Quantum Data 881 User Manual page 414

Chapter 12 CEC Interactive Troubleshooting Environment (ITE)
386
CEC1:PT 1
The table below lists the device (product) types and their codes.
Device Type
TV
Recording Device
Set Top Box
DVD
Audio System
CEC1:VID <vid>
CEC1:OSDN
CEC1:PA 0 0 0 0
4. Save the custom CEC device to a file:
CEC1:CECE
CEC1:CECS
5. Assign the custom CEC device to a connector:
CEC1:CECL myTV
CEC1:CECU
Configure generator to log CEC messages
The 882 can be configured to log CEC message and store them in a user defined
directory.
To enable CEC logging:
1. Enter the following command to enable logging on the HDMI connector:
CEC1:LOGG 1 //enables logging on the HDMI Tx output 1 port
CEC3:LOGG 1 //enables logging on the HDMI Rx ports
2. Enable all logging with the following command:
CECX:LOGM 6 //enables logging of all CEC messages
To disable CEC logging:
1. Enter the following command to disable CEC logging:
CEC1:LOGG 0 //disables logging on the HDMI Tx output 1 port
CEC3:LOGG 0 //disables logging on the HDMI Rx ports
//configures the product (device) type
Device Code
0
1
3
4
5
//configures the device vendor ID
//configures the device OSDN
//configures the device physical address
//ends the CEC editing session
//saves the CEC device
//assigns myTV to HDMI Rx port
//configures (uses) the assigned device
