Quantum Data 881 User Manual page 188

Chapter 6 Working with Formats
178
4. To see more options, press the Options key again. The following appears on the
generator's display as shown below.
*FullRange
ShootRange
LimitedRange
5. To see more options, press the Options key again. The following appears on the
generator's display as shown below.
*ACS
DCS
DSS
-Pedestal
6. Press the Options key again to see additional options for testing digital displays. The
following appears on the generator's display as shown below.
+ShotProtect
*Production
SafeAction
SafeTitle
To view and modify a format's settings using the front panel:
1. Press the Source key and choose a format by pressing the adjacent soft key.
2. Press the Settings key. The format settings appear on the generator's display as
shown below. Press the soft keys adjacent to the arrows to see all of the format
settings. Refer to the table below to locate the setting you want to change.
Video Signal
Interface
XVSI AVSI
<- 1 3
3. To change a setting value:
a. Position the blinking cursor on the value you want to change. To do this, press the
soft key adjacent to the arrow by the setting value to move the cursor left or right
until it appears on the digit you want to change.
b. Adjust the value of the setting up or down by pressing the + or - keys.
SyncOnR+
SyncOnG+
SyncOnB+
TriLevel+
AFD: 0
Action-
Title-
->
->
DVSI
0 ->
