882 Video Test Instrument User Guide (Rev A.35)
EMUG 1 // Enables emulate mode
To disable the emulate mode through the command line interface, enter the command
shown below:
EMUG 0 // Disables emulate mode
Selecting a format
From the Source list of formats, you select the video format output for your display under
test.
To select a format:
1. Identify the type of display (composite television, component standard definition
television, component high definition television, computer equipment, or other specialty
display).
Note: The 882 has a library of standard formats. For a description of how the library is
organized, see "Understanding the format
2. For non-EDID compliant displays, check the specifications of your display for
supported formats.
3. Press the Source key to access the list of formats. A list of formats appears on the
882's display as shown below. To see all of the formats, press the + and - keys.
*DMT0660
DMT0675
DMT0785H
DMT0860
Note: The list of formats displays when pressing the Source key may be a filtered or
abbreviated list. Formats not suitable for the selected interface type will not appear by
default on the Source list. Also, you can disable format catalogs to prevent certain
formats from appearing on the Source list. For more information about format catalogs,
see "Format catalogs" on page 223.
4. Choose a format by pressing the adjacent soft key.
Upon selecting a format, you can modify the format options and settings if necessary. For
instructions on this, see
library" on page 46.
DMT0672
DMT0685
DMT0856
DMT0872
"Configuring format parameters" on page 177.
275
