Chapter 12 CEC Interactive Troubleshooting Environment (ITE)
384
Configure an HDMI CEC device
Use the procedures below to configure the generator outputs as a particular CEC HDMI
device. An 880 series generator with the CEC option is provisioned with a library of
common HDMI CEC device types. You can either use one of these device types in the
library or create your own descriptor file. Once you create a descriptor file you can modify
it to characterize the emulated device to respond in a very specific way.
The following table lists the default device types and their parameters.
Note: All these devices have vendor ID of 1962 (07AA in hex).
Physical
Device Name Address (PA)
CECDev00 0 0 0 0
CECDev01 1 0 0 0
CECDev02 2 0 0 0
CECDev03 1 0 0 0
CECDev04 1 0 0 0
CECDev05 1 0 0 0
CECDev06 2 0 0 0
CECDev07 3 0 0 0
CECDev08 2 0 0 0
CECDev09 3 0 0 0
CECDev10 1 0 0 0
CECDev11 2 0 0 0
CECDev12 3 0 0 0
CECDev13 4 0 0 0
CECDev14 4 0 0 0
CECDev15 4 0 0 0
To set up the generator to emulate an HDMI CEC device using default devices:
1. Establish a session with the generator using HyperTerminal over a serial connection or
Telnet over an Ethernet LAN. For instructions, see
the 882" on page 30.
2. Query the device library to verify that it is provisioned in the generator:
CECQ? 1 16
The generator returns the CECDev types provisioned in the generator library.
CECDEV00.xml
.
Product Type
(PT) OSDN
0 (TV) TVOSDN
1 (Rec Dev) RecDev1
1 (Rec Dev) RecDev2
3 (Set Top Box) STB1
4 (DVD) DVD1
5 (Audio System) Audio1
3 (Set Top Box) STB2
3 (Set Top Box) STB3
4 (DVD) DVD2
1 (Rec Dev) RecDev3
10 (Reserved) Reserved1
10 (Reserved) Reserved2
10 (Reserved) Reserved3
10 (Reserved) Reserved4
0 (TV) FreeUse
10 (Reserved) Unregistered
"Establishing a terminal session with
Logical Address
(LA)
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
