882 Video Test Instrument User Guide (Rev A.35)
3. Choose the EDID item by pressing the adjacent soft key. The EDID reports menu
appears on the 882's display as shown below.
!DataRpt
!CompRpt
Note: Be sure that you have transferred any existing EDID reports to your PC.
Otherwise, generating a new report overwrites the existing report.
4. Define the capabilities declaration form for the sink device you are going to test by
selecting the EditCDF item. Select the adjacent soft key.
Refer to "Defining the capabilities of the display device under
instructions on defining the CDF.
5. Choose !CompRpt item by pressing the adjacent soft key. An HDMI EDID Compliance
Report is generated and stored on the PCMCIA card in the
/card0/Library/Reports/Edid_Compliance.htm file.
6. Open the FTP Browser on the 882 and select a suitable directory on your PC to store
the report.
7. Using the FTP Browser, transfer the report from the 882 PCMCIA card to your PC like
shown below.
EditCDF
test" on page 330 for
343
