Chapter 6 Working with Formats
208
Heading Field
Extended From
Content Apert.
Extended Apert.
Bars
Description / Function
Enables you to set the mapping type for mapping
CXAR-shaped image content into the extended
EXAR-shaped aperture.
Map
Parameter: EXCX
Enables you to set the mapping type for mapping
Signal from
EXAR-shaped image content into the SXAR-shaped
signal interface.
Map
Parameter: SXEX
Left Sets the left side letterbox bars in pixels.
Right Sets the right side letterbox bars in pixels.
Top Sets the top letterbox bars in pixels.
Bottom Sets the bottom letterbox bars in pixels.
