Page 1 Leica GPS1200+ Technical Reference Manual Version 7.0 English...
Page 2: Post-Processed Kinematic, All-On-Pole - Option
The type and the serial number of your product are indicated on the type plate. Enter the type and serial number in your manual and always refer to this information when you need to contact your agency or Leica Geosystems authorized service workshop. Type: _________________________ Serial No.:...
Page 3 Validity of this manual • This manual applies to all GPS1200+ instruments. Differences between the various models are marked and described. • The RX1200 is available as RX1210 or with touch screen functionality as RX1210T, RX1250X, RX1250Xc, RX1250T or RX1250Tc. The name RX1210 is used throughout the manual and may also represent the touch screen models.
Page 4 Overall comprehensive guide to the product and Manual program functions. Included are detailed descriptions of special software/hardware settings and software/hardware functions intended for technical specialists. Refer to the following resources for all GPS1200+ documentation and software: • the SmartWorx DVD • http://www.leica-geosystems.com/downloads...
Page 5: Table Of Contents
Table of Contents In this manual Chapter Page Equipment Setup Receiver Ports Post-Processed Static Reference on Pillar Post-Processed Static Reference on Tripod Post-Processed Kinematic, Pole and Minipack Post-Processed Kinematic, All-on-Pole - Option 1 Post-Processed Kinematic, All-on-Pole - Option 2 Real-Time Reference, Single Tripod Real-Time Reference, Two Tripods Real-Time Reference using SmartAntenna, RX1250 and GHT56 1.10...
Page 6: Gps1200
Table of Contents GPS1200+ 2.3.3 Pole Setup Measuring Slope Antenna Heights Using GPS1200+ without RX1200 Using RX1250 Overview Switching between Leica SmartWorx software and Windows CE desktop Sleep Mode Configuring Interfaces 4.4.1 Overview 4.4.2 Configuring SmartAntenna Interface 4.4.3 Configuring Clip-On Interface...
Page 7 Manage...\Jobs Overview Accessing Job Management Creating a New Job Editing a Job Managing Job Codes Manage...\Data Overview Accessing Data Management Point Management 9.3.1 Terminology 9.3.2 Creating a New Point 9.3.3 Editing a Point 9.3.4 Mean Page Line/Area Management 9.4.1 Overview 9.4.2 Creating a New Line/Area 9.4.3...
Page 8: Gps1200
Table of Contents GPS1200+ 10.3 Accessing Codelist Management 10.4 Creating/Editing a Codelist 10.5 Managing Codes 10.5.1 Accessing MANAGE Codes 10.5.2 Creating a New Code 10.5.3 Editing a Code 10.6 Managing Code Groups Coding 11.1 Overview 11.2 Thematical Coding 11.2.1 Thematical Coding with Codelist 11.2.2 Thematical Coding without Codelist 11.3...
Page 9 12.3 Combining Linework and Coding Manage...\Coordinate Systems 13.1 Overview 13.2 Terminology 13.3 Accessing Coordinate System Management 13.4 Coordinate Systems 13.4.1 Creating a New Coordinate System 13.4.2 Editing a Coordinate System 13.5 Transformations 13.5.1 Accessing Transformation Management 13.5.2 Creating a New Transformation 13.5.3 Editing a Transformation 13.6...
Page 10: Gps1200
Table of Contents GPS1200+ Manage...\Configuration Sets 14.1 Overview 14.2 Accessing Configuration Set Management 14.3 Creating a New Configuration Set 14.3.1 Initial Steps 14.3.2 Configuration Set for Static Operations 14.3.3 Configuration Set for Post-Processed Kinematic Operations 326 14.3.4 Configuration Set for Real-Time Reference Operations 14.3.5 Configuration Set for Real-Time Rover Operations 14.4...
Page 11 17.4 Importing Data in GSI Format 17.5 Importing Data in DXF Format Convert...\Copy Points Between Jobs Config...\Survey Settings... 19.1 ID Templates 19.1.1 Overview 19.1.2 Accessing ID Template Configuration 19.1.3 Creating a New ID Template 19.1.4 Editing an ID Template 19.1.5 Deleting an ID Template 19.1.6 Working Example...
Page 12: Gps1200
Table of Contents GPS1200+ 20.5 Set NET Parameters Config...\General Settings... 21.1 Wizard Mode 21.2 Hot Keys & User Menu 21.3 Units & Formats 21.4 Language 21.5 Display, Beeps, Text 21.6 Start Up & Power Down Config...\Interfaces... - General 22.1 Overview 22.2 Accessing Configuration Interfaces 22.3...
Page 13 22.5 NMEA Out 22.6 Export Job 22.7 Hidden Point 22.8 Tilt 22.9 Meteo 22.10 SmartAntenna 22.11 Internet 22.12 PPS Output 22.13 Event Input 22.14 External Oscillator 22.15 ASCII Remote 22.16 Remote Configuration of Devices 23.1 Devices 23.1.1 Overview 23.1.2 Digital Cellular Phones 23.1.3 Modems 23.1.4...
Page 14: Gps1200
Table of Contents GPS1200+ Config...\Interfaces... - Controlling Devices 24.1 Digital Cellular Phones 24.1.1 Overview 24.1.2 Configuring a GSM Connection 24.1.3 Configuring a CDMA Connection 24.2 Modems 24.3 Radios 24.4 RS232 24.5 SMARTgate Boxes 24.6 Hidden Point Measurement Devices 24.7 GPRS / Internet Devices 24.8 Internet / Ethernet 24.9...
Page 15 Tools...\Format Memory Device Tools...\Transfer Objects... Tools...\Upload System Files... 27.1 Application Programs 27.2 System Languages 27.3 Instrument Firmware Tools...\Calculator 28.1 Overview 28.2 Accessing the Calculator 28.3 Configuring the Calculator 28.4 Using the Calculator 28.4.1 RPN Mode 28.4.2 Standard Mode 28.4.3 Description of Softkeys 28.4.4 Calling and Closing the Calculator from an Input Field for Numeric Characters...
Page 16: Gps1200
Table of Contents GPS1200+ 32.2.3 Current Position 32.2.4 Logging Status 32.2.5 Occupation Information Status 32.3 STATUS: Battery & Memory 32.4 STATUS: System Information 32.5 STATUS: Interfaces... 32.5.1 Real-Time Input 32.5.2 ASCII Input 32.5.3 Tilt 32.5.4 Meteo 32.5.5 SmartAntenna 32.5.6 Internet 32.5.7 Event Input 32.5.8...
Page 17 33.7 Survey Mode 33.7.1 MapView in Survey Mode 33.7.2 MapView in Staking Out Survey Mode 33.7.3 Selecting Lines and Areas Update Setups 34.1 Terminology 34.2 Procedure of Updating Setups NTRIP via Internet 35.1 Overview 35.2 Configuring a Real-Time Rover for Using NTRIP Service 35.2.1 Configuring an Access to the Internet 35.2.2...
Page 18: Gps1200
Table of Contents GPS1200+ 38.4.3 Inverse Point - Arc 38.4.4 Inverse Point - Current Position 38.5 COGO Calculation - Traverse Method 38.5.1 Overview 38.5.2 Traverse with Azimuth/Bearing 38.5.3 Traverse with Angle Right 38.6 COGO Calculation - Intersections Method 38.6.1 Intersection with Bearing - Bearing 38.6.2 Intersection with Bearing - Distance 38.6.3...
Page 19 38.12 Selecting a Result from Previous COGO Inverse Calculations 38.13 Modifying Values for Azimuths, Distances and Offsets Determine Coordinate System - General 39.1 Overview 39.2 Accessing Determine Coordinate System 39.3 Configuring Determine Coordinate System 39.3.1 Configuring Determine Coordinate System - Normal 39.3.2 Configuring Determine Coordinate System - One Point Localisation...
Page 20: Gps1200
Table of Contents GPS1200+ 41.3.3 Computing the Height Scale Factor 1011 41.4 Determine Coordinate System - Classic 3D Transformation 1014 41.5 Computing Required Azimuth 1018 Reference Line 1020 42.1 Overview 1020 42.2 Accessing Reference Line 1025 42.3 Configuring Reference Line 1028 42.4 Managing Reference Lines/Arcs...
Page 21 Reference Plane 1121 43.1 Overview 1121 43.2 Accessing Reference Plane 1125 43.3 Configuring Reference Plane 1128 43.4 Managing Reference Planes 1132 43.5 Measuring Points to a Reference Plane 1140 Stakeout 1142 44.1 Overview 1142 44.2 Accessing Stakeout 1145 44.3 Configuring Stakeout 1148 44.4 Staking Out...
Page 22: Gps1200
Table of Contents GPS1200+ 45.6.2 Accessing Initialisation for Real-Time Rover Operations 1214 45.6.3 Initialise while Moving 1216 45.6.4 Initialise while Static 1217 45.6.5 Initialise on Known Point 1219 Survey - Auto Points 1221 46.1 Overview 1221 46.2 Configuring Auto Points 1223 46.3 Auto Points for Post-Processed Kinematic and Real-Time Rover...
Page 23 Survey Cross Section 1289 48.1 Overview 1289 48.2 Accessing Survey Cross Section 1292 48.3 Configuring Survey Cross Section 1295 48.4 Surveying Cross Sections 1298 48.5 Cross Section Templates 1304 48.5.1 Accessing Cross Section Template Management 1304 48.5.2 Creating a New Cross Section Template 1307 48.5.3 Editing a Cross Section Template...
Page 24 GSA - GNSS DOP and Active Satellites 1393 F.10 GSV - GNSS Satellites in View 1395 F.11 LLK - Leica Local Position and GDOP 1397 F.12 LLQ - Leica Local Position and Quality 1399 F.13 RMC - Recommended Minimum Specific GNSS Data 1401 F.14...
Page 25 Appendix G Event Input Notify Message Format 1406 Appendix H Seismic Record Format 1408 Appendix I PPS Output Notify Message Format 1410 Appendix J AT Commands 1412 Index 1413 Table of Contents GPS1200+...
Page 26 Table of Contents GPS1200+...
Page 27: Equipment Setup
Equipment Setup Receiver Ports Description All receiver ports of GPS1200+ are part of the receiver front panel. Ports on the receiver GX1210+, GX1220+, GX1220+ GNSS, GX1230+, GX1230+ GNSS and GX1200+ with front panel PPS/Event option Equipment Setup GPS1200+...
Page 28 E1 E2 GPS12_001a a) Port E2: Event input 2, on GX1200+ with g) Port ANT: GNSS antenna in. PPS/Event option b) Port E1: Event input 1, on GX1200+ with h) Battery compartment B, not for GRX1200+/ PPS/Event option GRX1200+ GNSS c) Battery compartment A i) Port PPS: PPS output, on GX1200+ with with CompactFlash card compartment...
Page 29 e) Port P3: Power out, data in/out, or remote inter- k) Port P2: Power out, data in/out, or remote inter- face in/out. 8 pin LEMO face in/out. 8 pin LEMO f) Port PWR: Power in. 5 pin LEMO l) Port P1: Power out, data in/out, or remote inter- face in/out.
Page 30 a) Port OSC: External oscillator, in g) Port ANT: GNSS antenna in b) Port E1: Event input h) Port NET: Ethernet/LAN data in/out, or remote interface. c) Battery compartment i) Port PPS: PPS output with CompactFlash card compartment RX1200 in/out or remote interface d) LED indicators j) Port RX: in/out.
Page 31: Post-Processed Static Reference On Pillar
Post-Processed Static Reference on Pillar The equipment setup described below is to be used for static operations on fixed surveying pillars. Description The receiver and the RX1200 if used can be assembled to make one unit. One connection is needed to connect the GNSS antenna which is mounted on the pillar to the receiver. The receiver and the RX1200 can be kept in the container.
Page 32 Equipment setup GPS12_012 f) Receiver a) GNSS antenna GX1210+/GX1220+/GX1220+ GNSS/ AX1201/AX1203+ GNSS/AR25/AT504 GG GX1230+/GX1230+ GNSS b) Carrier g) Two batteries c) Tribrach h) 2.8 m antenna cable d) Pillar plate if required i) CompactFlash card e) RX1210 if required j) Transport container Equipment Setup GPS1200+...
Page 33 Equipment setup step- Step Description by-step If a pillar plate is being used, locate the pillar plate on the pillar. Screw the tribrach to the pillar plate or the pillar. Level the tribrach. Place and lock the carrier in the tribrach. Screw the GNSS antenna onto the carrier.
Page 34 When using the adapter and carrier, ensure that the GNSS antenna and the adapter assembly slide down the full length of the carrier stub. An incorrectly mounted GNSS antenna will have a direct effect on the results. If the receiver is left in the container during use in high temperatures, the lid should be left open.
Page 35: Post-Processed Static Reference On Tripod
Post-Processed Static Reference on Tripod The equipment setup described below is to be used for static operations over markers. Description The receiver and the RX1200 if used can be assembled to make one unit. The receiver is either clipped to the tripod leg or is placed in the transport container. One connection is needed to connect the GNSS antenna to the receiver.
Page 36 Equipment setup GPS12_013 g) Receiver a) GNSS antenna GX1210+/GX1220+/GX1220+ GNSS/ AX1201/AX1203+ GNSS GX1230+/GX1230+ GNSS b) Carrier h) Two batteries Equipment Setup GPS1200+...
Page 37 c) Height hook i) CompactFlash card d) Tribrach j) Tripod e) 2.8 m antenna cable k) Transport container f) RX1210 if required Equipment setup step- Step Description by-step Set up the tripod. Mount and level the tribrach on the tripod. Ensure that the tribrach is over the marker.
Page 38 Next step IF the receiver AND the RX1200 is Refer to chapter has been pre-programmed not being used has been pre-programmed being used requires programming being used When using the adapter and carrier, ensure that the GNSS antenna and the adapter assembly slide down the full length of the carrier stub.
Page 39: Post-Processed Kinematic, Pole And Minipack
Post-Processed Kinematic, Pole and Minipack The equipment setup described below is to be used for post-processed kinematic rover surveys with extended periods of use in the field. Description The receiver is placed in the minipack. Connections are made to the GNSS antenna and the RX1200.
Page 40 Equipment setup GPS12_014 a) GNSS antenna AX1201/AX1203+ GNSS h) 1.6 m antenna cable b) Upper half aluminium pole with screw i) Minipack c) 1.2 m antenna cable j) 1.8 m, RX to GX cable Equipment Setup GPS1200+...
Page 41 k) Receiver GX1210+/GX1220+/GX1220+ GNSS/ d) Grip for pole GX1230+/GX1230+ GNSS e) RX1210 l) Two batteries f) Holder for RX1210 on pole m) CompactFlash card g) Lower half aluminium pole Equipment setup step- Step Description by-step Screw the two halves of the pole together. Slide the grip onto the pole.
Page 42 Step Description Draw the required amount of cable out of the minipack and tighten the cable brake. Connect one end of the 1.2 m antenna cable to the loose end of the 1.6 m antenna cable and the other end to the GNSS antenna. Connect the 1.8 m, RX to GX cable to the RX1210.
Page 43 Position of cables in the minipack a) 1.6 m antenna cable GPS12_035 b) 1.8 m, RX to GX cable to the RX1210 Next step IF the receiver And the RX1200 is Refer to chapter has been pre-programmed being used requires programming being used Equipment Setup GPS1200+...
Page 44 When using the upper pole half with stub, ensure that the GNSS antenna and the screw-to- stub adapter slide down the full length of the stub before tightening the locking ring. An incor- rectly mounted GNSS antenna will have a direct effect on the results. Refer to "1.15 Using the Minipack"...
Page 45: Post-Processed Kinematic, All-On-Pole - Option
Post-Processed Kinematic, All-on-Pole - Option 1 The equipment setup described below is to be used for post-processed kinematic rover surveys with short periods of use, especially where there are many obstacles such as fences. Description The RX1200 is fixed to the pole grip with a holder. With another holder, the receiver is fixed to the pole.
Page 46 Equipment setup GPS12_015 g) Receiver a) GNSS antenna GX1210+/GX1220+/GX1220+ GNSS/ AX1201/AX1203+ GNSS GX1230+/GX1230+ GNSS b) 1.8 m antenna cable h) Holder for receiver on pole Equipment Setup GPS1200+...
Page 47 c) Upper half aluminium pole with screw i) RX1210 d) Grip for pole j) 1.0 m RX to GX cable e) Holder for RX1210 on pole k) Two batteries f) Lower half aluminium pole l) CompactFlash card Equipment setup step- Step Description by-step...
Page 48 Step Description Press PROG on the RX1210 to switch the receiver on. Next step IF the receiver AND the RX1200 is Refer to chapter has been pre-programmed being used requires programming being used When using the upper pole half with stub, ensure that the GNSS antenna and the screw-to- stub adapter slide down the full length of the stub before tightening the locking ring.
Page 49 Post-Processed Kinematic, All-on-Pole - Option 2 The equipment setup described below is to be used for post-processed kinematic rover surveys with short periods of use, especially where there are many obstacles such as fences. Description The RX1200, with the receiver attached, is fixed to the pole grip with a holder. One connec- tion is needed to connect the GNSS antenna to the receiver.
Page 50 Equipment setup GPS12_021 f) Receiver a) GNSS antenna GX1210+/GX1220+/GX1220+ GNSS/ AX1201/AX1203+ GNSS GX1230+/GX1230+ GNSS b) Upper half aluminium pole with screw g) 1.2 m antenna cable c) Grip for pole h) Lower half aluminium pole Equipment Setup GPS1200+...
Page 51 d) Holder for receiver together with RX1210 on i) Two batteries pole e) RX1210 j) CompactFlash card Equipment set-up step- Step Description by-step Screw the two halves of the pole together. Slide the grip onto the pole. Attach the holder for receiver together with RX1210 and tighten the screw. Screw the GNSS antenna to the top of the pole.
Page 52: Real-Time Reference, Single Tripod
Real-Time Reference, Single Tripod The equipment setup described below is to be used for real-time reference stations with the need of normal radio coverage. Raw observation data may also be collected for post- processing. Description The receiver and RX1200 if used can be assembled to make one unit. The receiver clips to the tripod leg.
Page 53 Equipment setup GPS12_016 a) Radio antenna i) RX1210 if required j) Receiver b) Radio antenna arm 15 cm long GX1210+/GX1220+/GX1220+ GNSS/ GX1230+/GX1230+ GNSS Equipment Setup GPS1200+...
Page 54 c) GNSS antenna AX1201/AX1203+ GNSS k) Radio in housing d) Height hook l) Transport container e) Carrier m) 1.2 m antenna cable to connect radio housing to radio antenna f) Tribrach n) Two batteries CompactFlash card g) 1.2 m antenna cable to connect receiver and GNSS antenna h) Tripod Equipment setup step-...
Page 55 When using the adapter and carrier, ensure that the GNSS antenna and the adapter assembly slide down the full length of the carrier stub. An incorrectly mounted GNSS antenna will have a direct effect on the results. If the receiver is left in the container during use in high temperatures, the lid should be left open.
Page 56: Real-Time Reference, Two Tripods
Real-Time Reference, Two Tripods The equipment setup described below is to be used for real-time reference station with the need of maximized radio coverage. Raw observation data may also be collected for post- processing. Description Refer to "1.7 Real-Time Reference, Single Tripod". The same description applies except that the radio antenna is mounted on the second tripod.
Page 57 Equipment setup GPS12_017 a) GNSS antenna AX1201/AX1203+ GNSS j) Radio antenna arm 3 cm long b) Carrier k) 2.8 m antenna cable c) Height hook l) Telescopic rod d) Tribrach m) Base for telescopic rod Equipment Setup GPS1200+...
Page 58 e) 1.2 m antenna cable n) Radio in housing f) RX1210 if required o) Transport container g) Receiver GX1210+/GX1220+/GX1220+ GNSS/ GX1230+/GX1230+ GNSS p) Tripod h) Tripod q) Two batteries i) Radio antenna r) CompactFlash card Equipment setup step- Step Description by-step Refer to "1.3 Post-Processed Static Reference on Tripod".
Page 59 IF the receiver AND the RX1200 is Refer to chapter requires programming being used When using the adapter and carrier, ensure that the GNSS antenna and the adapter assembly slide down the full length of the carrier stub. An incorrectly mounted GNSS antenna will have a direct effect on the results.
Page 60: Real-Time Reference Using Smartantenna, Rx1250 And Ght56
Real-Time Reference using SmartAntenna, RX1250 and GHT56 The equipment setup described below is to be used for real-time reference stations using SmartAntenna, RX1250 and GHT56. This setup is intended for surveys with the need of normal radio coverage. Raw observation data may also be collected for post-processing. Description The RX1250, the radio housing for a device and the GHT56 can be assembled to make one unit.
Page 61 Equipment setup RX12_28TR a) SmartAntenna i) Radio housing b) Battery for SmartAntenna j) Transport container c) Height hook k) RX1250 d) Carrier l) Radio antenna e) Tribrach m) Battery for RX1250 Equipment Setup GPS1200+...
Page 62 f) Tripod n) CompactFlash card g) GHT57 o) Battery for radio h) GHT56 Equipment setup step- Step Description by-step Set up the tripod. Mount and level the tribrach on the tripod. Ensure that the tribrach is over the marker. Place and lock the carrier in the tribrach. Insert the battery into the SmartAntenna.
