Generating an EDID Information Report

Chapter 11 Testing EDID for HDMI
324
To view EDID data received from a connected display device using the command line
interface:
1. Connect the display under test to the 882.
2. Establish a session with the 882 using either HyperTerminal over a serial connection or
Telnet over an Ethernet LAN. See
page 30 or "Establishing a Telnet session with the
3. Enter one of the following commands:
• To view the current EDID in ASCII hex format, enter the
• To view a specific segment of EDID, enter the
VGA:I2CR?) command (refer to the command description identify the arguments
of this query).
Follow the procedure to generate an HTML report of EDID data received from a
DDC-compliant VGA, HDMI, DisplayPort or DVI display connected to the 882.
Note: HDMI EDIDs are shown in the examples in this procedure.
To generate a report of EDID data received from a connected display device:
1. Connect the display under test to the 882.
2. Press the Tools key. The Tools menu appears on the 882's display as shown below.
System
Sequence
Probe
AFC
3. Press the Reports key. The Reports menu appears on the 882's display as shown
below.
EDID
4. Choose the EDID item by pressing the adjacent soft key. The EDID reports menu
appears on the 882's display as shown below.
!DataRpt
!CompRpt
"Establishing a terminal session with the
Reports
ImgShift
Analyzer
Packets
EditCDF
882" on page 33.
EDID? command..
I2CR? (OUT1:I2CR?, OUT2:I2CR?,
882" on
