Chapter 2 Testing Video Displays
50
Display type Display test
Digital flat panel Pixel anomalies
(fixed pixel (stuck pixels, misc sampling)
display)
Photometry (chrominance,
contrast, levels)
Luminance
Centering
Resolution
Persistence
3D (HDMI only)
Rendering image versions
Many images have secondary or alternate versions and some images have many
versions. Use the procedures below to view the alternate and multiple image versions.
To view alternate image versions in the Content list:
1. Select an image by pressing the Contents key and selecting an image with the
adjacent soft key until a * appears next to image name.
2. Enable and view image versions as follows:
a. Press the Options key. The following menu will appear on the 882's display for
images with a single secondary image:
-Alternate
-NoGamma
-Noise
b. Choose the Alternate item by pressing the adjacent soft key until a + appears next
to the item.
+Alternate
-NoGamma
-Noise
Recommended images
Flat, Raster,
Focus_@6, Focus_@7, Focus_@8,
Focus_@9,
Text_12T, Text_16
Flat, Flat07, Flat13, Flat20, Flat27, Flat33,
Flat40, Flat47, Flat53, Flat60, Flat67, Flat73,
Flat80, Flat87, Flat93, FlatGray, Flat_01,
Flat_02, Flat_03, Flat_04, Flat_05, Flat_06,
Flat_07, Flat_08, Flat_09, Flat_10, Flat_11,
Flat_12, Flat_13, Flat_14, Flat_15,
Ramp_B, Ramp_G, and
SMPTEbar,
SMPTE133
Grays11, Grays16, Grays32, Grays64
Outline0, Outline1, Outline2, Outline3
BurstTCE,
Grill_44
Animated images: Persist, Cubes,
3DCRTK, 3DCUBES, custom bitmap images
Red+
Green+
Blue+
Red+
Green+
Blue+
Ramp_B, Ramp_G, and Ramp_R,
Text_9, Text_9T, Text_11,
Flat_16,
Ramp_R, ColorBar,
SMPTE133
(Grayscale), Grays5, Grays9,
Grill_11, Grill_15, Grill_22, Grill_33,
SlideBox