Page 63 Step Description To hang the GHT56 on the tripod leg, use the hook GHT57 delivered with the GHT56. Remove the mounting arm if attached to the GHT56. The mounting arm is used to mount RX1250 on a pole. Screw the GHT57 onto the back of the GHT56. Hang the GHT56 on the tripod leg.
Page 64: Smartrover - External Radio
1.10 SmartRover - External Radio The equipment setup described below is to be used for real-time rover using SmartAntenna, RX1250X, GHT56 and an external radio. Description The RX1250X is fixed to the pole grip with the GHT56. The radio plus radio antenna attaches to the GHT56.
Page 65 Equipment setup RX12_31 a) SmartAntenna g) Lower half aluminium pole b) Battery for SmartAntenna h) Radio antenna c) Upper half aluminium pole with screw or stub i) Battery for RX1250X d) Grip for pole j) CompactFlash card Equipment Setup GPS1200+...
Page 66 e) GHT56 k) RX1250X f) Radio in housing l) Battery for radio Equipment setup step- Step Description by-step Screw the two halves of the pole together. Slide the grip onto the pole. Insert the battery into the SmartAntenna. Screw the SmartAntenna to the top of the pole. Insert the CompactFlash card into the RX1250X.
Page 67 Next step Refer to chapter the SmartAntenna interface has to be configured 22.10 the RX1250X has been pre-programmed the RX1250X requires programming When using the upper pole half with stub, ensure that the GNSS antenna and the screw-to- stub adapter slide down the full length of the stub before tightening the locking ring. An incor- rectly mounted GNSS antenna will have a direct effect on the results.
Page 68: Smartrover - External Radio, Maximized Radio Coverage
1.11 SmartRover - External Radio, Maximized Radio Coverage The equipment setup described below is to be used for real-time rover using SmartAntenna, RX1250X, GHT56 and an external radio. This setup is intended for surveys with the need of maximized radio coverage. Description The RX1250X is fixed to the pole grip with the GHT56.
Page 69 Equipment setup RX12_32 Equipment Setup GPS1200+...
Page 70 a) SmartAntenna i) Radio antenna b) Battery for SmartAntenna j) Radio antenna arm 15 cm long c) Upper half aluminium pole with screw or stub k) 1.2 m antenna cable d) Clip for cable l) Battery for RX1250X e) Grip for pole m) CompactFlash card f) GHT56 n) RX1250X...
Page 71 Next step Refer to chapter the SmartAntenna interface has to be configured 22.10 the RX1250X has been pre-programmed the RX1250X requires programming When using the upper pole half with stub, ensure that the GNSS antenna and the screw-to- stub adapter slide down the full length of the stub before tightening the locking ring. An incor- rectly mounted GNSS antenna will have a direct effect on the results.
Page 72: Real-Time Rover, Pole And Minipack
1.12 Real-Time Rover, Pole and Minipack The equipment setup described below is to be used for real-time rover with extended periods of use in the field. Raw observation data may also be collected for post-processing. Description The radio attaches to the receiver and is placed in the minipack. Connections are made to the GNSS antenna, radio antenna and RX1200.
Page 73 Equipment setup GPS12_018 a) GNSS antenna AX1201/AX1203+ GNSS j) 1.8 m, RX to GX cable k) Receiver b) Upper half aluminium pole with screw or GX1210+/GX1220+/GX1220+ GNSS/ stub GX1230+/GX1230+ GNSS Equipment Setup GPS1200+...
Page 74 c) Grip for pole l) Two batteries d) RX1210 m) CompactFlash card e) Holder for RX1210 on pole n) Radio antenna f) Lower half aluminium pole o) Radio antenna arm 3 cm long g) 1.2 m antenna cable p) 1.2 m antenna cable to connect radio housing and radio antenna h) 1.6 m antenna cable q) Telescopic rod...
Page 75 Step Description Pass the 1.6 m antenna cable through a cable brake and down through the opening in the bottom corner of the minipack flap. Refer to paragraph "Position of cables in the minipack". Draw the required amount of cable out of the minipack and tighten the cable brake. Connect one end of the second 1.2 m antenna cable to the loose end of the 1.6 m antenna cable and the other end to the GNSS antenna.
Page 76 Position of cables in the minipack a) 1.6 m antenna cable b) 1.8 m, RX to GX cable c) 1.2 m antenna cable to connect radio housing and radio antenna GPS12_036 Next step IF the receiver AND the RX1200 is Refer to chapter has been pre-programmed being used...
Page 77 When using the upper pole half with stub, ensure that the GNSS antenna and the screw-to- stub adapter slide down the full length of the stub before tightening the locking ring. An incor- rectly mounted GNSS antenna will have a direct effect on the results. Refer to "1.15 Using the Minipack"...
Page 78: Real-Time Rover, All-On-Pole - Option 1
1.13 Real-Time Rover, All-on-Pole - Option 1 The equipment setup described below is to be used for real-time rover with short periods of use, especially where there are many obstacles such as fences. Description The RX1200 is fixed to the pole grip with a holder. With another holder, the receiver is fixed to the pole.
Page 79 Equipment setup GPS12_019 a) GNSS antenna AX1201/AX1203+ GNSS h) Radio in housing b) Upper half aluminium pole with screw i) Receiver GX1210+/GX1220+/GX1220+ GNSS/ GX1230+/GX1230+ GNSS c) 1.8 m antenna cable j) Holder for receiver on pole d) Grip for pole k) RX1210 e) Holder for RX1210 on pole l) 1.0 m RX to GX cable...
Page 80 f) Lower half aluminium pole m) Two batteries g) Radio antenna n) CompactFlash card Equipment setup step- Step Description by-step Refer to "1.5 Post-Processed Kinematic, All-on-Pole - Option 1". Follow steps 1. to Attach the radio in its housing to port P1 or P3 on the receiver. Screw the radio antenna onto the housing.
Page 81: Real-Time Rover, All-On-Pole - Option 2
1.14 Real-Time Rover, All-on-Pole - Option 2 The equipment setup described below is to be used for real-time rover with short periods of use, especially where there are many obstacles such as fences. Description The RX1200, with the receiver attached, is fixed to the pole grip with a holder. One connec- tion is needed to connect the GNSS antenna to the receiver.
Page 82 Equipment setup GPS12_022 a) GNSS antenna AX1201/AX1203+ GNSS g) 1.2 m antenna cable b) Upper half aluminium pole with screw h) Lower half aluminium pole c) Grip for pole i) Radio antenna d) Holder for RX1210 and receiver on pole j) Radio in housing e) RX1210 k) Two batteries...
Page 83 f) Receiver GX1210+/GX1220+/GX1220+ GNSS/ l) CompactFlash card GX1230+/GX1230+ GNSS Equipment setup step- Step Description by-step Refer to "1.6 Post-Processed Kinematic, All-on-Pole - Option 2". Follow steps 1. to Attach the radio in its housing to port P1 or P3 the receiver. Screw the radio antenna onto the housing.
Page 84: Using The Minipack
1.15 Using the Minipack The minipack is used for various applications. The applications are: • Post-processed kinematic, pole and minipack. • Real-time rover, pole and minipack. Antenna pole strap Ensures the antenna pole does not sway around and remains as upright as possible. Pass the strap around the pole and fasten using the clip as shown in the diagram.
Page 85 Hip belt The hip belt • transfers most of the weight from the shoulders to the hips when properly adjusted. • contains velcro attachments through which cables can be passed. GPS12_138 Internal net pouch The internal net pouch is designed for •...
Page 86 Use in high tempera- In high temperatures it is desirable to increase air flow around the receiver. Therefore the tures minipack can be kept half or even fully open when in use. GPS12_140 GPS12_141 To half open the minipack: To fully open the minipack: 1.
Page 87: Checking And Adjusting The Circular Level On The Tribrach
1.16 Checking and Adjusting the Circular Level on the Tribrach Description The circular level is used to level the antenna over the observation point. An incorrectly adjusted circular level means that the GNSS antenna is not properly levelled over the point. This means that in fact another point on the ground is observed.
Page 88 Step Description • If yes, no adjustment is required. The procedure is finished. • If no, the bubble needs adjusting. Continue with step 6. Take down the carrier with precision bubble. Centre the bubble using the adjustment pin in conjunction with the adjustment screws on the bottom side of the bubble.
Page 89 Diagram GPS12_61 Equipment Setup GPS1200+...
Page 90: Antenna Heights
Vertical or slope height GPS1200+ accepts vertical and slope antenna heights measured to the Mechanical Refer- ence Plane. For the majority of GNSS antennas, including all Leica GNSS antennas, the vertical antenna height is measured. Measurements required This is an overview of required measurements depending on antennas, setup and accesso- ries.
Page 91 Leica • vertical height to GPS1200+/System 500 the MRP. • possibly vertical offset. Refer to "2.2 Mechan- ical Reference Planes, MRP" non Leica antenna standard • vertical height to GPS1200+/System the MRP. • possibly vertical offset. non Leica •...
Page 92 Vertical phase centre For Leica antennas: Are handled automatically in the standard antenna records. variations For non Leica antennas: Can be stored in a newly created antenna record. Antenna records including azimuth and elevation dependent corrections need to be created using LGO.
Page 93: Mechanical Reference Planes, Mrp
Mechanical Reference Planes, MRP General The Mechanical Reference Plane • is where the antenna heights are measured to. • is where the phase centre variations refer to. • varies for different antennas. The MRP is shown for each GPS1200+ antenna. AX1201/AX1203+ GNSS a) The mechanical reference plane is the under- side of the threaded metal insert.
Page 94 AT504/AT504 GG 379.4 mm a) The mechanical reference plane is the under- side of the preamplifier housing. The AT504/AT504 GG is built to a JPL design spec- 34.5 mm GPS12_030 ified by the IGS for reference stations. AR25 Ø380.2 mm a) The mechanical reference plane is the under- GPS12_171 32 mm...
Page 95: Determining Antenna Heights
Determining Antenna Heights 2.3.1 Pillar Setup • One of the Leica standard antennas is used: AX1201, AX1203+ GNSS, SmartAntenna, AR25, AT504, AT504 GG, AT501, AT502, AT503. • Leica standard accessories are used. Antenna Heights GPS1200+...
Page 96 Pillar setup a) Mechanical reference plane b) Vertical phase centre offset for L1 c) Vertical phase centre offset for L2 d) Vertical height reading An AX1201/AX1203+ GNSS antenna is GPS12_031 shown. Vertical offset = 0 Vertical height reading The vertical height reading is the height difference between the pillar benchmark and the mechanical reference plane of the antenna.
Page 97 MRP of the antenna sits on the carrier. Add the values determined in step 1. and 2., to get the vertical height reading. For Leica standard antennas plus accessories, the vertical offset is 0.00 m. Antenna Heights GPS1200+...
Page 98 Carrier and adapter dimensions GPS12_037 GPS12_038 GRT144 carrier with GAD31 screw-to-stub GRT146 carrier. adapter. Next step • At the beginning of a survey, enter the vertical height reading into the receiver. • The vertical offset of 0.00 m is stored in the antenna setup record for a pillar setup and will automatically be taken into account.
Page 99 For carriers other than those shown in the diagram above, the dimensions must be deter- mined. Except for Leica standard antennas plus accessories, the vertical offset must be measured. This value must be entered in the antenna setup record. Antenna Heights...
Page 100: Tripod Setup
2.3.2 Tripod Setup • One of the Leica standard antennas is used: AX1201, AX1203+ GNSS, SmartAntenna, AR25, AT504, AT504 GG, AT501, AT502, AT503. • Leica standard accessories are used. Antenna Heights GPS1200+...
Page 101 Tripod setup a) Mechanical reference plane b) Vertical phase centre offset for L1 c) Vertical phase centre offset for L2 d) Vertical offset e) Vertical height reading An AX1201/AX1203+ GNSS antenna is shown. GPS12_032 Vertical height reading The vertical height reading is the height difference between the ground mark and the bottom end of the height hook.
Page 102 For other height measurement devices than the height hook, the dimensions must be deter- mined and the vertical offset must be adapted. For other than Leica standard antennas, the vertical offset must be measured. It must be entered in the antenna setup record.
Page 103: Pole Setup
2.3.3 Pole Setup • One of the Leica standard antennas is used: AX1201, AX1203+ GNSS, SmartAntenna, AT502, AT503. • Leica standard accessories are used. Pole setup a) Mechanical reference plane b) Vertical phase centre offset for L1 c) Vertical phase centre offset for L2...
Page 104 The vertical height reading for • the Leica standard pole consisting of an upper and a lower half is 2.00 m. • the Leica standard pole consisting of an upper and a lower half with an addi- tional 1.00 m pole section added is 3.00 m.
Page 105: Measuring Slope Antenna Heights
Measuring Slope Antenna Heights Setup with a slope antenna height a) Mechanical reference plane b) Horizontal offset c) Slope height reading d) Vertical offset e) Vertical phase centre offset for L1 f) Vertical phase centre offset for L2 An AT504/AT504 GG antenna, Dorne Margolin T, as specified by the IGS is shown.
Page 106 Determine the slope The slope height reading is the height difference between the ground marker and the outside height reading edge of the antenna. Next step • Determine the horizontal and vertical offset. • At the beginning of a survey, enter the slope height reading. The horizontal and vertical offsets must also be configured in MANAGE Antennas.
Page 107: Using Gps1200+ Without Rx1200
Using GPS1200+ without RX1200 For reference stations in post-processing, real-time and static applications, GPS1200+ can be used without RX1200. Description The receiver is pre-programmed in the office using the RX1200. In the field, the receiver is used without the RX1200 attached. This greatly reduces the knowledge required to operate the instrument in the field.
Page 108 Step Description The receiver automatically begins to acquire and track satellites and record data as defined in the receiver configuration. To shut down the equipment press and hold down the ON/OFF button for 4 s. The LED indicators will not be lit when the equipment is switched off. Refer to para- graph "LED Indicators".
Page 109 Description of the LED’s IF the LED THEN no satellites are tracked. green enough satellites are tracked to compute a posi- tion. flashing green the first satellite is tracked, a position is not yet available. no memory device is available. CompactFlash card is not inserted or internal memory not fitted.
Page 110 Field Record Sheet Some information cannot be entered into the receiver without RX1200 but must be entered into LGO for post-processing. A field record sheet is intended for writing down this necessary information such as point ID and antenna height. Example Field Record Date:...
Page 111: Using Rx1250
Using RX1250 Overview Description Some important characteristics of the RX1250 are explained in this chapter. Using RX1250 GPS1200+...
Page 112: Switching Between Leica Smartworx Software And Windows Ce Desktop
Switching between Leica SmartWorx software and Windows CE desktop Graphic a) Icon to start Leica SmartWorx software b) Windows CE desktop c) Task bar d) Start button RX12_33 Access Leica Smart- THEN Worx software RX1250 is started the Leica SmartWorx software starts up automatically.
Page 113 SmartWorx in the task bar to maximise it. Access Windows CE THEN desktop Leica SmartWorx software is to be minimised SHIFT MINIM (F5) in Main Menu. Leica SmartWorx software is to be closed SHIFT EXIT (F6) in Main Menu. Windows CE task bar is to be displayed...
Page 114: Sleep Mode
Sleep Mode Description In sleep mode, the RX1250 shuts down and reduces power consumption. Rebooting RX1250 from sleep mode is quicker than a cold start after turning off. Putting RX1250 into The RX1250 can only be put into sleep mode in the Main Menu screen. sleep mode Press SHIFT SLEEP (F3).
Page 115: Configuring Interfaces
Configuring Interfaces 4.4.1 Overview Description The required interface configurations for the RX1250 depend on the type of equipment setup. Equipment setup Interface configurations Refer to chapter Real-Time Reference using Smart- • SmartAntenna interface via Blue- 4.4.2 Antenna, RX1250 and GHT56 tooth or USB •...
Page 116: Configuring Smartantenna Interface
Highlight the SmartAntenna to be used. CONT (F1) If the SmartAntenna selected is connected for the first time, a Windows CE authen- tication request comes up. Type in 0000 as identification number for Leica’s Blue- tooth and click OK. Using RX1250...
Page 117 Step Description Once the Bluetooth connection is established, the Bluetooth LED on the Smart- Antenna starts flashing in blue. Using RX1250 GPS1200+...
Page 118: Configuring Clip-On Interface
4.4.3 Configuring Clip-On Interface Configuration step-by- Step Description step Select Main Menu: Config...\Interfaces... in the Leica SmartWorx software. Highlight Real-Time. EDIT (F3) CONFIGURE Real-Time Mode <R-Time Mode: Rover> or <R-Time Mode: Reference> <Port: Clip-on> DEVCE (F5) to select the device attached to the GHT56.
Page 119: Receiver Protection With Pin
Receiver Protection with PIN Description The receiver can be protected by a Personal Identification Number. If the PIN protection is activated, the receiver prompts for PIN code entry after starting up and before GPS1200+ Main Menu comes up. If a wrong PIN has been typed in five times, a Personal UnblocKing code is required. Refer to "21.6 Start Up &...
Page 120 GPS1200+ Enter Security PIN Code OK (F4) To accept the PIN code and to continue with the subsequent screen. SHIFT QUIT (F6) To turn off the receiver. Description of fields Field Option Description PIN Code User input The PIN code as previously defined in CONFIGURE Start Up &...
Page 121 IF the PIN code THEN entered is wrong refer to paragraph "GPS1200+ Enter Security PIN Code Error: 479". wrong the fifth time the PUK code is required. Refer to paragraph "GPS1200+ Enter Security PIN Code Error: 478". GPS1200+ Enter Security PIN Code Error: 479 OK (F4)
Page 122 IF the PIN code THEN entered is wrong the fifth time the PUK code is required. Refer to paragraph "GPS1200+ Enter Security PIN Code Error: 478". GPS1200+ Enter Security PIN Code Error: 478 OK (F4) To continue with the subsequent screen. Next step OK (F4) to access GPS1200+ Enter Security PUK Code.
Page 123 Description of fields Field Option Description PUK Code User input The PUK code as generated by Leica Geosystems. • For receivers delivered with firmware version 2.10 or higher, the PUK code comes with the receiver. • For receivers delivered with firmware versions lower than v2.10, contact a Leica representative to...
Page 124 Next step IF the PUK code THEN entered is correct the old PIN code is cleared and the PIN protection is deactivated. GPS1200+ Main Menu is displayed. Refer to "7 Main Menu". wrong GPS1200+ keeps asking for the correct PUK code. SHIFT QUIT (F6) to turn off the receiver.
Page 125: Configurable Keys
Configurable Keys Hot Keys Description Two levels of hot keys exist: • The first level are the keys F7, F8, ..., F12 • The second level is the combination of SHIFT and F7, F8, ..., F12 Functionality Hot keys provide a shortcut for quickly and directly carrying out functions or starting applica- tion programs assigned to the keys.
Page 126 Step Description For Hot Keys/Shift Hot Keys select <F7: CONF Coding & Linework Settings>. For User Menu select <1: CONF Coding & Linework Settings>. CONT (F1) CONT (F1). Press F7 to access CONFIGURE Coding & Linework. Press USER and 1 to access CONFIGURE Coding & Linework. Configurable Keys GPS1200+...
Page 127: User Key
USER Key Description The USER key opens the user defined menu. User defined menu The user defined menu can be configured to contain the most used functions or application programs. The user defined menu can not be accessed while in a CONFIGURE XX screen. Refer to "21.2 Hot Keys &...
Page 128 Define USER key step- To define the USER key is the same as for the hot keys. Refer to paragraph "Define hot key by-step step-by-step". Configurable Keys GPS1200+...
Page 129: Main Menu
RX1250 off. SHIFT SLEEP (F3) Available on RX1250. To put RX1250 into sleep mode. SHIFT MINIM (F5) Available on RX1250. To minimise Leica SmartWorx software. SHIFT EXIT (F6) Available on RX1250. To close Leica Smart- Worx software. Main Menu GPS1200+...
Page 130 Description of the main Main menu function Description Refer to menu functions chapter Survey To start measuring. Programs... To select and start application programs. Manage... To manage jobs, data, codelists, configurations sets, antennas and coordinate systems. Convert... • To export data from a job on the receiver to a file on the CompactFlash card in a customised ASCII format or in DXF format.
Page 131 Main menu function Description Refer to chapter • To perform arithmetic operations such as addi- tion, subtraction, multiplication, division, statis- tical functions, trigonometric functions, conver- sions or roots. • To view files on the CompactFlash card or the internal memory. •...
Page 132: Survey
Survey Access Select Main Menu: Survey. Description Survey provides the functionality used to perform the survey. SURVEY CONT (F1) Survey Begin To accept settings and to continue with screen SURVEY Survey: Job Name. CONF (F2) Available for configuration sets with <R-Time Mode: None>...
Page 133: Programs
Programs... Access Select Main Menu: Programs..Press PROG. Description Programs... accesses the application programs menu. The screen of the application programs menu is called GPS1200+ Programs. GPS1200+ The application programs menu contains all loaded application programs including Survey. Programs They are listed in the order in which they were loaded. CONT (F1) To select the highlighted option and to continue with the subsequent screen.
Page 134 For Main Menu: Programs...\COGO Refer to chapter 38. For Main Menu: Programs...\Determine Coordinate System Refer to chapter 39. For Main Menu: Programs...\RoadRunner This program could contain the following: • RoadRunner Refer to separate manual. • RoadRunner Rail Refer to separate manual. For Main Menu: Programs...\Reference Line Refer to chapter 42.
