Quantum Data 881 User Manual page 653

DVIC
Class
Description
Command syntax
882 Video Test Instrument User Guide (Rev A.35)
Digital Video Identification Code
InfoFrame Packet
Writes the specified Video Identification Code (VIC) into the AVI InfoFrame.
DVIC code
code
0 = unestablished format
1 - 34 = DVIC code corresponding to a format defined in EIA/CEA-861-C standard
(Section 4). See table below for DVIC codes.
For detailed information on these timings refer to the CEA-861-C specification.
DVIC Format Name
DMT0659
1
DMT0660
1
480p59
2
480p60
2
480p59LH
2
480p60LH
2
480p59SH
3
480p60SH
3
720p59
4
720p60
4
1080i29
5
1080i30
5
480i2x29
6
480i2x30
6
480i2xL1
6
480i2xL2
6
480i2xS1
7
480i2xS2
7
240p2x_1
8
240p2x_2
8
240p2x_3
8
240p2x_4
8
240p2xL1
8
240p2xL2
8
240p2xL3
8
240p2xL4
8
240p2xS1
9
1 2
NCPP HRES
1 640
1 640
1 720
1 720
1 720
1 720
1 720
1 720
1 1280
1 1280
1 1920
1 1920
2 720
2 720
2 720
2 720
2 720
2 720
2 720
2 720
2 720
2 720
2 720
2 720
2 720
2 720
2 720
3
VTOT
525
525
525
525
525
525
525
525
750
750
1125
1125
525
525
525
525
525
525
262
262
263
263
262
262
263
263
262
625
