Cloning generators

Cloning a generator using the PC card

Chapter 3 Administrative Tasks
124
You can clone generators using either the generator's PC card or the Generator FTP
Browser over an Ethernet connection. To clone a generator, the firmware revision of the
source and target generators must match.
Follow this procedure to clone a generator using the PC card.
To clone a generator using the PC card:
1. Establish a session with the generator using either HyperTerminal over a serial
connection or Telnet over an Ethernet LAN. See
the 882" on page 30 or
2. Insert the PC card into the source generator.
3. Press the Tools key. The Tools menu appears on the generator's display as shown
below.
System
Sequence
Probe
AFC
4. Choose the System item by pressing the adjacent soft key. The System menu appears
on the generator's display as shown below.
Clock
CalFactor
Network
Serial
5. Choose the Clone item by pressing the adjacent soft key. The Clone menu appears on
the generator's display as shown below.
Capture
6. Choose the Capture item by pressing the adjacent soft key.
Note: The contents on the PC card are replaced by the contents on the flash memory.
A progress indicator appears.
7. Remove the PC card from the source generator and insert it into the target generator.
"Establishing a Telnet session with the
Reports
ImgShift
Analyzer
CEC
Clone*
Server
About
GPib
Restore
"Establishing a terminal session with
882" on page 33.
