882 Video Test Instrument User Guide (Rev A.35)
2. Enter the following commands:
seqname
SEQL
SMOD 1
SEQU
The generator's display shows the format and image name for each step, the mode,
and the current step number. Additionally, the sync gate status and output status
appear on the right, and the color gate status appears on the left, as shown below:
+Red myseq
+Grn Step:00001
+Blu DMT0660
Inv SMPTE133
If the sequence is set to auto, it begins running. Otherwise, press the + and - keys to
move through the sequence steps.
To stop a sequence:
Enter the following command:
SMOD 0
SEQU
To run a sequence at power up:
1. Run the sequence in the desired mode.
2. Cycle the power to the generator. Depending on the selected mode, the sequence will
start automatically, or you can press the + and - keys to step through the sequence.
// loads the sequence into sequence edit buffer
// where 1=step&stop; 2=step&wrap; 3=auto
// starts running the sequence
ACS
DCS
DSS*
Out+
255
