Appendix A Command Reference
520
Command
Type
BALG
Digital Video
PREG
Digital Video
DVSP
Digital Video
DVPT
Digital Video
DVSM
Digital Video
DVSS
Digital Video
(OUT1:DVSS,
OUT2:DVSS)
DSST
Digital Sync
DSCT
Digital Sync
HSPP
Digital Sync Polarity Set digital horizontal sync pulse polarity
VSPP
Digital Sync Polarity Set digital vertical sync pulse polarity
CSPP
Digital Sync Polarity Set digital composite sync output polarity
FSPP
Digital Sync Polarity Set digital frame sync pulse polarity
PSPP
Digital Sync Polarity Set probe pulse polarity
LSPP
Digital Sync Polarity Set digital line sync pulse polarity
HSPG
Digital Sync Gates
VSPG
Digital Sync Gates
CSPG
Digital Sync Gates
PSPG
Digital Sync Gates
LSPG
Digital Sync Gates
FSPG
Digital Sync Gates
PCPG
Digital Sync Gates
Description
Enable/disable adding DC balancing to Open
LVDI digital output
Enable/disable pre-emphasis to Open LVDI
digital outputs
Set signal polarity
Set output protocol (DVI or HDMI)
Set sampling mode
Set TMDS differential swing voltage
Set digital separate sync type for digital
composite sync output
Set composite sync type for digital composite
sync output
Enable/disable digital horizontal sync output
Enable/disable digital vertical sync output
Enable/disable all digital composite sync outputs
Enable/disable probe pulse on special sync
output
Enable/disable digital horizontal sync output
Enable/disable digital frame sync output
Enable/disable pixel clock pulse