Page 135: Manage
Manage... Access Select Main Menu: Manage..Description Manage... is used to manage • jobs. • coordinate systems. • data. • configuration sets. • codelists. • antennas. Management functions include creating, selecting, editing and deleting. GPS1200+ Management CONT (F1) To select the highlighted option and to continue with the subsequent screen.
Page 136 For Main Menu: Manage...\Coordinate Systems Refer to chapter 13. For Main Menu: Manage...\Configuration Sets Refer to chapter 14. For Main Menu: Manage...\Antennas Refer to chapter 15. Main Menu GPS1200+...
Page 137: Convert
Convert... Access Select Main Menu: Convert..Description Convert... provides access to data exchange options. GPS1200+ Convert Data CONT (F1) To select the highlighted option and to continue with the subsequent screen. Next step For Main Menu: Convert...\Export Data from Job Refer to chapter 16.
Page 138: Config
Config... Access Select Main Menu: Config..Press USER and then CONF (F2). Description Config... accesses all configuration parameters related to a survey, the receiver and the interfaces. Any changes made are stored in the configuration set. GPS1200+ Configuration: Configu- ration Set CONT (F1) To select the highlighted option and to continue with the subsequent screen.
Page 139: Tools
Tools... Access Select Main Menu: Tools..Description Tools... provides functionality which is not directly related to surveying data. GPS1200+ Tools Menu CONT (F1) To select the highlighted option and to continue with the subsequent screen. Next step For Main Menu: Tools...\Format Memory Device Refer to chapter 25.
Page 140 Manage...\Jobs Overview Description Jobs • structure surveying projects. • contain all points, lines, areas and codes that are recorded and stored. • can be downloaded to LGO for post-processing or for data transfer to a further program. • can be uploaded from LGO, for example, for real-time stake out operations. •...
Page 141: Manage
Accessing Job Management Access Select Main Menu: Manage...\Jobs. Press a hot key configured to access the screen MANAGE Jobs (Device). Refer to "6.1 Hot Keys" for information on hot keys. Press USER. Refer to "6.2 USER Key" for information on the USER key. From a choicelist in some screens for example the XX Begin screen of application programs.
Page 142 CFCRD (F6) or INTL (F6) Available for receivers with internal memory. To change between viewing jobs stored on the CompactFlash card or internal memory. Next step IF a job THEN is to be selected highlight the desired job. CONT (F1) closes the screen and returns to the screen from where MANAGE Jobs (Device) was accessed.
Page 143: Creating A New Job
Creating a New Job Access Refer to "8.2 Accessing Job Management" to access MANAGE Jobs (Device). Create job step-by-step The following table explains the most common settings. Refer to the stated chapter for more information on screens. Step Description Refer to chapter In MANAGE Jobs (Device) highlight a job.
Page 144 Step Description Refer to chapter MANAGE New Job, General page <Name:> A unique name for the new job. The name may be up to 16 characters long and may include spaces. Input required. <Description:> Two lines for a detailed description of the job. This can be for example, work to be performed or the classes contained in the job.
Page 145 Step Description Refer to chapter MANAGE New Job, Avge page In order to check measurements, the same point can be measured 9.3.4 more than once. If activated, an average or an absolute difference is calculated. <Averaging Mode:> Defines the averaging principles for multiple measured points.
Page 146 Step Description Refer to chapter • For <Averaging Mode: Absolute Diffs>: <Points to Use:> The type of points which will be taken into account for absolute differences. From <Easting:> to <Cartesian Z:> The acceptable absolute differences for each coordinate component. •...
Page 147: Editing A Job
Editing a Job Access Refer to "8.2 Accessing Job Management" to access MANAGE Jobs (Device). Edit job step-by-step The following table explains the most common settings. Refer to the stated chapter for more information on screens. Step Description Refer to chapter In MANAGE Jobs (Device) highlight a job to be edited.
Page 148 Step Description Refer to chapter • If no, continue with step 6. • If yes, continue with step 8. No codes are stored in the job. MANAGE Edit Job: Job Name, Codelist page <Codelist: <None>> This default setting can be changed. Choosing a codelist copies the codes to the job.
Page 149 Step Description Refer to chapter The functionality on this page is identical with the creation of a new job. The coordinate system of the job currently being used cannot be 22.3.4 edited for <Use Auto CrdSys: Yes> configured in CONFIGURE Additional Rover Settings.
Page 150: Managing Job Codes
Managing Job Codes Description To view, edit, group and sort all codes currently stored in the job. The functionality of this screen is mainly the same as for MANAGE Codes. For simplicity, the functionality which is different from MANAGE Codes is explained here. Refer to "10.5 Managing Codes" for infor- mation on MANAGE Codes.
Page 151: Manage
MANAGE Job Codes CONT (F1) To return to MANAGE Edit Job: Job Name, Codelist page. NEW (F2) To create a new code. Refer to "10.5.2 Creating a New Code". EDIT (F3) To edit the highlighted code. Accesses MANAGE Edit Code where new attributes can be added to a code and line styles can be changed.
Page 152 Next step THEN the job codes do not CONT (F1) closes the screen and returns to the screen from where need to be changed MANAGE Job Codes was accessed. a new job code is to NEW (F2). Refer to "10.5.2 Creating a New Code". be created an existing job code is highlight the job code and EDIT (F3).
Page 153 Type of code Description Point codes New attributes can be added with NEW-A (F2). Free codes Line codes • New attributes can be added with NEW-A (F2). • The line style can be changed. This new line style is stored to the Area codes code.
Page 154: Overview
Manage...\Data Overview Description Data is a generic term for points, lines and areas. Data management is the administration of data stored in the active job. This includes • viewing data with their related information. • editing data. • creating new data. •...
Page 155: Accessing Data Management
Accessing Data Management Access Select Main Menu: Manage...\Data. Press a hot key configured to access the screen MANAGE Data: Job Name. Refer to "6.1 Hot Keys" for information on hot keys. Press USER. Refer to "6.2 USER Key" for information on the USER key. From a choicelist in some screens for example in application programs.
Page 156 MANAGE CONT (F1) Data: Job Name, To close the screen and return to the screen from where this screen was accessed. Points page NEW (F2) To create a point. EDIT (F3) To edit the highlighted point. DEL (F4) To delete the highlighted point. MORE (F5) To display information about the codes if stored with any point, the time and the date of when...
Page 157 THEN a point is to be edited highlight the point and EDIT (F2). Refer to "9.3.3 Editing a Point". a line/area is to be PAGE (F6) changes to the Lines (X) and Areas (X) page. Refer to managed paragraph "MANAGE Data: Job Name, Lines (X) page; MANAGE Data: Job Name, Areas (X) page".
Page 158 MORE (F5) To display information about the codes if stored with any line/area, the start time, the end time of when the last point was added to the line/area, the length of the line, the perimeter and the area of the area. PAGE (F6) To change to another page on this screen.
Page 159 Next step IF the line/area THEN management is CONT (F1) closes the screen and returns to the screen from where this completed screen was accessed is to be opened highlight the line/area and OPEN (F4). which was last used is press a hot key configured to re-open last used line/area.
Page 160: Point Management
Point Management 9.3.1 Terminology Description This chapter describes technical terms related to data management. Coordinate triplet A measured point consists of three coordinate components - two horizontal components and one vertical component. The generic term for the three coordinate components is coordinate triplet.
Page 161 Class Characteristic Description Type • Reference point received by a real-time rover • Station point set by Setup application program. Instrument source GPS, TPS or LGO Number of triplets AVGE Type Averaged point calculated when more than one coordinate triplet of class MEAS exist for the same point ID unless <Averaging Mode: Off>.
Page 162 Class Characteristic Description Type Estimated points from LGO. Instrument source LGO. Possible number of triplets NONE Type Measured points with angles. Instrument source Possible number of Unlimited triplets Sub class The sub class describes certain classes in detail. It indicates the status of the position when a coordinate triplet was measured and how the coordinates were determined.
Page 163 Sub class Description Instrument source GPS Code Only Direct coordinate determination with code solu- tion. GPS Fixed Direct coordinate determination with phase fixed solution. GPS Float Direct coordinate determination with autonomous solution coming from LGO. Hidden Point Indirect coordinate determination with hidden GPS or TPS point measurements.
Page 164 Source Originated from application program/function- Instrument ality source Arc Centre Pt COGO, Arc Calculation - Centre Point GPS or TPS Arc Offset Pt COGO, Arc Calculation - Offset Point GPS or TPS Arc Segmt Pt COGO, Arc Calculation - Segmentation GPS or TPS Backward Brg-Dist Hidden point measurements, Backward Bearing...
Page 165 Source Originated from application program/function- Instrument ality source Intsct (Dst Dst) COGO, Intersection - Distance - Distance GPS or TPS Intsct (4 Pts) COGO, Intersection - By points GPS or TPS LandXML Design to Field in LGO converting data from LandXML software to be used in the field Line Base Pt COGO, Line Calculation - Base Point...
Page 166 Source Originated from application program/function- Instrument ality source Setup (Resect H) Setup, Resection Helmert Setup (Set Az) Setup, Set Azimuth Srvy Auto Offset Survey Auto Points, automatically recorded with GPS or TPS offsets Stakeout Stakeout GPS or TPS Survey Survey, measured Survey (Auto) Survey Auto Points, automatically recorded Survey (Event)
Page 167 Instrument source The instrument source describes where the coordinate triplet was measured or entered. The options are GPS, TPS, LGO or Level. Coordinate quality Description The Coordinate Quality is • computed on the rover for code solutions and phase fixed solutions. •...
Page 168 Computation GPS measurements Unknowns Least square adjustment like rover coordinates Elements of cofactor matrix Root Mean Square RMS = a posteriori of unit weight • Reflects the influence of the different constellations of the • Reflects all error sources such as satellites on the coordinate diffraction, multipath, ionospheric components.
Page 169 Range For a phase fixed solution: Centimetre level For a code solution: From 0.4 to 5 m. Position CQ versus height CQ All GPS computed positions are almost twice as accurate in plan than in height. For the posi- tion determination, satellites can appear in all four quadrants. For the height determination, satellites can appear in two quadrants.
Page 170: Creating A New Point
9.3.2 Creating a New Point Access Refer to "9.2 Accessing Data Management" to access MANAGE Data: Job Name. Create point step-by- The following table explains the most common settings. Refer to the stated chapter for more step information on screens. Step Description Refer to...
Page 171 Step Description Refer to chapter NORTH (F3) or SOUTH (F3). Available for local geodetic or WGS 1984 geodetic coordinates when <Local Lat:> or <WGS 1984 Lat:> is highlighted. Changes between North and South latitude. EAST (F3) or WEST (F3). Available for local geodetic or WGS 1984 geodetic coordinates when <Local Long:>...
Page 172 Step Description Refer to chapter • For <Thematc Codes: Without Codelist>: Codes for points can be typed in but not selected from a codelist. <Code:> The code to be stored with the point. A check is performed to see if a point code of this name already exists in the job.
Page 173 Step Description Refer to chapter Class: CTRL Sub class: Fixed (Pos & Ht) Source: User Entered Instrument source: GPS It may happen that a point with the same point ID exists in the job. If 11.6 the codes and/or attribute values of the new and the existing point do not match, a screen opens where they can be corrected.
Page 174: Editing A Point
9.3.3 Editing a Point Access Refer to "9.2 Accessing Data Management" to access MANAGE Data: Job Name. Edit point step-by-step The following table explains the most common settings. Refer to the stated chapter for more information on screens. Step Description Refer to chapter In MANAGE Data: Job Name, Points page highlight a point to be...
Page 175 Step Description Refer to chapter SHIFT ELL H (F2) or SHIFT ORTH (F2). Available for local coordi- nates. Change between the option to enter an ellipsoidal or an ortho- metric height. Changing the height type does not edit the point. Is <Class: MEAS>? •...
Page 176 Step Description Refer to chapter PAGE (F6) changes to the Code page. MANAGE Edit Point: Point ID, Code page 11.2 and 11.3 The point code can be edited. All point codes in the job can be selected. The description of the code is shown as an output field. The attributes are shown as output, input or choicelist fields depending on their definition.
Page 177 Step Description Refer to chapter DEFLT (F5) recalls the default attribute values for the selected code. Is <Class: MEAS> and no offset point or <Class: NAV>? • If yes, continue with step 11. • If no, continue with step 10. Is <Class: AVGE>? •...
Page 178 Step Description Refer to chapter STORE (F1) stores the changes and returns to MANAGE Data: Job Name. An edited point retains the creation value for <Time:>. Changing coordinates of a point which has been previously used in other application programs, for example COGO, or hidden point measurements does not update the application results.
Page 179: Mean Page
9.3.4 Mean Page Description In order to check measurements, the same point can be measured more than once. These measured points are assigned the class MEAS. The various measured coordinate triplets for one point can be recorded using the same point ID. If the averaging mode is acti- vated, an average is calculated when more than one measured coordinate triplet is available for the same point ID.
Page 180 Description of averaging modes Averaging Description mode Average When more than one measured coordinate triplet is recorded for the same point, the average for the position and the height is computed. Depending on the selected averaging method, the average will be computed weighted or arithmetic (no weighting).
Page 181 Access step-by-step The Mean page can be accessed if <Averaging Mode: Average> or <Averaging Mode: Absolute Diffs> is configured in MANAGE New Job, Avge page or in MANAGE Edit Job: Job Name, Avge page. more than one measured coordinate triplet is recorded for the same point using the same point ID.
Page 182 MANAGE All measured coordinate triplets recorded using the same point ID are shown. Edit Point: Point ID, Mean page STORE (F1) To store the changes and to return to the screen from where this screen was accessed. USE (F2) To change between the options in the Use column for the highlighted coordinate triplet.
Page 183 DEL (F4) To delete the highlighted coordinate triplet. The average is recomputed. MORE (F5) To change between time and date of when the point was stored and the 3D coordinate quality. PAGE (F6) To change to another page on this screen. SHIFT DIFFS (F5) Available for <Averaging Mode: Absolute Diffs>...
Page 184 Column Description • The coordinate triplet is always included in the averaging computation even if it would fall outside the averaging limit defined in MANAGE New Job, Avge page or in MANAGE Edit Job: Job Name, Avge page. • The coordinate triplet is never included in the averaging computation. •...
Page 185 Next step IF a measured coor- THEN dinate triplet is not to be viewed STORE (F1) stores the changes and returns to MANAGE Data: Job Name. is to be viewed highlight a measured coordinate triplet and EDIT (F3). Manage...\Data GPS1200+...
Page 186: Line/Area Management
Line/Area Management 9.4.1 Overview Description A line/area consists of points and can be created/edited in MANAGE Data: Job Name. The individual points are measured within any application program. These can be all points except auxiliary points. Points can be simultaneously assigned to one or more lines and/or areas.
Page 187: Creating A New Line/Area
9.4.2 Creating a New Line/Area The functionality of all screens and fields are similar for the creation of both lines and areas. The step-by-step instructions for creating a new line can be applied for areas. Access Refer to "9.2 Accessing Data Management" to access MANAGE Data: Job Name. Press a hot key configured to access the screen MANAGE New Line/MANAGE New Area.
Page 188 Step Description Refer to chapter <Pts to Store:> The type of points which are used to form the line 46.1, 46.4 during a survey. Select between all points, measured points, auto points and offset points of type 1 or 2. <Line Style:>...
Page 189 Step Description Refer to chapter • For <Thematc Codes: Without Codelist>: Codes for lines can be typed in but not selected from a codelist. <Line Code:> The line code to be stored with the point. A check is performed to see if a line code of this name already exists in the job.
Page 190 Step Description Refer to chapter The value for <Start Time:> with which the line is stored is the time 9.4.3 when STORE (F1) was pressed. The same value is assigned to the value for <End Time:> until a point is added to the line. Any existing lines and areas which are open are closed.
Page 191: Editing A Line/Area
9.4.3 Editing a Line/Area The functionality of all screens and fields are similar for the editing of both lines and areas. The step-by-step instructions for editing a new line can be applied for areas. Access Refer to "9.2 Accessing Data Management" to access MANAGE Data: Job Name. Edit line step-by-step The following table explains the most common settings.
Page 192 Step Description Refer to chapter <Start Time:> and <Start Date:> The time/date when the line was created. A line cannot be renamed to an already existing line ID. MORE (F5) displays <End Time:> and <End Date:>. This is the time/date when the last point was added to the line. This can be different to the time the point was created.
Page 193 Step Description Refer to chapter PAGE (F6) changes to the Code page. MANAGE Edit Line: Line ID, Code page The line code can be edited. All line codes can be selected. For <Line Code: <None>>, the line style can be changed. The description of the code is shown as an output field.
Page 194: Working Example
9.4.4 Working Example Description Application: Pick up points along fence lines with a gate. The gate can also be represented as a line. Some points belong to more than one line. Working technique: Real-time kinematic. Setting: F7 is configured to access the MANAGE Data: Job Name screen.
Page 195 Field procedure step- The following table explains the most common settings. Refer to the stated chapter for more by-step information on screens. Step Description Refer to chapter Create the lines F1, F2 and G1. Start Survey application program for a real-time rover. 45.3.3 Press F7.
Page 196 Step Description Refer to chapter CONT (F1) SURVEY Survey: Job Name 45.3.3 Measure P1. This point is automatically added to all three lines open at that time. Press F7. MANAGE Data: Job Name, Lines (X) page Highlight the line F1. CLOSE (F4) to close the line.
Page 197: Data Log
Data Log Description A list of all objects and free codes in the active job is displayed in order of time. Access step-by-step Access within data management Step Description Refer to "9.2 Accessing Data Management" to access MANAGE Data: Job Name. In MANAGE Data: Job Name on the Points page, SHIFT LOG (F4) to access MANAGE Data Log: Job Name.
Page 198 Access by user defined menu Press USER. Refer to "6.2 USER Key" for information on the USER key. MANAGE In the column Data Record, all points, lines and areas as well as free codes stored within Data Log: Job Name the active job are displayed.
Page 199 MORE (F5) To display information about the type of data recorded, the time and the date of when it was stored or for lines and areas when they were created and the codes if stored with any object. Next step CONT (F1) returns to the screen from where MANAGE Data Log: Job Name was accessed.
Page 200: Point Sorting And Filters
Point Sorting and Filters 9.6.1 Sorting and Filters for Points, Lines and Areas Description The sort settings define the order of the objects in the active job. The filter settings define the objects to be viewed. Three types of filters are available: Point filter: An active point filter shows selected points in MANAGE Data: Job Name, Points page.
Page 201 Access step-by-step Step Description Refer to "9.2 Accessing Data Management" to access MANAGE Data: Job Name. In MANAGE Data: Job Name on the Points, Lines (X) or Areas (X) page, SHIFT FILT (F5) to access MANAGE Sorts & Filters. MANAGE Sorts & Filters This screen consists of three pages, one for each type of object.
Page 202 Description of fields Field Option Description <Sort:> Ascend Point ID, Always available. The method points are sorted by. Descend Point ID, Forward Time or Backward Time <Filter:> Always available. The method the points are filtered No Filter Shows all points. Highest Class Shows points of highest class.
Page 203 Field Option Description Radius From Pt Shows points within the defined radius from a partic- ular point. The radius is the horizontal distance. Individual Line Shows points forming a selected line. This may for example be useful during stakeout. Individual Area Shows points forming a selected area.
Page 204 The coordinate triplets of the highest class are shown. All Triplets All classes for one coordinate triplet are shown. <Instrument:> All, TPS, GPS, Available for <Filter: Instrument>. Points originating LEICA Geo Office, from this instrument type are shown. Level, Data Logger, Third Party SW or Unknown <Type:>...
Page 205 Field Option Description <Radius:> User input Available for <Filter: Radius From Pt>. The radius of the circle within which the points are shown. <Line ID:> Choicelist Available for <Filter: Individual Line>. Opening the choicelist opens MANAGE Data: Job Name. Refer to "9.2 Accessing Data Management".
Page 206 MANAGE Sorts & Filters, Lines page CONT (F1) To close the screen and return to the screen from where this screen was accessed. The selected sort and filter settings are applied and the lists in MANAGE DATA: Job Name are updated.
Page 207 Field Option Description Code/Code Group Shows lines with selected codes attached. Refer to "9.6.2 Point, Line and Area Code Filter" since the functionality is identical to the point code filter. Next step PAGE (F6) changes to the Areas page. Refer to paragraph "MANAGE Sorts & Filters, Areas page".
Page 208 Next step CONT (F1) returns to the screen from where MANAGE Sorts & Filters was accessed. Manage...\Data GPS1200+...
Page 209: Point, Line And Area Code Filter
9.6.2 Point, Line and Area Code Filter For each object, a code filter exists. The point, line and area code filters are independent from each other. The functionality is identical. For simplicity, the point code filter is explained. Access step-by-step Step Description Refer to "9.6.1 Sorting and Filters for Points, Lines and Areas"...
Page 210 USE (F5) To activate and deactivate the filter for the highlighted code. NONE (F6) or ALL (F6) To deactivate or activate all point codes. SHIFT SORT (F5) To define the order of the codes. Accesses MANAGE Sort Codes. Manage...\Data GPS1200+...
Page 211: Stakeout Filter
9.6.3 Stakeout Filter Description The settings on this screen define a filter for the Stakeout application program, for example to show points which are already staked or points that are still to be staked. The stakeout filter acts in addition to any other filter set in MANAGE Sorts & Filters. For example, points still to be staked out with a particular code can be filtered.
