Chapter 11 Testing EDID for HDMI
342
• Testing Pixel Encoding Requirements (Test ID 8-19)—verifies that the display
under test supports YCbCr pixel encoding when required.
Running the HDMI EDID Compliance test report
Follow the procedure to generate an HTML report of EDID compliance test results. Prior to
running this test you will need to configure the 882 for the test. Refer to
HDMI sink device EDID compliance
882 for the EDID test.
To generate a report of EDID compliance test results:
1. Press the Tools key. The Tools menu appears on the 882's display as shown below.
System
Sequence
Probe
AFC
2. Press the Reports key. The Reports menu appears on the 882's display as shown
below.
EDID
testing" on page 334 for instructions on setting up the
Reports
ImgShift
Analyzer
Packets
"Setting up 882 for
