAMK /cache0/Library/Images/TVImages/SMPTE133.img
Or...
NAMY 1
DIRE
DIRS
You can delete an image catalogs either through the command line or through the
Generator FTP Browser. Procedures for both methods are provided below.
FPDImages-
SMPTEBar
PulseBar
Geom_1
"Establishing a Telnet session with the
// identifies directory as a content directory
// begins a directory editing session
// deletes SMPTE133 (index 1)
// ends the directory editing session
// saves the catalog
"Establishing a terminal session with
882" on page 33.
245