Page 212 Description of fields Field Option Description <View:> Shows all points. Pts to Stakeout Shows points not yet staked out. Staked Points Shows points which are already staked out. Manage...\Data GPS1200+...
Page 213: Terminology
Manage...\Codelists 10.1 Terminology Description This chapter describes technical terms related to codes and codelists. The values for code groups, codes and attributes are case sensitive. For example the code group Tree is not the same as the code group TREE. Object For coding, points, lines and areas have the same behaviour.
Page 214 Thematical codes: Free codes: Object related information recorded Time related information together with the actual object in the field. recorded between objects in the field. A time stamp is recorded with each free code. It allows to export free codes and objects in a chronological order to be used for third party mapping software.
Page 215 Code types The code type defines how and for which objects a code can be used. It is possible to create a code of the same name but of different code types both on the receiver and in LGO. Example: The code Oak can exist with code type point code and with code type line code. Point code: To record a code directly with a point.
Page 216 Attribute value type: Text Real Integer Attribute value region: Attribute value region: None Choicelist None Choicelist Range Attribute types The attribute type defines the input requirements for the attribute. Normal: An input for the attribute is optional. The attribute value can be typed in in the field.
Page 217 Text: Any input for the attribute is interpreted as text. New attributes with this attribute value type can be created in LGO or on the receiver. Real: An input for the attribute must be a real number, for example 1.23. New attributes with this attribute value type can be created in LGO.
Page 218 Codelist Description A codelist is a collection of codes that can be used to describe surveyed objects in the field. Elements of a codelist • Code group • Code • Attributes Manage...\Codelists GPS1200+...
Page 219 Structure of a codelist Structure Example Codelist Codelist |—— Code group 1 |—— Trees |—— Code 1.1 |—— Birch |—— Attribute 1.1.1 |—— Height |—— Attribute ... |—— Condition |—— Attribute 1.1.20 |—— Remark |—— Code 1.2 |—— Oak |—— Attribute 1.2.1 |——...
Page 220: Overview
10.2 Overview It is recommended to create a codelist in LGO. A codelist can be transferred from LGO to the System RAM of the receiver using the CompactFlash card. Steps from creating to Codelist Tools: Transfer Receiver using a codelist Manage- ment: Serial...
Page 221: Accessing Codelist Management
10.3 Accessing Codelist Management Access Select Main Menu: Manage...\Codelists. From a choicelist in some screens, for example MANAGE New Job, Codelist page. MANAGE Listed are all codelists stored in the System RAM. Codelists CONT (F1) To return to the screen from where this screen was accessed.
Page 222 Next step IF a codelist THEN is to be selected highlight the desired codelist. CONT (F1) copies the codes of the codelist to the active job, closes the screen and returns to the screen from where MANAGE Codelists was accessed. is to be created NEW (F2).
Page 223: Creating/Editing A Codelist
10.4 Creating/Editing a Codelist Access Refer to "10.3 Accessing Codelist Management" to access MANAGE Codelists. Create/edit a codelist The following table explains the most common settings. Refer to the stated chapter for more step-by-step information on screens. Step Description Refer to chapter MANAGE Codelists 10.3...
Page 224: Managing Codes
10.5 Managing Codes 10.5.1 Accessing MANAGE Codes Description Managing codes includes • creating new codes • viewing codes with their related information • editing codes. • deleting existing codes. Access step-by-step Step Description Refer to "10.3 Accessing Codelist Management" to access MANAGE Codelists. In MANAGE Codelists highlight the codelist of which codes are to be managed.
Page 225 The indicates codes which have attributes attached. CONT (F1) To close the screen and return to the screen from where this screen was accessed. NEW (F2) To create a new code. Refer to "10.5.2 Creating a New Code". EDIT (F3) To edit the highlighted code.
Page 226 Next step THEN a code is to be NEW (F2). Refer to "10.5.2 Creating a New Code". created a code is to be edited highlight the code and EDIT (F3). Refer to "10.5.3 Editing a Code". code groups are to be SHIFT GROUP (F4).
Page 227: Creating A New Code
10.5.2 Creating a New Code Create a new code step- The following table explains the most common settings. Refer to the stated chapter for more by-step information on screens. Step Description Refer to chapter Refer to "10.5.1 Accessing MANAGE Codes" to access MANAGE Codes.
Page 228 Step Description Refer to chapter • None: Select this option to disable the functionality. All other code settings on the instrument are not affected when this option is set. • Begin Line: When a point code is newly selected, a new line is opened and the point being stored is added to the line.
Page 229 Step Description Refer to chapter Up to twenty attributes can be created. Is another attribute to be created? • If yes, repeat step 4. • If no, continue with step 6. STORE (F1) adds the new code and any associated attributes to the System RAM codelist and returns to the screen from where this screen was accessed.
Page 230: Editing A Code
10.5.3 Editing a Code Access step-by-step Step Description Refer to "10.5.1 Accessing MANAGE Codes" to access MANAGE Codes. EDIT (F3) to access MANAGE Edit Code. All following steps are identical with the creation of a new code. Refer to "10.5.2 Creating a New Code". Follow the instructions in paragraph "Create a new code step-by-step"...
Page 231: Managing Code Groups
10.6 Managing Code Groups Access step-by-step Step Description Refer to "10.5.1 Accessing MANAGE Codes" to access MANAGE Codes. SHIFT GROUP (F4) to access MANAGE Code Groups. MANAGE The listed code groups belong to Code Groups the selected System RAM codelist when this screen was accessed through Main Menu: Manage...\Codelists.
Page 232 USE (F5) To activate and deactivate the highlighted code group. Codes belonging to a deactivated code group are not displayed in MANAGE Codes. NONE (F6) or ALL (F6) To deactivate or activate all code groups. Description of columns Column Description Code Group The name of the code group.
Page 233: Coding
Coding 11.1 Overview Description A code is a description which can be stored with a point, line, area or alone. Coding on GPS1200+ is very flexible with thematical, free and quick coding being available. Thematical and free coding is possible by selecting codes from a codelist or by directly typing in codes.
Page 234 Coding Characteristic Description method Recording of the Together with the objects. codes Free To store a description independent of an object at any time. A free code can be used to store a descrip- tion related to an object or to store additional descriptions such as the job name or the tempera- ture.
Page 235 Coding Characteristic Description method Selection of the codes Shortcuts must be assigned to codes in the job codelist. <Quick Code: On> must be set in CONFIGURE Coding & Linework. Typing the shortcut searches for the assigned code. Point occu- pation begins. Recording of the •...
Page 236: Thematical Coding
11.2 Thematical Coding 11.2.1 Thematical Coding with Codelist Requirements • The job codelist contains thematical codes for points, lines and/or areas. • <Thematc Codes: With Codelist> in CONFIGURE Coding & Linework. • A display mask with an input field for codes must be configured. Access Open the choicelist for <Code:>...
Page 237 MANAGE MANAGE Select Code is shown as an example. Select Code CONT (F1) To return to the screen from where this screen was accessed. NEW (F2) To create a new code. Refer to "10.5.2 Creating a New Code". ATRIB (F3) Available unless accessed from MANAGE New Point/Line/Area or MANAGE Edit Point/Line/Area.
Page 238 Thematical coding with The following table explains the most common settings. Refer to the stated chapter for more codelist step-by-step information on screens. Step Description Refer to chapter Refer to paragraph "Access" to access XX Select Code. MANAGE Select Code Depending on the setting for <Show Codes:>...
Page 239 Step Description Refer to chapter If configured for the selected code, input fields for attribute values are available. Type in the attribute values. Attribute values for attributes of type • normal can be typed in. • fixed cannot be edited. NEW-A (F2) to add a new attribute of type normal and of value type text.
Page 240 Step Description Refer to chapter If a point with the same point ID exists in the job, the codes, the 11.6 attribute names and the attribute values of the new and the existing point must be identical. Should they not be identical, a screen opens where the code or attribute mismatch can be corrected.
Page 241: Thematical Coding Without Codelist
11.2.2 Thematical Coding without Codelist Requirements • <Thematc Codes: Without Codelist> in CONFIGURE Coding & Linework. • A display mask with an input field for codes must be configured. • A display mask with an choicelist for code types must be configured. Access A thematical code is typed in the field <Code:>...
Page 242 Step Description <Code:> The name for the point, line or area code. <Attribute n:> The attribute values for the code. Type in a code and attribute values. Up to eight attributes can be added. This is configured in the display mask. •...
Page 243: Free Coding
11.3 Free Coding 11.3.1 Free Coding Using a Codelist In this chapter, free coding using a codelist is explained for points. Refer to "9.4 Line/Area Management" for information on coding lines/areas. Requirements • The job codelist contains free codes. • A hot key is configured to access the screen FREECODE Select Free Code or the user defined menu is configured to display the option Select Free Code.
Page 244 FREECODE STORE (F1) Select Free Code To store the free code and any associated attribute values and to return to the screen from where this screen was accessed. NEW (F2) To create a new code. Refer to "10.5.2 Creating a New Code". ATRIB (F3) To type in attribute values and/or add new attributes for the selected free code.
Page 245 Free coding using a The following table explains the most common settings. Refer to the stated chapter for more codelist step-by-step information on screens. Step Description Refer to chapter Refer to paragraph "Access" to access FREECODE Select Free Code. FREECODE Select Free Code All free codes from the job codelist which belong to the active code 10.6 groups are available for selection.
Page 246 Step Description Refer to chapter NAME (F3) or VALUE (F3) Available for attributes for which an attribute name can be typed in. To highlight <Attribute n:> or the field for the attribute value. Attributes of type mandatory or fixed and of value type real or integer online help must be created in LGO.
Page 247: Free Coding With Direct Input
11.3.2 Free Coding with Direct Input In this chapter, free coding with direct input is explained for points. Refer to "9.4 Line/Area Management" for information on coding lines/areas. Requirements A hot key is configured to access the screen FREECODE Enter Free Code & Attributes or the user defined menu is configured to display the option Enter Free Code.
Page 248 Step Description Available if a free code has been previously used in the active job. Accesses FREECODE Last Used Free Codes. To select from a list of last used free codes. The free codes are sorted by time with the most recently used code at the top of the list.
Page 249: Quick Coding
11.4 Quick Coding Requirements • The job codelist contains quick codes for points, lines and/or areas. • According to the requirements of the used CAD package, set <Rec Free Code: Before Point> or <Rec Free Code: After Point> in CONFIGURE Coding & Linework. Activate quick coding The current setting for <Quick Code:>...
Page 250 Quick coding for points The following table explains the most common settings. Refer to the stated chapter for more step-by-step information on screens. Step Description Refer to chapter Refer to paragraph "Activate quick coding" to activate quick coding. A screen must be active where points can be occupied. OCUPY (F1) must be visible.
Page 251 Step Description Refer to chapter • fixed cannot be edited. The point code and any associated attribute values are stored with the point. This can be automatic if <Auto STOP: Yes> and <Auto STORE: Yes> is configured or manual with STOP (F1) and STORE (F1).
Page 252 Step Description Refer to chapter Quick coding for a free code is finished. Quick coding for The following table explains the most common settings. Refer to the stated chapter for more lines/areas step-by-step information on screens. Step Description Refer to chapter Refer to paragraph "Activate quick coding"...
Page 253: Smartcodes
11.5 SmartCodes 11.5.1 Overview Description SmartCodes is basically a quick way for code to be selected and point to be measured. All existing coding, linework, and point measurement functionality is retained. Coding GPS1200+...
Page 254: Configuring Smartcodes
11.5.2 Configuring SmartCodes Access Select Main Menu: Survey. In SURVEY Survey Begin press CONF (F2) to access SURVEY Configuration. In SURVEY Survey: Job Name press SHIFT CONF (F2) to access SURVEY Configu- ration. SURVEY The settings on this page activate the using of SmartCodes and define the method. All Configuration, settings in this panel are stored within the currently active configuration set.
Page 255 Description of fields Field Option Description <Use Activates using of SmartCodes. SCodes:> All other fields on the screen are active and can be edited. Deactivates using of SmartCodes and all fields on this screen. <Show Info:> Information shown in line 8 of SURVEY Survey: Job name, SCode page.
Page 256 Field Option Description Linework The linework flag to be stored with the point. The options available depend on whether a line/area is currently open. Refer to "12.2 Performing Linework" for an explanation of the options that become avail- able in SURVEY Survey: Job name, SCode page. <Measure Yes or No If one of the code boxes is tapped in SURVEY...
Page 257 Field Option Description <Direction:> The way of using the code boxes. This influences in which order the code boxes will be applied. Forward The code boxes are used in the same way as defined in SURVEY Survey: Job name, SCode page. Backward The code boxes are used in the reverse way as defined in SURVEY Survey: Job name, SCode...
Page 258: Code Block
11.5.3 Code Block Requirements • <Use SCodes: Yes> in SURVEY Configuration, SCode page. SURVEY Survey: Job Name, SCode page OCUPY (F1) To start recording positions. The position mode icon changes to the static icon. (F1) changes to STOP. The highlighted code is stored with the point.
Page 259 Step Description Refer to chapter PAGE (F6) until the SCode page is visible. With the focus on <Code Block: 1> press enter to access SURVEY Manage Code Blocks panel. NEW (F2) to create a new code block. Code blocks can only be created or deleted in SURVEY Manage Code Blocks panel.
Page 260 Step Description Refer to chapter Code blocks are stored in the job. Refer to paragraph "Accessing Job Management" to access MANAGE Edit Job: Job Name, Codelist page. <Codelist:> If codes had been copied from a System RAM codelist, the name of the codelist is displayed. If codes have been typed in, then the name of the active job is displayed.
Page 261: Using Smartcodes
11.5.4 Using SmartCodes Measuring points using The following table explains the most common settings. Refer to the stated chapter for more Code Blocks step-by- information on screens. step Step Description Refer to chapter Refer to paragraph "Creating a Code Block step-by-step" to access 11.5.3 SURVEY Survey: Job Name, SCode page.
Page 262 Measuring lines/ares The following table explains the most common settings. Refer to the stated chapter for more using Code Blocks information on screens. step-by-step Step Description Refer to chapter Activate <Show Info: Linework> in SURVEY Configuration, 11.5.2 SCode page. Refer to paragraph "Creating a Code Block step-by-step" to access 11.5.4 SURVEY Survey: Job Name, SCode page.
Page 263: Code And Attribute Mismatch
11.6 Code and Attribute Mismatch 11.6.1 Code Mismatch Description When storing a point with a code, it may happen that a point with the same point ID already exists in the job. If the codes of the new and the existing point do not match, a screen opens where the code can be corrected.
Page 264 Match codes step-by- Step Description step XX Point Code Mismatch opens automatically if the codes of the new and the existing point do not match. Highlight the code to be stored with the new point. STORE (F1) stores the highlighted code and any associated attributes with the point being stored and continues with the application program or data manage- ment.
Page 265: Attribute Mismatch
11.6.2 Attribute Mismatch Description If a point with the same point ID exists in the job, the codes, the attribute names and the attribute values of the new and the existing point must be identical. Should they not be iden- tical, a screen opens where the attribute mismatch can be corrected.
Page 266 Description of fields Field Option Description <Point Code:> Output • For XX Attributes Already Stored: The code of the existing point in the job. • For XX Attributes Being Stored: The code of the new point. Attributes Output • For XX Attributes Already Stored: The attributes as stored for the existing point in the job.
Page 267: Linework
Linework 12.1 Overview Description Working with lines can be automated. Two ways of working are available. They are listed in the table below. The two ways of working can be mixed. Linework by Description Linework In all application programs and on the Auto page in Survey, a display mask listbox can be configured to show a field <Linework:>...
Page 268: Performing Linework
12.2 Performing Linework The Survey application program is used here to explain Linework. Requirements • A display mask with a choicelist for Linework must be configured. • The flags for Linework must be defined in CONFIGURE Coding & Linework Settings, Linework page.
Page 269 SURVEY The most important keys are explained. For the explanation of the other keys refer to "45.3.3 Survey: Job Name, Real-Time Rover Operations". Survey page OCUPY (F1) To start recording positions. The position mode icon changes to the static icon. (F1) changes to STOP.
Page 270 Field Option Description • To start a new sequence of point ID’s type over the point ID. • For an individual point ID independent of the ID template SHIFT INDIV (F5). SHIFT RUN (F5) changes back to the next ID from the configured ID template.
Page 271 Field Option Description ReOpen Last Line Opens the last used line again. The last code used with the reopened line is automatically selected when the point is stored. End Line Closes all open lines. Cont Line/Area Indicates a line/area is open. Start Spline Stores the linework flag for beginning a spline and continues any open line/area.
Page 272 Field Option Description Close Area Closes all open areas. Next step Step Description Go to the point to be occupied. Select the linework flag to be stored with the next point. OCUPY (F1) STOP (F1) STORE (F1) Depending on the option selected for <Linework:>, a line/area is opened, closed or re-opened.
Page 273: Combining Linework And Coding
12.3 Combining Linework and Coding Description Linework and coding can be combined. This combination can be useful, because coding, assigning linework flags and opening/closing lines/areas can all be done with one point observation. Combining Linework and coding can only be configured if thematical point codes or if themat- ical point, line and area codes are available for selection.
Page 274 <Code:> Required Optional Appearance Choicelist User input Choicelist User input <Code Type:> Required Optional Appearance Output Output Output Choicelist <Linework:> Required Optional Appearance Choicelist Choicelist Choicelist Choicelist Requirements • A display mask must be configured with • a field for codes. •...
Page 275 • <Thematc Codes: With Codelist> or <Thematc Codes: Without Codelist>. • In CONFIGURE Coding & Linework Settings, Linework page define the flags for Line- work. • <R-Time Mode: None> or <R-Time Mode: Rover> in CONFIGURE Real-Time Mode. The Survey application program is used here to explain the combination of Linework and Coding.
Page 276 OCUPY (F1) To start recording positions. The position mode icon changes to the static icon. (F1) changes to STOP. STOP (F1) To end recording of positions when enough data is collected. When <Auto STOP: Yes> in CONFIGURE Point Occupation Settings, recording of positions ends automatically as defined by the stop criteria.
Page 277 Step Field Description for thematical coding With codelist Without codelist <Code Type:> Point is displayed. This field is an output field. It can not be changed. <Linework:> Select an option for the Linework flag to be stored with the point. Refer to "12.2 Performing Linework"...
Page 278 For <Show Codes: All Codes> Step Field Description for thematical coding With codelist Without codelist <Code:> Select a code from the Type in a code. choicelist. Point, line and area codes are available for selec- tion. <None> to store a point without ----- to store a point without code or to perform Linework code or to perform Linework...
Page 279 Step Field Description for thematical coding With codelist Without codelist • An open line/area is closed when the selection for <Line- work:> was not changed but • the selection for <Code:> was changed. • the same code was re-selected, for example by using the right/left arrow key.
Page 280: Manage
Manage...\Coordinate Systems 13.1 Overview Description A coordinate system • consists of up to five elements. • allows the conversion from WGS 1984 geodetic or cartesian coordinates to, local carte- sian, geodetic or grid coordinates and back. • can be attached to jobs. •...
Page 281 Elements of coordinate The five elements which define a coordinate system are: system • a transformation • a projection • an ellipsoid • a geoid model • a Country Specific Coordinate System model Manage...\Coordinate Systems GPS1200+...
Page 282 a) WGS 1984 cartesian: X, Y, Z b) WGS 1984 ellipsoid c) WGS 1984 geodetic: Latitude, longitude, ellip- soidal height d) 7 parameter transformation: dX, dY, dZ, rx, ry, rz, scale e) Local cartesian: X, Y, Z f) Local ellipsoid g) Local geodetic: Latitude, longitude, ellipsoidal height h) Local projection...
Page 283 Default coordinate The default coordinate system is WGS 1984. It cannot be deleted. systems Additional default coordinate systems may be available for certain countries. Coordinate system WGS 1984 is the global geocentric datum to which all GPS positioning information is referred WGS 1984 to.
Page 284: Terminology
13.2 Terminology Description This chapter describes technical terms related to coordinate system management. Transformation Refer to "39.1 Overview" for information on transformations. Geoid model Description GPS operates on the WGS 1984 ellipsoid and all heights obtained by measuring baselines are ellipsoidal heights. Existing heights are usually orthometric heights, also called height above the geoid, height above mean sea level or levelled height.
Page 285 N value and geoid model The geoid separation (N value) is the distance between the geoid and the reference ellipsoid. It may refer to the WGS 1984 or to the local ellipsoid. It is not a constant except over maybe small flat areas such as 5 km x 5 km.
Page 286 of CSCS models are supported by GPS1200+. Their conversion process is as explained in the following table. Any suitable geoid model can be combined with a geodetic CSCS model. Refer to the online help of LGO for more information on CSCS models. Type Description Grid...
Page 287: Accessing Coordinate System Management
13.3 Accessing Coordinate System Management Access Select Main Menu: Manage...\Coordinate Systems. Press a hot key configured to access the screen MANAGE Coordinate Systems. Refer to "6.1 Hot Keys" for information on hot keys. Press USER. Refer to "6.2 USER Key" for information on the USER key. From a choicelist in some screens for example in MANAGE New Job, Coord System page.
Page 288 MANAGE Listed are all coordinate systems stored in the database DB-X. Any unavailable information Coordinate Systems is shown as -----. CONT (F1) To select the highlighted coordinate system and to return to the previous screen. With a CompactFlash card inserted, the selected coordinate system will be attached to the active job.
