Quantum Data 881 User Manual page 1034

Appendix D Format Reference
1006
Active
Format (HxV)
480p# 640 x 480
480p#KA 640 x 480
480p119 720 x 480
480p119L 720 x 480
480p119S 720 x 480
480p120 720 x 480
480p120L 720 x 480
480p120S 720 x 480
480p239 720 x 480
480p239L 720 x 480
480p239S 720 x 480
480p240 720 x 480
480p240L 720 x 480
480p240S 720 x 480
480p2x59 1440 x 480
480p2x60 1440 x 480
480p2xL1 1440 x 480
480p2xL2 1440 x 480
480p2xS1 1440 x 480
480p2xS2 1440 x 480
480p4x59 2880 x 480
480p4x60 2880 x 480
480p4xL1 2880 x 480
480p4xL2 2880 x 480
480p4xS1 2880 x 480
480p4xS2 2880 x 480
480p59 720 x 480
480p59LH 720 x 480
480p59SH 720 x 480
480p60 720 x 480
480p60LH 720 x 480
480p60SH 720 x 480
480pWH 960 x 480
487i 720 x 487
576i 720 x 576
576i# 720 x 576
576i#KA 720 x 576
576i2x_1 720 x 576
576i2x25 720 x 576
576i2x50 720 x 576
576i2xL1 720 x 576
576i2xL2 720 x 576
576i2xLH 720 x 576
576i2xS1 720 x 576
576i2xS2 720 x 576
576i2xSH 720 x 576
576i4x25 2880 x 576
Horizontal
Scan Rate (kHz)
Interlace 31.469
Progressive 31.469
Progressive 62.937
Progressive 62.937
Progressive 62.937
Progressive 63.000
Progressive 63.000
Progressive 63.000
Progressive 125.874
Progressive 125.874
Progressive 125.874
Progressive 126.000
Progressive 126.000
Progressive 126.000
Progressive 31.469
Progressive 31.500
Progressive 31.469
Progressive 31.500
Progressive 31.469
Progressive 31.500
Progressive 31.469
Progressive 31.500
Progressive 31.469
Progressive 31.500
Progressive 31.469
Progressive 31.500
Progressive 31.469
Progressive 31.469
Progressive 31.469
Progressive 31.500
Progressive 31.500
Progressive 31.500
Progressive 31.469
Interlace 15.734
Interlace 15.625
Interlace 15.625
Interlace 15.625
Interlace 62.500
Interlace 16.625
Interlace 31.250
Interlace 31.250
Interlace 62.500
Interlace 16.625
Interlace 31.250
Interlace 62.500
Interlace 15.625
Interlace 15.625
Vertical Pixel
Rate (Hz) Rate (MHz)
59.940 24.545454
59.940 24.545454
119.880 54.000
119.880 54.000
119.880 54.000
120.000 54.054
120.000 54.054
120.000 54.054
239.760 107.999992
239.760 107.999992
239.760 107.999992
240.000 108.108
240.000 108.108
240.000 108.108
59.940 54.000
60.000 54.054
59.940 54.000
60.000 54.054
59.940 54.000
60.000 54.054
59.940 108.000
60.000 108.108
59.940 108.000
60.000 108.108
59.940 108.000
60.000 108.108
59.940 27.000
59.940 27.000
59.940 27.000
60.000 27.027
60.000 27.027
60.000 27.027
59.940 36.000
59.939 13.500
50.000 13.500
50.000 14.750
50.000 14.750
200.000 54.000
50.000 13.500
100.000 27.000
100.000 27.000
200.000 54.000
50.000 13.500
100.000 27.000
200.000 54.000
50.000 13.500
50.000 54.000
