Command Type
PXAR? Active Format
(HDMI)
XBBH Manual Border
(HDMI)
XLBW Manual Border
(HDMI)
XRBW Manual Border
(HDMI)
XTBH Manual Border
(HDMI)
PELD Canvas
NPPP Canvas
AVST Analog Video
AVSS Analog Video
AVPS Analog Video
AVPG Analog Video
AVCS Analog Video
AVCO Analog Video
ASSS Analog Sync
ASCT Analog Sync
EQUF Analog Sync
ASBG Analog Sync Gates Add composite sync to blue analog video output
TSPG Analog Sync Gates Enable/disable tri-level sync pulse
ASSG Analog Sync Gates Add composite sync to all three analog video
DVST Digital Video
DVQM Digital Video
NCPP Digital Video
NBPC Digital Video
LMAX Digital Video
LMIN Digital Video
NLNK Digital Video
Description
Get aspect ratio of pixels in active regions of
raster image
Set bottom border height
Set left border width
Set right border width
Set top border height
Set pixel depth
Set pixel repetition factor
Set signal output type
Set maximum peak-to-peak swing for analog
video output
Set analog video black pedestal level
Enable/disable analog video set-up pedestal
Set color subcarrier type for television output
Set mapping of video colors to analog video
output
Set maximum peak-to-peak swing for composite
sync
Set composite sync type for analog video output
Enable/disable equalization pulses in composite
sync
outputs
Set signal type
Set quantizing mode
Set number of clocks per pixel
Set color depth
Set maximum digital quantizing level
Set minimum digital quantizing level
Set number of links used by LVDI digital outputs