Page 289 SHIFT DEFLT (F5) To recall the deleted default coordinate systems. Next step IF a coordinate THEN system is to be selected highlight the desired coordinate system. CONT (F1) closes the screen and returns to the screen from where MANAGE Coordinate Systems was accessed. is to be created highlight any coordinate system and NEW (F2).
Page 290: Coordinate Systems
13.4 Coordinate Systems 13.4.1 Creating a New Coordinate System Coordinate systems can be defined by manual creation or determined by calculation. In this chapter, the manual creation of coordinate systems is explained. Refer to "39 Deter- mine Coordinate System - General" for information on the determination by calculation. Coordinate systems with a Classic 3D transformation can be defined by manual creation.
Page 291 Step Description Refer to chapter <Residuals:> Available for transformations with control points. Manually entered transformations do not have control points. The method by which residuals are distributed throughout the transforma- tion area. The transformation results become more realistic and any strain is dispersed in the transformation.
Page 292: Editing A Coordinate System
13.4.2 Editing a Coordinate System The type of transformation of the selected coordinate system determines which elements of a coordinate system can be edited. The name of the coordinate system, the method of residual distribution and the geoid model in use are always editable. For coordinate systems with source RTCM only the geoid model in use can be changed.
Page 293 Step Description Refer to chapter <Pre Transform:> Available for Twostep transformations. The name of a preliminary 3D transformation which is used together with the selected projection to obtain preliminary grid coordinates to be used for a final 2D transformation. Make the required changes. STORE (F1) stores the changes and returns to MANAGE Coordi- nate Systems.
Page 294: Transformations
13.5 Transformations 13.5.1 Accessing Transformation Management MANAGE Transformations cannot be accessed for coordinate systems with source RTCM. Refer to "RTCM coordinate system". Access step-by-step Step Description Refer to "13.3 Accessing Coordinate System Management" to access MANAGE Coordinate Systems. In MANAGE Coordinate Systems highlight a coordinate system to be edited. EDIT (F3) In MANAGE Edit Coordinate System highlight <Transform:>.
Page 295 MANAGE Listed are all Classic 3D transformations stored in the database DB-X. Any unavailable infor- Transformations mation is shown as -----. CONT (F1) To select the highlighted transformation and to return to the previous screen. NEW (F2) To create a new transformation. Refer to "13.5.2 Creating a New Transformation".
Page 296 Next step IF a transformation THEN is to be selected highlight the desired transformation. CONT (F1) closes the screen and returns to the screen from where MANAGE Transformations was accessed. is to be created highlight any transformation and NEW (F2). Refer to "13.5.2 Creating a New Transformation".
Page 297: Creating A New Transformation
13.5.2 Creating a New Transformation Classic 3D transformations can be created. Access Refer to "13.5.1 Accessing Transformation Management" to access MANAGE Transforma- tions. Create a transformation The following table explains the most common settings. Refer to the stated chapter for more step-by-step information on screens.
Page 298 Step Description Refer to chapter MANAGE New Transformation, More page <Height Mode:> The type of heights to be computed. <Transf Model:> The transformation model to be used. For <Transf Model: Molodensky-Bad>, additional input fields are available. Select at least a height mode and a transformation model. CLEAR (F5) Available for <Transf Model: Molodensky-Bad>.
Page 299: Editing A Transformation
13.5.3 Editing a Transformation Access step-by-step Step Description Transformations with source RTCM cannot be edited. Refer to "RTCM coordinate system". Refer to "13.5.1 Accessing Transformation Management" to access MANAGE Transformations. In MANAGE Transformations highlight a transformation to be edited. EDIT (F3) to access MANAGE Edit Transformation. All following steps are identical with the creation of a new transformation.
Page 300: Ellipsoids
13.6 Ellipsoids 13.6.1 Accessing Ellipsoid Management MANAGE Ellipsoids cannot be accessed for coordinate systems with source RTCM. Refer to "RTCM coordinate system". Access step-by-step Step Description Refer to "13.3 Accessing Coordinate System Management" to access MANAGE Coordinate Systems. In MANAGE Coordinate Systems highlight a coordinate system to be edited. EDIT (F3) to access MANAGE Edit Coordinate System.
Page 301 CONT (F1) To select the highlighted ellipsoid and to return to the previous screen. NEW (F2) To create a new ellipsoid. Refer to "13.6.2 Creating a New Ellipsoid". EDIT (F3) To edit the highlighted ellipsoid. Refer to "13.6.3 Editing an Ellipsoid". DEL (F4) To delete the highlighted ellipsoid.
Page 302 IF an ellipsoid THEN is to be edited highlight the ellipsoid and EDIT (F3). Refer to "13.6.3 Editing an Ellipsoid". Manage...\Coordinate Systems GPS1200+...
Page 303: Creating A New Ellipsoid
13.6.2 Creating a New Ellipsoid Access Refer to "13.6.1 Accessing Ellipsoid Management" to access MANAGE Ellipsoids. Create an ellipsoid The following table explains the most common settings. Refer to the stated chapter for more step-by-step information on screens. Step Description Refer to chapter In MANAGE Ellipsoids highlight an ellipsoid.
Page 304: Editing An Ellipsoid
13.6.3 Editing an Ellipsoid Access step-by-step Step Description Refer to "13.6.1 Accessing Ellipsoid Management" to access MANAGE Ellip- soids. In MANAGE Ellipsoids highlight an ellipsoid to be edited. EDIT (F3) to access MANAGE Edit Ellipsoid. All following steps are identical with the creation of a new ellipsoid. Refer to "13.6.2 Creating a New Ellipsoid".
Page 305: Projections
13.7 Projections 13.7.1 Accessing Projection Management MANAGE Projections cannot be accessed for coordinate systems with source RTCM. Refer to "RTCM coordinate system". Access step-by-step Step Description Refer to "13.3 Accessing Coordinate System Management" to access MANAGE Coordinate Systems. In MANAGE Coordinate Systems highlight a coordinate system to be edited. EDIT (F3) to access MANAGE Edit Coordinate System.
Page 306 MANAGE Listed are all projections stored in the database DB-X. Any unavailable information is shown Projections as -----. CONT (F1) To select the highlighted projection and to return to the previous screen. NEW (F2) To create a new projection. Refer to "13.7.2 Creating a New Projection".
Page 307 Column Option Description Customised Customised projection. Certain fixed projections which cannot be defined by any of the following options. Trans Mercator Transverse Mercator. Conformal projection onto a cylinder with its axis lying on the equatorial plane. The cylinder is tangential to a meridian. Universal Transverse Mercator.
Page 308 Column Option Description Cassini-Soldn Soldner Cassini. Projection onto a cylinder. It is neither equal area nor conformal. The scale is true along the central meridian and along lines perpendic- ular to central meridian. Polar Stereo Polar Stereographic. Conformal azimuthal projection onto a plane.
Page 309 IF a projection THEN is to be edited highlight the projection and EDIT (F3). Refer to "13.7.3 Editing a Projection". Manage...\Coordinate Systems GPS1200+...
Page 310: Creating A New Projection
13.7.2 Creating a New Projection Access Refer to "13.7.1 Accessing Projection Management" to access MANAGE Projections. Create a projection The following table explains the most common settings. Refer to the stated chapter for more step-by-step information on screens. Step Description Refer to chapter In MANAGE Projections highlight a projection.
Page 311: Editing A Projection
13.7.3 Editing a Projection Access step-by-step Step Description Projections with source RTCM cannot be edited. Refer to "RTCM coordinate system". Refer to "13.7.1 Accessing Projection Management" to access MANAGE Projec- tions. In MANAGE Projections highlight a projection to be edited. EDIT (F3) to access MANAGE Edit Projection.
Page 312: Geoid Models Overview
13.8 Geoid Models 13.8.1 Overview Use in the field For use on the receiver in the field, geoid field files are created from the geoid model. Geoid field file The geoid separations in a geoid field file may be used in the field to change between ellip- soidal and orthometric heights.
Page 313 Here the geoid field file is stored in the internal memory of the receiver. It is recom- mended for large geoid field files. This method is also explained in this chapter. Transfer Creation Geoid field file on the System Geoid model Main Menu: CompactFlash card on the receiver...
Page 314: Accessing Geoid Model Management
13.8.2 Accessing Geoid Model Management Access step-by-step Step Description Refer to "13.3 Accessing Coordinate System Management" to access MANAGE Coordinate Systems. In MANAGE Coordinate Systems highlight a coordinate system to be edited. EDIT (F3) to access MANAGE Edit Coordinate System. In MANAGE Edit Coordinate System highlight <Geoid Model:>.
Page 315 EDIT (F3) To view the highlighted geoid model. None of the fields can be edited. The geoid field file from which the geoid model was created must be stored in the System RAM or in the \DATA\GPS\GEOID directory on the Compact- Flash card / internal memory.
Page 316: Creating A New Geoid Model From The Compactflash Card / Internal Memory
13.8.3 Creating a New Geoid Model from the CompactFlash Card / Internal Memory Refer to "26 Tools...\Transfer Objects..." for information on how to transfer geoid field files to the System RAM on the receiver. Requirement At least one geoid field file with the extension *.gem is in the \DATA\GPS\GEOID directory on the CompactFlash card / internal memory.
Page 317: Cscs Models
13.9 CSCS Models Use in the field For use on the receiver in the field, CSCS field files are created from the CSCS model. CSCS field file CSCS field files may be used in the field to directly convert coordinates from WGS 1984 to local grid without the need of transformation parameters.
Page 318: Manage
Manage...\Configuration Sets 14.1 Overview Description The receiver has numerous user configurable parameters and functions. This allows a variety of preferences to be addressed. The configuration of the parameters and functions for an individual measuring technique are combined in a configuration set. Default configuration Default configuration sets exist on the instrument.
Page 319: Accessing Configuration Set Management
14.2 Accessing Configuration Set Management Access Select Main Menu: Manage...\Configuration Sets. Press a hot key configured to access the screen MANAGE Configuration Sets. Refer to "6.1 Hot Keys" for information on hot keys. Press USER. Refer to "6.2 USER Key" for information on the USER key. From a choicelist in some screens for example the begin screen of application programs.
Page 320 MORE (F5) To display information about the description, the creator and the creation date of the config- uration set. SHIFT SET-D (F4) Available unless a default configuration set is highlighted. To turn the highlighted configura- tion sets into a user defined default configura- tion set stored in the receiver.
Page 321: Creating A New Configuration Set
14.3 Creating a New Configuration Set 14.3.1 Initial Steps Configuration step-by- The following table explains the most common settings. Refer to the stated chapter for more step information on individual screens. Step Description Refer to chapter Refer to "14.2 Accessing Configuration Set Management" to access MANAGE Configuration Sets.
Page 322 Step Description Refer to chapter CONFIGURE Wizard Mode 21.1 <Wizard Mode: Reduced> LIST (F6) accesses CONFIGURE Quick Access. Lists all screens within the configuration set. Allows to access these individual screens and to change settings. CONT (F1) Is the configuration for a static operation? 14.3.2 Is the configuration for a post-processed kinematic operation? 14.3.3...
Page 323: Configuration Set For Static Operations
14.3.2 Configuration Set for Static Operations Description Configuring the receiver for post-processed static operations. Configuration step-by- The following table provides recommendations for the most common settings. For all other step fields, the default settings can be used. Refer to the stated chapter for more information on individual screens.
Page 324 Step Description Refer to chapter DMASK (F3) configures the selected display mask. CONT (F1) CONFIGURE Coding & Linework 19.3 <Quick Code: Off> <Attributes: Default Values> CONT (F1) CONFIGURE Logging of Raw Obs 19.5 <Log Raw Obs: Static Only> • For static operations with long baselines and over long time: <Log Rate: 15.0s>...
Page 325 Step Description Refer to chapter <Auto STOP: No> <Auto STORE: No> CONT (F1) CONFIGURE Quality Control Settings 19.4 <Allow 2D Posn: Yes> CONT (F1) CONFIGURE ID Templates <Survey Pts: No Template Used> <Auto Pts: Time & Date> <Auxil Pts: No Template Used> <Lines: No Template Used>...
Page 326: Configuration Set For Post-Processed Kinematic Operations
14.3.3 Configuration Set for Post-Processed Kinematic Operations Description Configuring the receiver for post-processed kinematic operations. Configuration step-by- The following table provides recommendations for the most common settings. For all other step fields, the default settings can be used. Refer to the stated chapter for more information on individual screens.
Page 327 Step Description Refer to chapter CONT (F1) CONFIGURE Coding & Linework 19.3 <Quick Code: Off> <Attributes: Default Values> CONT (F1) CONFIGURE Logging of Raw Obs 19.5 <Log Raw Obs: Static & Moving> FILES (F6) CONFIGURE Raw Observation Files 19.5 <Use Separate Files: No> CONT (F1) leads back to CONFIGURE Logging of Raw Obs CONT (F1) CONFIGURE Point Occupation Settings...
Page 328 Step Description Refer to chapter <Allow 2D Posn: Yes> CONT (F1) CONFIGURE ID Templates <Survey Pts: No Template Used> <Auto Pts: Time & Date> <Auxil Pts: No Template Used> <Lines: No Template Used> <Areas: No Template Used> CONT (F1) MANAGE Configuration Sets The adapted configuration set is highlighted.
Page 329: Configuration Set For Real-Time Reference Operations
Refer to "14.3 Creating a New Configuration Set". Follow the instruc- tions in paragraph "Configuration step-by-step" up to step 7. CONFIGURE Real-Time Mode 22.3.3 <R-Time Mode: Reference> <R-Time Data: Leica> RATES (F3) CONFIGURE Data Rates 22.3.3 <Data: 1.0s> <Coords: 10s>...
Page 330 Step Description Refer to chapter CONT (F1) leads back to CONFIGURE Real-Time Mode DEVCE (F5) to configure devices. 23.2 REF (F2) configures additional reference station options like time 22.3.3 slicing. SHIFT RT-2 (F2) configures a second real-time device. 14.3.4 CONT (F1) The sequence of screens varies slightly when a second real-time device was configured before the configuration set wizard was started.
Page 331 Step Description Refer to chapter <Attributes: Default Values> CONT (F1) CONFIGURE Logging of Raw Obs 19.5 <Log Raw Obs: No> CONT (F1) MANAGE Configuration Sets The adapted configuration set is highlighted. CONT (F1) closes the screen and returns to GPS1200+ Main Menu. The highlighted configuration set is then the active configuration set.
Page 332: Configuration Set For Real-Time Rover Operations
Refer to "14.3 Creating a New Configuration Set". Follow the instruc- tions in paragraph "Configuration step-by-step" up to step 7. CONFIGURE Real-Time Mode 22.3.4 <R-Time Mode: Rover> <R-Time Data: Leica> ROVER (F2) configures additional rover station options such as using 22.3.4 a reference network. DEVCE (F5) to configure devices.
Page 333 Step Description Refer to chapter The next screen depends on the setting for <Device:> in 23.2 CONFIGURE Real-Time Mode. Set the parameters required. CONT (F1) CONFIGURE Antenna & Antenna Heights 20.1 <Antenna: AX1203+ GNSS Pole> <Default Ht: 2.0000> <Meas Type: Vertical> CONT (F1) CONFIGURE Display Settings 19.2...
Page 334 Step Description Refer to chapter CONT (F1) CONFIGURE Point Occupation Settings 19.6 <Pt Occupation: Normal> <Auto OCCUPY: No> <Auto STOP: No> <Auto STORE: No> CONT (F1) CONFIGURE Quality Control Settings 19.4 <Allow 2D Posn: Yes> CONT (F1) CONFIGURE ID Templates <Survey Pts: No Template Used>...
Page 335 Step Description Refer to chapter CONT (F1) closes the screen and returns to GPS1200+ Main Menu. The highlighted configuration set is then the active configuration set. Manage...\Configuration Sets GPS1200+...
Page 336: Editing A Configuration Set
14.4 Editing a Configuration Set Description There are two possibilities to edit a configuration set. Using the configuration set wizard to be lead through the steps. Outside of the configuration set wizard. Each screen can be accessed separately without being guided through the steps. Access step-by-step Step Description...
Page 337 In CONFIGURE Wizard Mode, press LIST (F6). Refer to "14.3 Creating a New Configu- ration Set". Manage...\Configuration Sets GPS1200+...
Page 338: Overview
Manage...\Antennas 15.1 Overview Description • Leica Geosystems antennas are predefined as default and can be selected from a list. • Additional antennas can be defined. • Default antennas contain an elevation dependent correction model. • New antenna correction models can be set up and transferred to the receiver using LGO.
Page 339: Manage
15.2 Accessing Antenna Management Access Select Main Menu: Manage...\Antennas. Press a hot key configured to access the screen MANAGE Antennas. Refer to "6.1 Hot Keys" for information on hot keys. Press USER. Refer to "6.2 USER Key" for information on the USER key. From a choicelist in some screens for example the SURVEY Survey Begin screen.
Page 340 SHIFT DEFLT (F5) To recall previously deleted default antennas and to reset default antennas to the default settings. User defined antennas are not affected. Next step IF an antenna THEN is to be selected highlight the desired antenna. CONT (F1) closes the screen and returns to the screen from where MANAGE Antennas was accessed.
Page 341: Creating A New Antenna
15.3 Creating a New Antenna Access Refer to "15.2 Accessing Antenna Management" to access MANAGE Antennas. Create new antenna The following table explains the most common settings. Refer to the stated chapter for more step-by-step information on screens. Step Description Refer to chapter In MANAGE Antennas press NEW (F2).
Page 342 Step Description Refer to chapter <Serial Number:> The serial number of the antenna. <Set Up Number:> The set up number of the antenna. This identifies the version number of the current calibration. The combination of values typed in here provides a unique standard- ised ID for the antenna being used.
Page 343: Editing An Antenna
MANAGE Edit Antenna All the following steps are identical with the creation of a new antenna. All fields can be edited except those of Leica default antennas. Refer to "15.3 Creating a New Antenna". Follow the instructions from step 2.
Page 344: Convert
CompactFlash card. • to a file on the internal memory if fitted. • via RS232 to a Leica TPS400/700 instrument. Refer to "22.6 Export Job" for information on how to configure the interface. Export format Format...
Page 345 Format Characteristic Description Specialities: Points in file outside of CSCS The default value for missing variable is model output. Points in file outside of geoid The default value for missing variable is model output, also if a geoid separation is available. Coordinate conversion All points are converted to local grid position using the coordinate system.
Page 346 Format Characteristic Description Points in file outside of geoid The ellipsoidal height is exported. model Convert...\Export Data from Job GPS1200+...
Page 347: Accessing The Data Export Functionality
16.2 Accessing the Data Export Functionality Access Select Main Menu: Convert...\Export Data from Job. Press a hot key configured to access the screen EXPORT Export Data from Job. Refer to "6.1 Hot Keys" for information on hot keys. Press USER. Refer to "6.2 USER Key" for information on the USER key. Next step IF exporting to THEN...
Page 348: Exporting Data From A Job To A Custom Ascii Format
16.3 Exporting Data from a Job to a Custom ASCII Format Description The settings on this screen define the data that is converted and exported and what format is used. Data is exported from the selected job. Currently active view, filter and sort settings are applied.
Page 349 Step Description Refer to chapter <Job:> All jobs from Main Menu: Manage...\Jobs can be selected. When in this choicelist press CFCRD (F6) or INTL (F6) to select a job from a different memory device. <Coord System:> The coordinate system currently attached to the selected <Job:>.
Page 350 Step Description Refer to chapter FILT (F4) to set the sort and filter settings for export. Accesses EXPORT Sorts & Filters. EXPORT Sorts & Filters, Points page <Sort:> The order in which points, lines and areas are exported. <Filter:> Defines which points are exported. PAGE (F6) changes to the Lines or Areas page.
Page 351: Exporting Data From A Job To Another Device
16.4 Exporting Data from a Job to another Device General Data can be transferred to a Leica TPS400/700 via RS232. Access Refer to "16.2 Accessing the Data Export Functionality" to access EXPORT Export ASCII Data from Job. Export data step-by- The following table explains the most common settings.
Page 352 Step Description Refer to chapter CONT (F1) accepts the changes and returns to EXPORT Export ASCII Data from Job. CSYS (F6) accesses EXPORT Coordinate Systems. To update the 13.3 coordinate system in which the coordinates are exported. CONT (F1) exports the data. Information message: Are more data to be exported? •...
Page 353: Exporting Data In Dxf Format
16.5 Exporting Data in DXF Format General Data can be exported to a DXF file in the \DATA directory of the CompactFlash card or the internal memory, if fitted. Access Refer to "16.2 Accessing the Data Export Functionality" to access EXPORT Export DXF from Job.
Page 354 Step Description <Areas:> Defines if areas are exported. <Filter:> Defines which points are exported. PAGE (F6) changes to the DXF page. <Lines & Areas:> Defines if lines and areas are exported as Line or Polyline enti- ties. <LGO Symbols:> Defines if a block is created for each point with the same icons used in LGO.
Page 355 Step Description If no, continue with step 6. YES (F6). Repeat steps 1. to 4. NO (F4) returns to the GPS1200+ Main Menu. Convert...\Export Data from Job GPS1200+...
