882 Video Test Instrument User Guide (Rev A.35)
Button
Description / Function
Clicking on this button will cause the Format Editor application to generate
Generate HTML
an HTML report of the list of formats. A dialog box pops up to allow you to
Report
specify a location and name on your PC.
This activation button is only enabled when you select a format from the list.
Edit Format
Clicking on this button will open up the Format Editor window at the Timing
tab.
This activation button is only enabled when you select a format from the list.
Use Format
Clicking on this button activate this format in the connected 882 generator.
The table below describes the report fields available for the New Report screen.
Report Parameter
Parameter Description
The format name.
Name
Writes the specified Video Identification Code (VIC) into the AVI InfoFrame.
Digital Video
Identification Code
The total number of active pixels (Machine) or microseconds (Time) of the
Horizontal Total
horizontal video. The total is the sum of the Active and Blanking. Parameter:
HTOT.
The number of active pixels (machine) or microseconds (Time) of the
Horizontal Active
horizontal video. Parameter: HRES.
Indicates whether the digital horizontal sync pulse polarity is positive going
Horizontal Sync
or negative going. Parameter: HSPP.
Pulse Polarity
The horizontal line rate of the format. The HRAT is the fundamental
Horizontal Rate
frequency in the 882. Parameter: HRAT.
(kHz)
The total number of active lines (Machine) or milliseconds (Time) of the
Vertical Total
vertical video. The total is the sum of the Active and Blanking. Parameter:
VTOT.
The number of active lines (machine) or milliseconds (Time) of the vertical
Vertical Active
video. Parameter: VRES.
Indicates whether the vertical sync pulse polarity is positive or negative
Vertical Sync Pulse
going. Parameter: VSPP.
Polarity
The vertical frame rate of the format. Parameter: VRAT.
Vertical Rate
Indicates the sync type of the format. The parameter is SSST.
Sync Type
211
