882 Video Test Instrument User Guide (Rev A.35)
6. To save the changes, press the Enter (Options) key. The following choices appear on
the generator's display:
Apply Settings?
Yes
To save the changes, choose the Yes item by pressing the adjacent soft key.
To exit without saving the changes, choose the No item.
To return to the previous screen without saving the changes, choose the Back item.
7. Reboot the generator.
Setting the PC's network settings
To establish a local ethernet connection between PC and generator, follow these steps to
configure a static IP address on your PC and connect using a crossover cable.
To connect directly to the generator:
1. Determine the IP address of the generator by pressing the Tools key, choosing the
System item, and then choosing the Network item. The IP address of the generator
appears on the generator's display. Refer to the procedures above
IP address" on page 143 for more details on accessing this display.
2. Configure the IP address of your PC. To enter the IP address, open Windows Control
Panel, and then open the Network Connections window.
3. In the Network Connections window, right click the connection that represents your
Ethernet card and select Properties. Select the Internet Protocol TCP/IP connection,
and then click Properties.
Back
No
"Setting the 882's
115