Page 356: Exporting Data In Landxml Format
16.6 Exporting Data in LandXML Format General Data can be exported to a LandXML file in the \DATA directory of the CompactFlash card or the internal memory, if fitted. Access Refer to "16.2 Accessing the Data Export Functionality" to access EXPORT Export LandXML from Job.
Page 357 Step Description <Areas:> Defines if areas are exported. <TPS Measurements:> Defines if TPS observations are exported. <GPS Measurements:> Defines if GPS observations are exported. <Codes:> Defines if point codes, line codes and area codes are exported. <Free Codes:> Defines if the free code, the free code description, the free code group and the free code attributes are exported to the LandXML file associated to each exported point.
Page 358 Step Description CONT (F1) exports the data. Message: Do not remove CF Card! Information message: Are more data to be exported? If yes, continue with step 5. If no, continue with step 6. YES (F6). Repeat steps 1. to 6. NO (F4) returns to the GPS1200+ Main Menu.
Page 359: Convert
Convert...\Import Data to Job 17.1 Overview Description This screen lists all the importers loaded. The data to import must be stored on the Compact- Flash card or in the internal memory, if fitted. Data can be imported to a job •...
Page 360 Format Characteristic Description Neither coordinates nor No import heights in file No point ID’s in file No import GSI8 Import variables Point ID (WI 11), local coordinates (WI 81, GSI16 WI 82, WI 83), thematical codes (WI 71). No free codes, no attributes. Example for GSI8: 110014+00001448 81..01+00001363 82..01-00007748 83..01-00000000 71..+000sheep...
Page 361 Format Characteristic Description Format definition Fixed format (X/Y/Z). Units Not predefined. Heights Z value imported as orthometric. Specialities Neither coordinates nor No import heights in file Checks Points are always imported with the class CTRL and a coordinate quality of -----. Refer to "9.3.1 Terminology".
Page 362 Case 2: Point already exists in database with a class other than CTRL Add point to database? Point not imported. Is a code attached to the point? Point imported. Point imported. Is the attached code the same as for the point already existing in the database? Point imported, existing code from data- Should the existing code for the...
Page 363 Point imported with code. Convert...\Import Data to Job GPS1200+...
Page 364: Accessing The Data Import Functionality
17.2 Accessing the Data Import Functionality Access Select Main Menu: Convert...\Import Data to Job. Press a hot key configured to access the screen IMPORT Import Data to Job. Refer to "6.1 Hot Keys" for information on hot keys. Press USER. Refer to "6.2 USER Key" for information on the USER key. Next step IF importing data in THEN ASCII format...
Page 365: Importing Data In Ascii Format
17.3 Importing Data in ASCII Format Requirements At least one ASCII file with any file extension is stored in the \DATA directory of the Compact- Flash card. Access Refer to "17.2 Accessing the Data Import Functionality" to access IMPORT Import ASCII/GSI Data to Job.
Page 366 Step Description <No. Lines/Pt:> Available for <Delimiter: Line Feed>. The number of lines used to describe each point. Select the delimiter and the positions of the particular variables. DEFLT (F5) recalls the default ASCII import settings. CONT (F1) leads back to IMPORT Import ASCII/GSI Data to Job SHIFT HTS (F2) to access IMPORT Define Ht Type &...
Page 367: Importing Data In Gsi Format
17.4 Importing Data in GSI Format Requirements At least one ASCII file in GSI format with the file extension *.gsi is stored in the \GSI directory of the CompactFlash card. Access Refer to "17.2 Accessing the Data Import Functionality" to access IMPORT Import ASCII/GSI Data to Job.
Page 368 Step Description CONT (F1) leads back to IMPORT Import ASCII/GSI Data to Job CONT (F1) imports the data. Points with a height > 20000 m are not imported. Information message: Are more data to be imported? • If yes, continue with step 7. •...
Page 369: Importing Data In Dxf Format
17.5 Importing Data in DXF Format Requirements At least one file in DXF format with the file extension *.dxf has to be stored in the \DATA direc- tory of the CompactFlash card. Access Refer to "17.2 Accessing the Data Import Functionality" to access DXF IMPORT Import DXF Data to Job.
Page 370 Step Description <Exclude Height:> Height value inside the DXF file are considered invalid and will not be converted. CONT (F1) leads back to DXF IMPORT Import DXF Data to Job CONT (F1) imports the data. Message: Do not remove CF Card! Information message: Are more data to be imported? If yes, continue with step 5.
Page 371: Convert
Convert...\Copy Points Between Jobs Description This chapter explains the process of copying points from one job to another. Important features: • Points are copied as defined by the point filter settings. • Points selected for copying may be viewed in a points listing. The point sort settings define the order of the points in the listing.
Page 372 COPY Copy Points Between Jobs CONT (F1) To copy a selection of points. FILT (F4) To define the point sort and/or point filter settings of points from the job <From Job:>. DATA (F5) To view, edit and delete points, lines and areas stored with the job.
Page 373: Config
Config...\Survey Settings... 19.1 ID Templates 19.1.1 Overview Description ID templates are predefined templates for point, line or area numbers. ID templates save having to type in the ID for each object. They are useful when many points are collected quickly, for example in post-processed and real-time kinematic operations. The ID templates that are selected to be used suggest ID’s for <Point ID:>, <Line ID:>...
Page 374 Default ID template Description Line0001 Suggested as ID for lines in default configuration sets. This ID is automatically incremented. No Template Used The last point ID during a survey will be displayed. This ID is auto- matically incremented if it contains numerical characters. If this ID is overwritten, the auto increment starts from the new ID.
Page 375: Accessing Id Template Configuration
19.1.2 Accessing ID Template Configuration Access Select Main Menu: Config...\Survey Settings...\ID Templates. Press a hot key configured to access the screen CONFIGURE ID Templates. Refer to "6.1 Hot Keys" for information on hot keys. Press USER. Refer to "6.2 USER Key" for information on the USER key. Within the configuration set wizard.
Page 376 Description of fields Field Option Description <Survey Pts:> Choicelist Sets the ID templates for manually occupied points. <Auto Pts:> Choicelist Sets the ID templates for auto points. These points are automatically recorded at a specific rate. <Auxil Pts:> Choicelist Sets the ID templates for auxiliary points. These points are used when trying to find a stake-out point.
Page 377: Creating A New Id Template
19.1.3 Creating a New ID Template Create ID template step- Step Description by-step Refer to "19.1.2 Accessing ID Template Configuration" to access CONFIGURE ID Templates. In CONFIGURE ID Templates highlight any field. ENTER to access CONFIGURE ID Template Library. Highlight an ID template. A copy of this ID template is taken for further configura- tions.
Page 378 Step Description CONT (F1) returns to the screen from where CONFIGURE ID Templates was accessed. Examples for incremen- For <Increment: Numeric only> tation The rightmost numeric part is incremented within the point ID. <ID:> <Increment Next point ID Notes By:> Point994 Point999 Point1004...
Page 379 <ID:> <Increment Next point ID Notes By:> Abcdefghijklmno9 Abcdefghijklmnop4 Negative incrementing fails if Point ID increment fail next increment requires nega- tive sign and will result in more than 16 characters. For <Increment: Alphanumeric> The rightmost character within the point ID is incremented regardless of whether that char- acter is numeric or alphanumeric.
Page 380 Template Increment Next point ID’s Notes value ABCDEB ABCDEB Upper case alpha characters ABCDEG increment from upper to lower case until z is reached. Then a Abcdez new point ID must be entered. Point ID increment fail Config...\Survey Settings... GPS1200+...
Page 381: Editing An Id Template
19.1.4 Editing an ID Template Edit ID template step- Step Description by-step Refer to "19.1.2 Accessing ID Template Configuration" to access CONFIGURE ID Templates. In CONFIGURE ID Templates highlight any field. ENTER to access CONFIGURE ID Template Library. CONFIGURE ID Template Library Highlight the ID template to be edited.
Page 382 Step Description CONT (F1) returns to CONFIGURE ID Templates. CONT (F1) returns to the screen from where CONFIGURE ID Templates was accessed. Config...\Survey Settings... GPS1200+...
Page 383: Deleting An Id Template
19.1.5 Deleting an ID Template Delete ID template step- Step Description by-step Refer to "19.1.2 Accessing ID Template Configuration" to access CONFIGURE ID Templates. In CONFIGURE ID Templates highlight any field. ENTER CONFIGURE ID Template Library Highlight the ID template to be deleted. DEL (F4) It does not matter if the ID template is being used in a configuration set.
Page 384: Working Example
19.1.6 Working Example Description Application: • Pick up points with many different point ID’s. • Most point ID’s require an incrementing number behind a text. Working technique: Real-time kinematic. Goal: • The first point ID’s for survey points are Bolt 001, Bolt 002, ..•...
Page 385 Step Description CONT (F1) returns to CONFIGURE ID Templates. CONFIGURE ID Templates <Survey Pts: Bolt 001> CONT (F1) returns to the screen from where CONFIGURE ID Templates was accessed. Field procedure step- Step Description by-step Refer to "45.3 Surveying Points" to access SURVEY Survey: Job Name. SURVEY Survey: Job Name <Point ID: Bolt 001>...
Page 386 Step Description STOP (F1) STORE (F1) <Point ID: Road0724> is shown automatically. Repeat steps 7. to 9. until all points with the ID RoadXXXX are surveyed. SURVEY Survey: Job Name The next required point ID is BM98. It is valid for one point. SHIFT INDIV (F5) SURVEY Survey: Job Name Type BM98.
Page 387: Display Settings
19.2 Display Settings Description Display settings define the parameters shown on a page on the SURVEY screen. Four display masks are definable. Mask 1: Always shown on the SURVEY screen. Mask 2: Can be shown or hidden on the SURVEY screen. Mask 3: Can be shown or hidden on the SURVEY screen.
Page 388 CONFIGURE Display Settings CONT (F1) return to the screen To accept changes and from where this screen was accessed DMASK (F3) To configure the selected display mask. Refer to paragraph "CONFIGURE Define Display Mask n". Description of fields Field Option Description <Define:>...
Page 389 Next step IF a display mask THEN is not to be edited CONT (F1) closes the screen and returns to the screen from where CONFIGURE Display Settings was accessed. is to be edited highlight the display mask and DMASK (F3). Refer to paragraph "CONFIGURE Define Display Mask n".
Page 390 Field Option Description <Fixed Lines:> From 0 to 5 Defines how many lines do not scroll in the survey screen when that display mask is used. <1st Line:> Output Fixed to <1st Line: Point ID>. <2nd Line:> to For each line one of the following options can be <16th Line:>...
Page 391 Field Option Description GDOP Output field for the current GDOP of the computed position. HDOP Output field for the current HDOP of the computed position. Line Space Full Insert full line space. Line Space Half Insert half line space. Linework Choicelist with option for flagging a line/area.
Page 392 Field Option Description RTK Positions Output field for the number of positions recorded over the period of point occupation. Appears in the display mask of real-time rover configurations. Rel Humidity Input field for relative humidity to be stored with point. Temp Dry Input field for dry temperature to be stored with point.
Page 393: Coding & Linework
19.3 Coding & Linework Description The settings on this screen define the method of coding. Refer to "11 Coding" for a complete description of coding. Access Select Main Menu: Config...\Survey Settings...\Coding & Linework Settings. Press a hot key configured to access the screen CONFIGURE Coding & Linework. Refer to "6.1 Hot Keys"...
Page 394 Description of fields Field Option Description <Quick Code:> Never Prevents the use of quick coding completely. Allows the use of quick coding and activates it. Allows the use of quick coding, but keeps it deacti- vated. <Digits:> 1, 2 or 3 Available unless <Quick Code: Never>.
Page 395 Field Option Description <Mand Always Prompt The screen XX Enter Mandatory Attribute will Attribs:> always appear when codes, having one or more attributes of attribute type mandatory, are being stored. Attributes of attribute type mandatory or fixed can only be created in LGO. Only If No Value The screen XX Enter Mandatory Attribute will only appear when codes, having one or more attributes of...
Page 396 Field Option Description All Codes All codes of the job codelist will be available in the choicelist for <Code:>/<Point Code:> in a display mask of an application program. Selecting a line/area code opens a new line/area. <String Choicelist Available for <Show Codes: All Codes>. Attrib:>...
Page 397 CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Begin Line:> User input Opens a new line when the next point is stored. Any lines which are currently open are closed.
Page 398 Field Option Description <Start Spline:> User input Stores the linework flag for beginning a spline and continues any open line/area. <End Spline:> User input Stores the linework flag to stop a spline. <Cont Spline:> User input Indicates a line/area is open with spline line type. <Begin Area:>...
Page 399: Quality Control Settings
19.4 Quality Control Settings Description The settings on this screen define the limits for coordinate quality and DOP values accepted for point occupations. Access Select Main Menu: Config...\Survey Settings...\Quality Control Settings. Press a hot key configured to access the screen CONFIGURE Quality Control Settings. Refer to "6.1 Hot Keys"...
Page 400 Description of fields Field Option Description <CQ Control:> None, Pos Only, The type of coordinate quality to be checked before Height Only or storing a point. If activated, the limit defined in Pos & Height <Maximum CQ:> is checked before storing a point. A warning signal is given when the limit is exceeded.
Page 401 Next step CONT (F1) returns to the screen from where CONFIGURE Qualtiy Control Settings was accessed. Config...\Survey Settings... GPS1200+...
Page 402: Logging Of Raw Obs
19.5 Logging of Raw Obs Description Logged raw observations are used for • static and kinematic operations. With these operations, raw data is always post-proc- essed in the office. Raw data must therefore be logged on both reference and rover receivers.
Page 403 Within the configuration set wizard. Refer to "14.2 Accessing Configuration Set Manage- ment". CONFIGURE Logging of Raw Obs CONT (F1) To accept changes and return to the screen from where this screen was accessed. Description of fields Field Option Description <Log Raw Never Available unless <R-Time Mode: Reference>.
Page 404 Field Option Description Static & Moving Available unless <R-Time Mode: Reference>. Raw observation logging during static and moving inter- vals. For post-processed kinematic rover operations. If Radio Down Available for <R-Time Mode: Rover>. Continuous raw observation logging during static and moving intervals when no real-time corrections are being received by a receiver.
Page 405 Field Option Description • For static operations with long baselines and over long time <Log Rate: 15.0s> or <Log Rate: 30.0s>. • For reference stations for post-processed and real-time kinematic rovers, <Log Rate:> at the reference should be the same rate as at the rover. •...
Page 406 CONFIGURE Raw Observation Files CONT (F1) To accept changes and to return to CONFIGURE Logging of Raw Obs. Description of fields Field Option Description <Use Separate Yes or No Stores all raw observations into one or into separate Files:> files. <Obs File From 1 min to 24 Available for <Use Separate Files: Yes>.
Page 407 Field Option Description Moving intervals are always interrupted and written to a new file when the time set for <Obs File Size:> is reached. <Delete Old Yes or No Available for <Use Separate Files: Yes>. Deletes Files:> the recorded data after a specified period of time. <When Older From 1 day to 30 Available for <Delete Old Files: Yes>.
Page 408: Point Occupation Settings
19.6 Point Occupation Settings 19.6.1 Configuration of Point Occupation Settings Description The settings on this screen define the way in which points are occupied and recorded. Point occupation settings are configurable for <R-Time Mode: Rover> and <R-Time Mode: None>. Access Select Main Menu: Config...\Survey Settings...\Point Occupation Settings.
Page 409 CONFIGURE Point Occupation Settings CONT (F1) To accept changes and return to the screen from where this screen was accessed. PARAM (F3) To configure the time interval after which a point occupation can be stopped automatically. Refer to paragraph "CONFIGURE Post- Process Stop Criteria".
Page 410 Field Option Description Instantaneous Records the time tag when OCUPY (F1) is pressed. A coordinate is interpolated between the positions at the neighbouring two epochs to filter out effects of slight movement. Recommended when measuring positions of objects while the antenna is moving. Example: Measuring the position of lampposts by driving in a car along the road and pressing OCUPY (F1) when the car is next to the lamppost.
Page 411 Field Option Description Defines the method used for <Auto STOP:>. The setting determines the computation and value to be shown for <% Completed:> in the display mask and in STATUS Occupation Information. Parameters for the selected method are defined with PARAM (F3).
Page 412 Field Option Description None, Time, Available for <R-Time Mode: None>. Observations or No. of Satellites <Beep On Yes or No Activates that a beep is made when the point occupa- STOP:> tion is ended by <Auto STOP:>. <Auto Yes or No Stores points automatically after stopping the point STORE:>...
Page 413 Point occupation mode Normal a) Time in epochs b) OCUPY (F1) pressed c) STOP (F1) pressed d) Post-processed coordinates computed by averaging resulting positions of epochs 2 and GPS12_056 Point occupation mode Instantaneous a) Time in epochs b) OCUPY (F1) pressed and point coordinates interpolated based on epochs 2 and 3 c) OCUPY (F1) pressed and point coordinates interpolated based on epochs 4 and 5...
Page 414 Next step IF parameters for THEN <Auto STOP:> are not to be config- CONT (F1) closes the screen and ured returns to the screen from where CONFIGURE Point Occupation Settings was accessed. are to be configured <R-Time Mode: None> PARAM (F3) changes to CONFIGURE Post-Process Stop Criteria.
Page 415 CONFIGURE Post-Process Stop Criteria CONT (F1) To accept changes and to return to CONFIGURE Point Occupation Settings Description of fields The parameters shown on this screen depend on the setting for <STOP Criteria:> in CONFIGURE Point Occupation Settings. Field Option Description <Time at Point:>...
Page 416 Field Option Description <At Logging Output Displays the rate at which static raw observations are Rate:> logged as configured in CONFIGURE Logging of Raw Obs. <8+ satellites for:> User input Sets the required observation time depending on the <7 satellites for:> number of satellites available.
Page 417 CONFIGURE Real-Time Stop Criteria CONT (F1) To accept changes and to return to CONFIGURE Point Occupation Settings. Description of fields The parameters shown on this screen depend on the setting for <STOP Criteria:> in CONFIGURE Point Occupation Settings. Field Option Description <Pos Quality User input...
Page 418 Field Option Description <Position Output Displays the value for <Position and Screen Update:> Update:> as configured in CONFIGURE Display Settings. <No. of Posi- User input Sets the number the positions which must be tions:> observed before the receiver stops measuring. Counting the number of positions starts when OCUPY (F1) is pressed.
Page 419 Observation time depending on the number of satellites available GPS12_075 Thin line represents <6 satellites for: 3 min>. Bold line represents <5 satellites for: 5 min>. Dashed line represents <4 satellites for: 7 min>. a) OCUPY (F1) is pressed. Counting time starts. b) Observation is stopped.
Page 420: Working Example
19.6.2 Working Example Description Application: • Surveying individual points in a kinematic chain. • Required accuracy less than 30 mm. Working technique: Real-time kinematic Aim: • Press OCUPY (F1) to start recording manually. • Stop recording and storing points without user interaction. •...
Page 421 Step Description CONFIGURE Post-Process Stop Criteria Type in how many positions are to be occupied before the point occupation stops automatically. The number varies with each application. CONT (F1) closes the screen. CONT (F1) returns to the screen from where CONFIGURE Point Occupation Settings was accessed.
Page 422: Seismic Recording
19.7 Seismic Recording Description In some countries, certain information must be documented for seismic surveys. This infor- mation is output as a seismic record. Refer to "Appendix H Seismic Record Format" for a detailed description of the seismic record format. The settings on this screen activate seismic recording.
Page 423 CONFIGURE Seismic Recording CONT (F1) To accept changes and return to the screen from where this screen was accessed. Description of fields Field Option Description <Store Yes or No Stores a seismic record with each real-time point. Seismic The seismic record is stored in point annotation 4 of Record:>...
Page 424 Next step CONT (F1) returns to the screen from where CONFIGURE Seismic Recording was accessed. Config...\Survey Settings... GPS1200+...
Page 425: Ring Buffer
• can be configured and used from an external software using special commands from Outside World Interface or Leica Binary 2 format. Documentation for OWI and LB2 is available on request from the Leica Geosystems representative. •...
Page 426 Reserved space on When a ring buffer is activated a check is made that there is enough free space on the memory device CompactFlash card or in the internal memory to log the data with the defined observation rate and data interval. This required space is reserved, so that it cannot be used by other applications such as logging the standard set of raw data.
Page 427: Configuring And Using A Ring Buffer
19.8.2 Configuring and Using a Ring Buffer Access Select Main Menu: Config...\Survey Settings...\Ring Buffer. This option is not available for RX1250 with SmartAntenna. The configuration of an active ring buffer cannot be changed. In order to change the config- uration of a ring buffer, raw data logging for the ring buffer must be stopped and the recorded raw data must be deleted.
Page 428 Description of fields Field Option Description <Buffer No.:> From 0 to 9 The number of the ring buffer to be configured or used. Up to ten ring buffers can be configured, one ring buffer can be used at a time. <Status:>...
Page 429 Field Option Description <Data From 10 min to Available for <Configuration: Overall Length>. The Interval:> 4 weeks duration for how long data is recorded to the ring buffer before newly observed data is recorded over the oldest data. <File Length:> From 1 min to 24 h Available for <Configuration: No. of Files>. For how long data are written to one file before a new file is created.
Page 430 THEN a ring buffer is to be deactivated select the desired <Buffer No.:>. STOP (F3). the raw data on a deactivated ring select the desired <Buffer No.:>. DEL (F4). buffer is to be deleted the screen is to be quit ESC.
