D Format Reference
SDTV Formats
882 Video Test Instrument User Guide (Rev A.35)
Topics in this appendix:
• Formats by type
Active
Format (HxV)
480i 720 x 480
480i# 720 x 480
480i#KA 720 x 480
480i2x_1 720 x 480
480i2x_2 720 x 480
480i2x29 720 x 480
480i2x30 720 x 480
480i2x59 720 x 480
480i2x60 720 x 480
480i2xL1 720 x 480
480i2xL2 720 x 480
480i2xL3 720 x 480
480i2xL4 720 x 480
480i2xL5 720 x 480
480i2xL6 720 x 480
480i2xS1 720 x 480
480i2xS2 720 x 480
480i2xS3 720 x 480
480i2xS4 720 x 480
480i2xS5 720 x 480
480i2xS6 720 x 480
480i4x29 2880 x 480
480i4x30 2880 x 480
480i4xL1 2880 x 480
480i4xL2 2880 x 480
480i4xS1 2880 x 480
480i4xS2 2880 x 480
480iLH 720 x 480
480iSH 720 x 480
480iWH 960 x 480
Horizontal
Scan Rate (kHz)
Interlace 15.734
Interlace 15.734
Interlace 15.734
Interlace 62.937
Interlace 63.000
Interlace 15.734
Interlace 15.750
Interlace 31.469
Interlace 31.500
Interlace 15.734
Interlace 15.750
Interlace 31.469
Interlace 31.500
Interlace 62.937
Interlace 63.000
Interlace 15.734
Interlace 15.750
Interlace 31.469
Interlace 31.500
Interlace 62.937
Interlace 63.000
Interlace 15.734
Interlace 15.750
Interlace 15.734
Interlace 15.750
Interlace 15.734
Interlace 15.750
Interlace 15.734
Interlace 15.734
Interlace 15.734
Vertical Pixel
Rate (Hz) Rate (MHz)
59.940 13.500
59.940 12.272727
59.940 12.272727
239.760 53.999968
240.000 54.054
59.940 13.500
60.000 13.5135
119.880 27.000
120.000 27.027
59.940 13.500
60.000 13.5135
119.880 26.999984
120.000 27.027
239.760 53.999968
240.000 54.054
59.940 13.500
60.000 13.513500
119.880 26.999984
120.000 27.027
239.760 53.999968
240.000 54.054
59.940 54.000
60.000 54.054
59.940 54.000
60.000 54.054
59.940 54.000
60.000 54.054
59.940 13.500
59.940 13.500
59.940 18.000