Page 431: Config
Config...\Instrument Settings... 20.1 Antenna & Antenna Heights Description The settings on this screen define the antenna and the default height for the antenna. Refer to "2 Antenna Heights" for all information about antenna heights. Access Select Main Menu: Config...\Instrument Settings...\Antenna & Antenna Heights. Press a hot key configured to access the screen CONFIGURE Antenna &...
Page 432 CONFIGURE Antenna & Antenna Heights CONT (F1) To accept changes and return to the screen from where this screen was accessed. Description of fields Field Option Description <Antenna:> Choicelist Antennas in the receiver’s System RAM or as defined in Main Menu: Manage...\Antennas. <Default Ht:>...
Page 433 Field Option Description <Meas Type:> Slope or Vertical The way the antenna height will be measured. <Horiz Offset:> Output Available for <Meas Type: Slope>. The horizontal antenna offset for the selected antenna. <Moving Ht:> User input Sets the default antenna height for auto points and for the moving part of a track when logging raw observa- tions.
Page 434: Satellite Settings
20.2 Satellite Settings Description The settings on this screen define which satellite system (available for GX1230+ GNSS/ ATX1230+ GNSS), satellites and satellite signals will be used by the receiver. Access Select Main Menu: Config...\Instrument Settings...\Satellite Settings. Within the configuration set wizard. Refer to "14.2 Accessing Configuration Set Manage- ment".
Page 435 Description of fields Field Option Description <GLONASS:> Yes or No Available for GX1230+ GNSS/ATX1230+ GNSS/ GX1220+ GNSS/GRX1200+ GNSS. Defines if GLONASS satellite signals are accepted by the receiver when tracking satellites. <Galileo:> Yes or No Available for GX1230+ GNSS/ATX1230+ GNSS/ GX1220+ GNSS/GRX1200+ GNSS.
Page 436 Field Option Description This setting is remembered when the receiver is turned off. It is stored as part of the configu- ration set. Automatic Incoming satellite signals are monitored by the receiver. Data from signals which are flagged as unhealthy are neither recorded nor used for real-time computations.
Page 437 CONFIGURE This screen consists of the GPS page, GLO page and the GAL page. The explanations for Satellite Tracking, the softkeys given below are valid for all pages. GPS page CONT (F1) To accept changes and return to the screen from where this screen was accessed.
Page 438 Column Option Description System OK, N/A or Information on the satellite health taken from the Unhealthy almanac. N/A stands for not available. User Excludes satellite from tracking. Includes satellite in tracking. Auto Automatic satellite tracking when satellite is healthy. This setting is remembered until the receiver is turned off.
Page 439: Time Zone
20.3 Time Zone Description The settings on this screen help the receiver to quickly locate and track satellites. Access Select Main Menu: Config...\Instrument Settings...\Time Zone. Within the configuration set wizard. Refer to "14.2 Accessing Configuration Set Manage- ment". CONFIGURE Local Time Zone CONT (F1) To accept changes and to return to GPS1200+ Main Menu.
Page 440 Field Option Description <Local Time:> User input Setting the local time and date supports a very fast <Local Date:> satellite acquisition. Next step CONT (F1) returns to GPS1200+ Main Menu. Config...\Instrument Settings... GPS1200+...
Page 441: Instrument Id
20.4 Instrument ID Description The settings on this screen define the instrument identification number. This number is used for the generation of the file names. Using format files, the instrument ID can be output together with data from the instrument. By doing so, it can be identified which instrument was used for certain measurements.
Page 442 Description of fields Field Option Description <Instrument User input Sets a four digit number as instrument identification ID:> number. By default the last four numbers of the serial number are used. Next step CONT (F1) returns to GPS1200+ Main Menu. Config...\Instrument Settings...
Page 443: Set Net Parameters
20.5 Set NET Parameters The Set NET Parameters option is available on the GRX1200+ and GRX1200+ GNSS. Description The settings on the screen allow the network parameters to be defined for the Ethernet device. Typical uses The Ethernet connection can be used to remotely •...
Page 444 Within the configuration set wizard. Refer to "14.2 Accessing Configuration Set Manage- ment". CONFIGURE Set NET Parameters CONT (F1) To return to GPS1200+ Main Menu. CLEAR (F5) To reset all fields to their default values. Description of fields Field Option Description <IP Address:>...
Page 445 Field Option Description <Network User input Used together with the IP address to identify the Mask:> network the receiver is on. It is a 32 bit number which must be obtained from the network administrator or the Internet service provider. The format of the network mask is aaa.bbb.ccc.ddd where aaa is a value ranging from 001 to 255 and bbb, ccc and ddd are values ranging from 000 to 255.
Page 446: Config
Config...\General Settings... 21.1 Wizard Mode Description The settings on this screen define the behaviour of the configuration set wizard. Access Select Main Menu: Config...\General Settings...\Wizard Mode. Within the configuration set wizard. Refer to "14.2 Accessing Configuration Set Manage- ment". CONFIGURE Wizard Mode CONT (F1) To accept changes and to return to GPS1200+...
Page 447 Description of fields Field Option Description <Wizard View All Screens All configuration screens are shown in the configura- Mode:> tion set wizard. Application program configuration screens are not included. They can be configured within each application program. Reduced A reduced set of screens are shown in the configura- tion set wizard.
Page 448: Hot Keys & User Menu
21.2 Hot Keys & User Menu Description The settings on this screen assign a particular function, screen or application program to each of the first and second level of hot keys and to the USER key. Refer to "6 Configurable Keys"...
Page 449 CONFIGURE To configure the first level of hot keys. Hot Keys & User Menu, Hot Keys page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option...
Page 450 CONFIGURE To configure the second level of hot keys. Hot Keys & User Menu, The functionality on this page is identical to the one on the Hot Keys page. Shift Hot Keys page Next step PAGE (F6) changes to the User Menu page. Refer to paragraph "CONFIGURE Hot Keys & User Menu, User Menu page".
Page 451 Next step PAGE (F6) changes to the first page on this screen. Config...\General Settings... GPS1200+...
Page 452: Units & Formats
21.3 Units & Formats Description The settings on this screen define • the units for all types of measurement data displayed. • information related to some types of measurement data. • the order in which coordinates are displayed. Access Select Main Menu: Config...\General Settings...\Units & Formats. Press a hot key configured to access the screen CONFIGURE Units &...
Page 453 CONFIGURE Units & Formats, Units page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Distance The units shown for all distance and coordinate Unit:>...
Page 454 Field Option Description Kilometres (km) Kilometres [km] <Distance From 0 Decimals The number of decimal places shown for all distance Dec:> to 4 Decimals and coordinate related fields. This is for data display and does not apply to data export or storage. The available options depend on the selected <Distance Unit:>.
Page 455 Field Option Description <Velocity Km/h (kmh), Mph The units shown for all velocity related fields. Unit:> (mph) or Knots (kn) <Area Unit:> , Int Acres (Ai), The units shown for all area related fields. US Acres (A), Hectares (ha), fi or ft <Temp Unit:>...
Page 456 CONFIGURE Units & Formats, Angle page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Direc Ref:> North Azimuth, Sets the reference direction as well as the direction South Azimuth,...
Page 457 Field Option Description GPS12_084 For all other options, the azimuth/bearing fields in other screens are called <Azimuth:>. <Direc Base:> True or Magnetic Sets the North direction. <Mag Declin:> User input Available for <Direc Base: Magnetic>. The value for the magnetic declination. It is consid- ered when computing or using any azimuth values.
Page 458 CONFIGURE Units & Formats, Time page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Time 24 hour or 12 hour How the time is shown in all time related fields.
Page 459 CONFIGURE Units & Formats, Format page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Grid East,North or The order in which grid coordinates are shown in all Format:>...
Page 460: Language
21.4 Language Description The setting on this screen defines the language used on the instrument. Three languages can be stored on the receiver at one time - English and two others. English cannot be deleted. Refer to "27.2 System Languages" for information on uploading languages. Access Select Main Menu: Config...\General Settings...\Language.
Page 461 Column Description The selected language is used for the system software. If a language is not available for the system software, the English language is used instead. Application programs run in the language they were loaded. Next step CONT (F1) returns to GPS1200+ Main Menu. Config...\General Settings...
Page 462: Display, Beeps, Text
21.5 Display, Beeps, Text Description The settings on this screen allow the screen appearance to be configured, turn the notifica- tion beeps on and off and define the behaviour of the keys. The settings are stored on the RX1200 itself. If RX1200’s are exchanged, the settings stored on the new RX1200 apply. Access Select Main Menu: Config...\General Settings...\Display, Beeps, Text.
Page 463 Field Option Description <Screen Off, Soft or Loud Controls the beep upon touching the touch screen. Beep:> <Screen Off, Always On, Controls the screen illumination to be on, off or on for Illum:> On for 1 min, On the specified time after the last key was pressed, or for 2 min or On for touch screen event.
Page 464 CONFIGURE Display, Beeps, Text, Beeps page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Warning Off, Soft or Loud Controls the beep for acoustic warning signals.
Page 465 CONFIGURE Display, Beeps, Text, Text page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Deflt αNum:> Choicelist Sets the set of extra characters available through αNUM or F1-F6 whenever an entry is made.
Page 466: Start Up & Power Down
21.6 Start Up & Power Down Power Down is unavailable for a RX1250 with SmartAntenna. Description The settings on this screen • define the behaviour of the instrument for a general start up. • define the behaviour of the instrument when starting up after a power loss. •...
Page 467 For receivers delivered with firmware version 2.10 or higher, the PUK code comes with the receiver. • For receivers delivered with firmware versions lower than v2.10, contact a Leica representative to obtain a PUK code. Access Select Main Menu: Config...\General Settings...\Start Up & Power Down.
Page 468 CONFIGURE Start Up & Power Down, Start Up page CONT (F1) To accept changes and to return to GPS1200+ Main Menu. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Start Choicelist Determines the screen entered after turning on the Screen:>...
Page 469 CONFIGURE This page is not available for RX1250 with SmartAntenna. Start Up & Power Down, Power Down page CONT (F1) To accept changes and to return to GPS1200+ Main Menu. PAGE (F6) To change to another page on this screen. Description of fields Field Option...
Page 470 Field Option Description <Set Primary:> External A, Available for the GRX1200+ Series where batteries External B or can be attached to port PWR with a Y-cable. Sets the Automatic external battery which is always used when sufficient power is available, regardless of the status of the other battery.
Page 471 Description of fields Field Option Description Use PIN Yes or No Activates the PIN code protection. This setting is not part of the configuration set. New PIN User input The PIN code must be a number with four to six digits.
Page 472 Next step PAGE (F6) changes to the first page on this screen. Config...\General Settings... GPS1200+...
Page 473: Config
Config...\Interfaces... - General 22.1 Overview Description The receiver has a variety of interfaces which can be configured to be used with different ports and devices. The configuration varies depending on the individual application. Interface, port and Description of the technical terms device Technical term Description...
Page 474: Accessing Configuration Interfaces
22.2 Accessing Configuration Interfaces Access Select Main Menu: Config...\Interfaces..Press a hot key configured to access the screen CONFIGURE Interfaces. Refer to "6.1 Hot Keys" for information on hot keys. Press USER. Refer to "6.2 USER Key" for information on the USER key. CONFIGURE The screen gives an overview of all interfaces with the currently assigned port and device.
Page 475 SHIFT CONEC (F4) and SHIFT DISCO (F4) Available for a real-time interface configured to use a device of type digital cellular phone or modem. To dial the number of another station configured in the active configuration set and to hang up again. Description of columns Column Option...
Page 476 Next step THEN an interface is to be highlight the interface to be configured and EDIT (F3). Refer to the edited sections in this chapter on each individual interface. a device attached to highlight the relevant interface and CTRL (F4). Refer to "24 an interface is to be Config...\Interfaces...
Page 477: Real-Time
22.3 Real-Time 22.3.1 Overview Description The real-time interface allows real-time related parameters to be configured. This includes defining if the receiver should work as a reference or a rover and the real-time messages to be used. Up to two real-time interfaces can be configured on the receiver. Access Select Main Menu: Config...\Interfaces..
Page 478 IF the real-time THEN interface is for use with both Refer to "22.3.5 Configuration with Digital Cellular Phone and digital cellular phone Radio". and radio Config...\Interfaces... - General GPS1200+...
Page 479: Configuration Without Real-Time Interface
22.3.2 Configuration without Real-Time Interface Access Refer to "22.3.1 Overview" to access CONFIGURE Real-Time Mode. CONFIGURE <R-Time Mode: None> means the receiver is not to be used as a real-time reference or as Real-Time Mode a real-time rover. Next step IF a Space-Based Augmentation System THEN needs to be configured SHIFT SBAS (F5) to access CONFIGURE...
Page 480: Configuration Of A Reference Real-Time Interface
22.3.3 Configuration of a Reference Real-Time Interface Access Refer to "22.3.1 Overview" to access CONFIGURE Real-Time Mode. CONFIGURE The available fields and keys on this screen depend on the selected settings. Real-Time Mode CONT (F1) To accept changes and return to the screen from where this screen was accessed.
Page 481 <R-Time Data: Reference> activates a reference Mode:> or Rover real-time interface. <R-Time Leica The proprietary Leica real-time GPS data format Data:> supporting GPS L1/L2 and GLONASS L1/ L2. This is recommended when working exclusively with Leica receivers. Leica 4G The proprietary Leica real-time GNSS data format supporting GPS L1/ L2/ L5, GLONASS L1/ L2 and Galileo E1/E5a/E5b/Alt-BOC.
Page 482 Field Option Description CMR and CMR+ are compacted formats used to CMR+ broadcast data for third party receivers. RTCM v3.1 Use RTCM when rover units from a different manu- facturer are to be used. Message according to RTCM version 3. A new standard format for transmission of Global Navigation Satellite System correction information.
Page 483 Field Option Description • 1010: Extended L1-only GLONASS real-time observables • 1011: L1 & L2 GLONASS real-time observables • 1012: Extended L1 & L2 GLONASS real-time observables Network RTK Messages according to Master- Auxiliary Concept: • 1014: Network Auxiliary Station Data message. This message contains details of the reference stations in the network, for example the master station and its coordinates, and the coordinate...
Page 484 Field Option Description • For L1 and L2: 1 - 5 cm rms after a successful ambiguity resolution. RTCM 1,2 v2 Message according to RTCM version 2.x. Differential and delta differential GPS corrections. Message 3 is also generated. Use for DGPS applications. Accu- racy at the rover: 0.25 - 1 m rms.
Page 485 Field Option Description RTCM Message according to RTCM version 2.x. Combina- 1,2,20,21 v2 tion of RTCM 1,2 v2 and RTCM 20,21 v2. <Port:> Bluetooth x Available for RX1250. The Bluetooth port which will be used for the interface functionality. Clip-on Available for RX1250.
Page 486 CONFIGURE Additional Reference Options, General page CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Ref Stn ID:> User input An identification for a reference station.
Page 487 From 0 to 1023 For <RTCM Version: 1.x> and <RTCM Version: 2.x>. From 0 to 4095 For <R-Time Data: Leica 4G> and <R-Time Data: RTCM v3.1> in CONFIGURE Real-Time Mode. <Time Yes or No The possibility to send real-time messages delayed.
Page 488 Field Option Description <RTCM 2.1, 2.2 or 2.3 Available for <R-Time Data: RTCM XX v2> in Version:> CONFIGURE Real-Time Mode. The same version must be used at the reference and the rover. Next step PAGE (F6) changes to the NTRIP page. CONFIGURE Additional Reference Options,...
Page 489 Field Option Description <Password:> User input A password for authentication is required to send data to the NTRIP Caster. Contact the NTRIP admin- istrator for information. <Mountpnt:> User input Identifies from where data is streamed to the NTRIP Caster. Next step Step Description CONT (F1) closes the screen and returns to CONFIGURE Real-Time Mode.
Page 490 Field Option Description <Coords:> From 10s to 120s Rate for the transmission of reference coordinates. <Messages:> Choicelist Available for <RTCM Version: 2.3> in CONFIGURE Additional Reference Options, General page. The messages sent within the coordinate message. <Info:> From 10s to 120s Rate for the transmission of reference station infor- mation such as point ID.
Page 491 Next step IF changes for the first THEN real-time interface are not to be made CONT (F1) accepts the changes, closes the screen and returns to the screen from where CONFIGURE Real-Time Mode was accessed. The second real-time interfaces is added to the list in CONFIGURE Interfaces.
Page 492: Configuration Of A Rover Real-Time Interface
22.3.4 Configuration of a Rover Real-Time Interface Access Refer to "22.3.1 Overview" to access CONFIGURE Real-Time Mode. CONFIGURE The available fields and keys on this screen depend on the selected settings. Real-Time Mode CONT (F1) To accept changes and return to the screen from where this screen was accessed.
Page 493 SHIFT PARA (F3) To activate and deactivate the prediction of real-time observations between the data rate of the reference. Refer to paragraph "Prediction" for information on prediction. Available unless <R-Time Data: RTCM 1,2 v2> or <R-Time Data: RTCM 9,2 v2>. Define if GLONASS observations are fixed or not in an RTK solution or wether the sensor automatically decides (only GLONASS...
Page 494 <R-Time Data: Rover> activates a rover real-time Mode:> or Rover interface. <R-Time Leica Refer to "22.3.3 Configuration of a Reference Real- Data:> Leica 4G Time Interface" for information about these real-time CMR/CMR+ data formats. RTCM v3.1 RTCM 1,2 v2 RTCM 9,2 v2 RTCM 18,19 v2...
Page 495 Field Option Description Automatic SBAS, Wide Area Augmentation System EGNOS, WAAS, European Geostationary Navigation Overlay Service MSAS, EGNOS MTSAT Satellite-based Augmentation System where (Test), WAAS MTSAT stands for Multi-functional Transport SATel- (Test) or GAGAN lite GPS Aided Geo Augmentation Navigation. <Port:>...
Page 496 The real-time data formats Leica, Leica 4G, CMR, CMR+ and RTCM v3.1 contain this information. This is mainly important when a System300 receiver or a receiver from a different manufacturer is used as reference.
Page 497 Next step IF additional rover THEN options are not to be config- CONT (F1) closes the screen and returns to the screen from where ured CONFIGURE Real-Time Mode was accessed. are to be configured ROVER (F2). Refer to paragraph "CONFIGURE Additional Rover Options, General page".
Page 498 ID of the reference station from which real-time data is to be received. The allowed minimum and maximum values vary. From 0 to 31 For <R-Time Data: Leica> and <R-Time Data: CMR/CMR+>. From 0 to 1023 For <RTCM Version: 1.x> and <RTCM Version: 2.x>.
Page 499 The corrections are also individualsied by LEICA GNSS Spider, which means it determines the best suitable corrections for that rover. The corrections are sent in Leica, RTCM v2.3 or RTCM v3.1 with message types 1015/1016. Config...\Interfaces... - General...
Page 500 GGA Message Sending for Reference Network Applications". Master-AuXiliary corrections The rover typically does not send its position to LEICA GNSS Spider. LEICA GNSS Spider calculates and sends Master-Auxiliary corrections to the rover. The rover individualises the corrections for its position, which means it determines the best suitable correc- tions.
Page 501 <User ID 1:> User input Available for <Send User ID: Yes>. and <User ID The specific user ID’s to be sent as part of the Leica 2:> proprietary NMEA message. By default the serial number of the instrument is displayed.
Page 502 CONFIGURE Additional Rover Options, CONT (F1) NTRIP page To accept changes and return to the screen from where this screen was accessed. SRCE (F5) To download the NTRIP source table if <Mountpnt:> is unknown. To do this, the GPRS Internet interface must already be configured.
Page 503 Field Option Description <Mountpnt:> User input The NTRIP Source from where real-time data is required. Next step PAGE (F6) changes to the RTCM Options page. This page is only available for <R-Time Data: RTCM v3.1> in CONFIGURE Real-Time Mode. CONFIGURE Additional Rover Options, RTCM Options page...
Page 504 Description of fields Field Option Description <Use Auto CrdSys:> Yes or No To set a RTCM coordinate system received by a reference network as active coordinate system. Is marked grey and set to No for <Ref Network: None> in CONFIGURE Addi- tional Rover Options, General page.
Page 505 Step Description CONT (F1) returns to the screen from where CONFIGURE Real-Time Mode was accessed. Prediction The following provides additional information on the prediction of real-time positions between the data rate of the reference. This can be activated for a real-time rover interface unless <R- Time Data: RTCM 1,2 v2>...
Page 506 Access SHIFT FILT (F4) in CONFIGURE Real-Time Mode. Description Height smoothing is a filter applied to all heights measured in the WGS 1984 or a local coor- dinate system or output via NMEA. The filter defaults are best suited for high dynamic vari- ations in height up to 1 m/s as carried out by graders.
Page 507 Position determination with satellites Height determination with satellites appearing in all four quadrants. appearing in two quadrants. In high dynamic GPS operations, this fact results in height variations of a few centimetres as shown in the blue curve in the diagram below. Some GPS monitoring applications require a stabilised height.
Page 508: Configuration With Digital Cellular Phone And Radio
22.3.5 Configuration with Digital Cellular Phone and Radio Description An ideal real-time setup is to combine a radio and a digital cellular phone to get the best of both technologies. The radio can be used where the radio signals can be received, the advantage being that the radio data transmission is free.
Page 509: Configuration Of Sbas
22.3.6 Configuration of SBAS Description Allows a Space-Based Augmentation System to be configured to provide additional correc- tions in conjunction with GPS signals. Also commonly referred to as Satellite-Based Augmentation System, SBAS provides corrected time and distance measurements calcu- lated by a network of ground relay stations and geostatic satellites. A SBAS can correct for problems such as atmospheric delays, poor satellite geometry and incorrect satellite posi- tioning.
Page 510 Description of fields Field Option Description <SBAS The Space-Based Augmentation System to use. Tracking:> The options available for <R-Time Data:> in CONFIGURE Real-Time Mode depend on the selec- tion made here. Automatic SBAS SBAS satellites will be tracked and the SBAS service used will be automatically selected.
Page 511 Next step Step Description CONT (F1) returns to CONFIGURE Real-Time Mode. CONT (F1) returns to the screen from where CONFIGURE Real-Time Mode was accessed. Config...\Interfaces... - General GPS1200+...
Page 512: Configuration Of Gga Message Sending For Reference Network Applications
22.3.7 Configuration of GGA Message Sending for Reference Network Appli- cations Description Most reference networks require an approximate position of the rover. For reference network applications, a rover dials into the reference network and submits its approximate position in form of a NMEA GGA message. By default, the receiver sends GGA messages with updated current positions automatically when a reference network is selected.
Page 513 CONFIGURE CONT (F1) Send GGA NMEA To accept changes and return to the screen from where this screen was accessed. COORD (F2) Available for <GGA Position: From Job> and <GGA Position: LAST/HERE Posn>. To view other coordinate types. Local coordinates are available when a local coordinate system is active.
Page 514 Description of fields Field Option Description <GGA Posi- Automatic The current rover position is sent to the reference tion:> network. The position is updated and sent every five seconds. From Job A point from the active job can be selected in <Point ID:>.
Page 515 Step Description CONT (F1) returns to the screen from where CONFIGURE Real-Time Mode was accessed. Config...\Interfaces... - General GPS1200+...
Page 516: Ascii Input
22.4 ASCII Input 22.4.1 Overview Description The ASCII Input interface receives ASCII messages from third party devices such as depth sounders, barometers, digital cameras, pipe detectors, Geiger counters, etc. The ASCII messages are stored as point annotations together with the next manually occupied point and/or auto point.
Page 517: Configuration Of An Ascii Input Interface
22.4.2 Configuration of an ASCII Input Interface Access Refer to "22.4.1 Overview" to access CONFIGURE ASCII Input. CONFIGURE ASCII Input CONT (F1) To accept changes and return to the screen from where this screen was accessed. ANNOT (F2) To configure which ASCII messages to record to which annotation.
Page 518 Field Option Description NETx Available for an activated Internet interface. If these ports are not assigned to a specific interface, then these ports are additional remote ports. Port x The physical port P1, P2 or P3 on the instrument to which the device is attached.
Page 519: Configuration Of Annotations
22.4.3 Configuration of Annotations Configuration of anno- Step Description tations step-by-step Refer to "22.4.1 Overview" to access CONFIGURE ASCII Input. ANNOT (F2) to access CONFIGURE Annotations to be Used. CONFIGURE Annotations to be Used <Annotation:> The annotation to which the ASCII message is to be stored. <Accept ASCII:>...
Page 520 Step Description Any characters to accept strings that include the characters at any position. For example 1 accepts 1234, 4321 or 2134 but not 2345. <Use Prefix:> Stores the description in <Message Desc:> as prefix to the ASCII message. This helps to more easily identify the annotations registered with a point. <Send Reply:>...
Page 521: Configuration Of A Command To The Device
22.4.4 Configuration of a Command to the Device Configuration of Step Description command step-by-step Refer to "22.4.1 Overview" to access CONFIGURE ASCII Input. SHIFT CMND (F5) CONFIGURE Send Command to Device <Command:> A message to be sent to the device through the configured port when the survey or stakeout application program is accessed.
Page 522: Working Example 1
22.4.5 Working Example 1 Description Application: Survey on a small lake. Recording the depth with the survey points. Working technique: Using a depth sounder to measure the depth of the lake at certain locations. Goal: The depth sounder constantly streams data at a rate of 1 Hz and sends the depth it has measured to the GPS1200+ receiver in the format: 27.234<CR>...
Page 523 Step Description CONFIGURE ASCII Input <Use Device: Yes> <Port:> Select the port to which the depth sounder is connected. <End of Msg: CR> ANNOT (F2) CONFIGURE Annotations to be Used <Annotation: Annotation 1> <Accept ASCII: Yes> <Message Desc: Depth Sounder> <Message ID: ----->...
Page 524 Field procedure step- Step Description by-step The coordinates of points can be measured over the lake with the depth of the lake at that point recorded as an annotation. Refer to "45 Survey - General" for infor- mation on how to run a survey. Because the depth sounder is streaming data, the depth measurement that is stored with the point is the last measurement received by the receiver before the point is stored.
Page 525: Working Example 2
22.4.6 Working Example 2 Description Application: Survey on contaminated waste land. Recording four different levels of different gasses with the surveyed points. Working technique: Using a gas analyser to measure the levels of gasses at various locations. Goal: The gas analyser outputs the results as an ASCII message and sends the four different levels it has measured to the GPS1200+ receiver in the format: GS1 2.786<CR/LF>...
Page 526 Requirements The port and the device to be used for the gas analyser is configured correctly. The device will most likely be RS232 using the same parameters as the depth sounder. Refer to "23.2 Accessing CONFIGURE Devices / CONFIGURE GPRS Internet Devices". Configuration of ASCII Step Description...
Page 527 Step Description <Message ID: GS2> <Use Prefix: None> <Send Reply: No> Repeat step 5. accordingly for <Annotation: Annotation 3> and <Annotation: Annotation 4>. CONT (F1) closes the screen and returns to CONFIGURE ASCII Input. CONT (F1) returns to the screen from where CONFIGURE ASCII Input was accessed.
Page 528: Nmea Out
22.5 NMEA Out Description National Marine Electronics Association has developed a message standard related to the marine electronics industry. NMEA messages have been accepted as the standard for sharing specific data information between companies since the late 1970s. Refer to "Appendix F NMEA Message Formats"...
Page 529 CONFIGURE CONT (F1) NMEA Output To accept changes and return to the screen from where this screen was accessed. MESGS (F2) To configure what NMEA messages are output, the rates and the output timing method. Refer to paragraph "CONFIGURE NMEA Messages".
Page 530 Field Option Description <Device:> Output Usually, RS232 is used to transfer NMEA messages. <NMEA Standard or User The NMEA Talker ID based on the NMEA standards Mode:> defined v3.0 or user defined input. <Talker ID:> User input Available for <NMEA Mode: User defined>. Appears at the beginning of each NMEA message.
Page 531 CONFIGURE This screen shows the messages that can be output, which messages are currently output, NMEA Messages the output rates and the output timing method. CONT (F1) To accept changes and return to the screen from where this screen was accessed. EDIT (F3) To configure how the currently highlighted message is output.
Page 532 CONFIGURE Message to Send CONT (F1) To accept changes and return to the screen from where this screen was accessed. Description of fields Field Option Description <Output:> At Epoch The NMEA message is created at the exact epoch as defined in <Position and Screen Update:> in CONFIGURE Display Settings.
Page 533 Field Option Description If the time interval as defined in <Rate:> is shorter than the epochs as defined in <Posi- tion and Screen Update:> in CONFIGURE Display Settings, then the internal computa- tion of positions is changed to allow the speci- fied rate of NMEA positions.
Page 534 Field Option Description All Points The NMEA message is sent when any type of point is stored. Occupy Pts Only The NMEA message is sent when a manually occu- pied point is stored. Auto Pts Only The NMEA message is sent when auto points are stored.
Page 535 Step Description CONT (F1) returns to the screen from where CONFIGURE NMEA Messages was accessed. Diagram For <Output: At Epoch> with <Rate: 1.0s> and <Position and Screen Update: 1.0s> Data 1 available NMEA message for data 1 composed NMEA message for data 1 sent Data 2 available NMEA message for data 2 composed NMEA message for data 2 sent...
Page 536: Export Job
The Export Job interface allows data from a job to be exported from the receiver to an instru- ment such as Leica TPS400/700. Refer to "16.4 Exporting Data from a Job to another Device" for information on how to export data via RS232.
Page 537 Description of fields Field Option Description <Use Device:> Yes or No Activates the interface. <Port:> Bluetooth x Available for RX1250. The Bluetooth port which will be used for the interface functionality. NETx Available for an activated Internet interface. If these ports are not assigned to a specific interface, then these ports are additional remote ports.
Page 538 Next step CONT (F1) returns to the screen from where CONFIGURE Export Job Interface was accessed. Config...\Interfaces... - General GPS1200+...
Page 539: Hidden Point
22.7 Hidden Point Description Hidden point measurement devices are used for measuring to points which cannot be directly measured with GPS, for example house corners or trees. The measurements made with a hidden point measurement device are directly transferred to the receiver for the calcu- lation of the coordinates of the hidden point.
Page 540 CONFIGURE Depending on the method of access, the name of the screen varies. Hidden Point Measure- CONT (F1) ments To accept changes and return to the screen from where this screen was accessed. OFSET (F2) To configure the heighting and external angle offsets.
Page 541 Field Option Description <Est Ht Qlty:> User input Available for <Compute Ht: Yes>. The estimated value for the height quality assigned to all hidden points. <Use Device:> Yes or No Activates the hidden point interface. For <Use Device: No>, the measured values must be entered manually.
Page 542 CONFIGURE Hidden Pt Device Offsets CONT (F1) To accept changes and to return to CONFIGURE Hidden Point Measurements. Description of fields Field Option Description <Height Available for <Compute Ht: Yes> in CONFIGURE Offset:> Hidden Point Measurements. None No height offsets are used. The result is the delta height between the centre of the device and the aimed point.
Page 543 Field Option Description Device & Trgt Ht When measuring hidden points, the height of the hidden point measurement device as well as the target height can be typed in. This option should be used when the hidden point cannot be directly meas- ured with a hidden point device but a target point can be used to calculated the position of the hidden point.
Page 544 Field Option Description Permanent Applies a default value for the offset angle. The value is changeable. New for Each Pt Offset angle values must be entered for each new hidden point. <Offset:> User input Available for <EAO Method: Permanent>. The default value for the offset angle. Next step Step Description...
Page 545 Diagram P0 Known point P1 Target point P2 Hidden point Height of P0 Height of P2 = a + d1 + d4 - d3 Device height: height of hidden point meas- urement device above P0 Slope distance Device height: height of P1 above P2 Height difference between hidden point measurement device and P1 Horizontal distance...
Page 546 Distance offsets at A Leica Disto is shown as an example. hidden point measure- ment devices Negative <Dist Offset:> Positive <Dist Offset:> Pole Disto P0 Hidden point GPS12_039 Config...\Interfaces... - General GPS1200+...
Page 547: Tilt
22.8 Tilt Description Tilt devices are used for measuring inclinations. The data from the tilt device is logged together with the GPS raw observations. PC based software can convert the tilt data to a readable ASCII format, e.g. RINEX. In addition, a binary notification message can be output through ports P1, P2, P3, RX or NET to controlling application software.
Page 548 CONFIGURE CONT (F1) Tilt Measurement To accept changes and return to the screen from where this screen was accessed. NPORT (F4) Available for <Notify Msg: Binary>. To configure the port and the device through which the notification message shall be trans- mitted.
Page 549 <Notify Msg:> None or Binary Activates the output of a binary notification message. The format is LB2 v2. Documentation for LB2 is avail- able on request from the Leica Geosystems repre- sentative. Next step IF port and device for a...
Page 550 CONFIGURE Choose Notification Port CONT (F1) To accept changes and return to the screen from where this screen was accessed. DEVCE (F5) Available unless <Port: NETx>. To create, select, edit or delete a device. Refer to "23.2 Accessing CONFIGURE Devices / CONFIGURE GPRS Internet Devices".
Page 551: Meteo
22.9 Meteo Description Meteo devices are used for measuring air pressure, temperature and relative humidity. The data from the meteo device is logged together with the GPS raw observations. PC based software can convert the meteo data to a readable ASCII format, e.g. RINEX. In addition, a binary notification message can directly be output through ports P1, P2, P3, RX or NET to controlling application software.
Page 552: Smartantenna
Automatic connection automatically Establishing a connection is initiated automatically upon switching on RX1250. double clicking the icon on Windows CE desktop to display the Leica SmartWorx software. Requirements The SmartAntenna interface is configured such that SmartAntenna is being used via Bluetooth.
Page 553 Access Select Main Menu: Config...\Interfaces..Highlight SmartAntenna. EDIT (F3). CONFIGURE CONT (F1) SmartAntenna Interface To accept changes and return to the screen from where this screen was accessed. To establish a connection to the Smart- Antenna. SRCH (F4) Available for <Use Device: Yes>. To search for all available SmartAntenna’s.
Page 554 Field Option Description <Device:> Output The device that is currently configured to <Port:>. <Bluetooth x> The Bluetooth device inside the RX1250 that is currently configured to <Port:>. <ID Address:> Output The ID address of the SmartAntenna to be used. Next step CONT (F1) returns to the screen from where CONFIGURE SmartAntenna Interface was accessed.
Page 555: Internet
22.11 Internet Description The Internet interface • allows accessing the Internet using a GPS1200+ receiver plus normally a GPRS device. • can be used together with the Real-Time interface to receive real-time data from a NTRIP Caster via Internet communication. Refer to "35.1 Overview"...
Page 556 CONFIGURE Internet Interface CONT (F1) To accept changes and return to the screen from where this screen was accessed. DEVCE (F5) To create, select, edit or delete a device. Refer to "23.2 Accessing CONFIGURE Devices / CONFIGURE GPRS Internet Devices". Description of fields Field Option...
Page 557 Field Option Description Dynamic The IP address to get access to the Internet is provided by the network provider dynamically. Each time a GPS1200+ receiver wants to access the Internet via the device a new IP address is assigned to the receiver. When using GPRS to connect to the Internet then the network provider always dynami- cally assigns the IP address.
Page 558 Field Option Description <Password:> User input Some providers ask for a password to allow connecting to the Internet via GPRS. Contact your provider if a password is required. Next step CONT (F1) returns to the screen from where CONFIGURE Internet Interface was accessed.
Page 559: Pps Output
22.12 PPS Output The PPS output is an optional interface requiring a special port. Description PPS stands for Pulse Per Second. It is a pulse that is output at a specified interval time. This can be used to activate another device. Additionally, a notification message can be output through ports P1, P2, P3 or RX when a PPS output occurs.
Page 560 CONFIGURE PPS Output CONT (F1) To accept changes and return to the screen from where this screen was accessed. NPORT (F4) Available unless <Notify Msg: None>. To configure the port and the device through which the notification message shall be trans- mitted.
Page 561 Field Option Description Yes or No Activates the observation of the time accuracy limit within which pulses shall be generated. <Limit:> User input Available for <Limit Error: Yes>. The time accuracy limit in nanoseconds. <Notify Msg:> None, Binary or Activates the output of a notification message with ASCII each PPS output.
Page 562: Event Input
22.13 Event Input The event input is an optional interface requiring a special port. Description The event input interface allows pulses which are sent from devices connected to the receiver to be recorded. These records can later be superimposed on the processed kine- matic data and the positions where the events took place can be interpolated in LGO.
Page 563 CONT (F1) To accept changes and return to the screen from where this screen was accessed. NPORT (F4) To configure the port and the device through which the notification message shall be trans- mitted. Refer to "22.16 Remote". Description of fields Field Option Description...
Page 564 Field Option Description <Time Guard:> User input If two or more events take place during the time defined in s, the first event will be recorded. Enter 0 to accept all events. The shortest recording time is 0.05 s. <Notify Msg:> None, Binary or Activates the output of a notification message with ASCII each event input.
Page 565: External Oscillator
22.14 External Oscillator The external oscillator option is available on the GRX1200+ and GRX1200+ GNSS. Description An external oscillator can be used to provide a better quality time signal to the GRX1200+/GRX1200+ GNSS than the internal clock, for example, through the use of a rubidium or caesium oscillator.
Page 566 CONFIGURE External Oscillator CONT (F1) To accept changes and return to the screen from where this screen was accessed. Description of fields Field Option Description <Use Device:> The type of external oscillator to use. An external oscillator is not been used. All other fields become unavailable.
Page 567 Field Option Description User Allows noise elements to be defined for a customised external oscillator. The noise elements are used to describe the frequency noise characteristics of the oscillator. The noise elements are a value with a number part and an exponential part, for example, 1.0167e <Frequency:>...
Page 568: Ascii Remote
GX1200+ at a PC. For requesting ASCII Data a Outside World Interface or Leica Binary 2 command is used. Documentation for OWI and LB2 is available on request from the Leica Geosystems repre- sentative.
Page 569 CONFIGURE ASCII Remote CONT (F1) To accept changes and return to the screen from where this screen was accessed. DEVCE (F5) To create, select, edit or delete a device. Refer to "23.2 Accessing CONFIGURE Devices / CONFIGURE GPRS Internet Devices". Description of fields Field Option...
Page 570 Activates the output of a notification message. The Binary format is OWI or LB2 v2. Documentation for OWI and LB2 is available on request from the Leica Geosys- tems representative. Next step CONT (F1) returns to the screen from where CONFIGURE ASCII Remote was accessed.
Page 571: Remote
RX1200, e.g. a PC. Outside World Interface or Leica Binary 2 commands can be used to control the receiver through the remote port. Documentation for OWI and LB2 is available on request from the Leica Geosystems representative.
Page 572 Access Select Main Menu: Config...\Interfaces..Highlight Remote. EDIT (F3). CONFIGURE Remote Interfaces CONT (F1) To accept changes and return to the screen from where this screen was accessed. CTRL (F4) To configure additional parameters. Refer to "24 Config...\Interfaces... - Controlling Devices".
Page 573 Column Description Device The hardware connected to the chosen port. Next step CONT (F1) returns to the screen from where CONFIGURE Remote Interfaces was accessed. Config...\Interfaces... - General GPS1200+...
Page 574: Configuration Of Devices
Configuration of Devices 23.1 Devices 23.1.1 Overview Description A device is the hardware which is connected to a chosen port of GPS1200+. Devices are used to transmit and receive real-time data and to communicate with the receiver, for example to download raw observations from a remote location. Before using any device it is necessary to configure the interface with which it will be used.
Page 575: Digital Cellular Phones
23.1.2 Digital Cellular Phones Description Digital cellular phones comprise of the technologies CDMA and GSM with its subgroup GPRS. Typical uses • To transmit real-time data. • To download raw observations from a remote location. • To receive real-time data. •...
Page 576 Sometimes required: • SIM card. This is the same SIM card as normally used in mobile phones. The SIM card must be enabled to transmit data. Contact the service provider to enable the SIM card. • Personal Identification Number • Registration Supported digital Default digital cellular phones fitting into a clip-on-housing...
Page 577 • Siemens M75 • SonyEricssonT610 User defined digital cellular phones Other digital cellular phones than those listed above can be used. Their settings must be defined by creating a new digital cellular phone configuration. Refer to "23.3 Creating a New Device".
Page 578: Modems
23.1.3 Modems Typical uses • To transmit NMEA messages. • To download raw observations from a remote location. • To transmit real-time data • Example of use Step Description The reference is equipped with a modem. The rover is equipped with a digital cellular phone. Ensure that the modem is switched on.
Page 579 Supported modems Default modems • AirLink CDMA • U.S. Robotics 56K Modems must be connected with a cable. Refer to "Appendix E Cables" for information on cables. User defined modems Other modems than those listed above can be used. Their settings must be defined by creating a new modem configuration.
Page 580: Radios
23.1.4 Radios Typical uses • To transmit real-time data. • To download raw observations from a remote loca- tion. • To receive real-time data. • To steer a receiver. Example of use Step Description Reference and rover must both be equipped with radios using the same frequency range and the same data format.
Page 581 Default radios not fitting into a clip-on-housing These radios must be connected with a cable. Refer to "Appendix E Cables" for information on cables. • AT-RXM500, Akasaka Tech • Satelline 2ASx • Pacific Crest RFM96W • Satelline 2ASxE User defined radios Other radios than those listed above can be used.
Page 582: Rs232
23.1.5 RS232 Typical uses To exchange information with a device via an RS232 interface, for example sending NMEA messages to a computer. Port P1, P2, P3 and the RX port of the receiver are standard RS232 interfaces. The device is always connected with a cable. Refer to "Appendix E Cables"...
Page 583: Smartgate
SMARTgate is a device with an integrated digital cellular phone, a radio and the functionality of a SAPOS-Box, available in a Leica radio housing. The SAtellite POSitioning service is a reference station service available in Germany. Refer to www.navsys.de for more informa- tion about the SMARTgate device.
Page 584: Hidden Point Measurement Devices
23.1.7 Hidden Point Measurement Devices Typical uses To measure • distances, using laser technology • angles • azimuths to points which are not directly accessible by means of GPS, for example house corners or trees. The measurements taken with hidden point measurement devices are directly trans- ferred if the device is connected to the receiver.
Page 585 Leica Disto memo • Leica Laser Locator • Leica Disto pro • Leica Laser Locator Plus • Leica Disto • Leica Vector User defined hidden point measurement devices Other hidden point measurement devices than those listed above can be used. Their settings must be defined by creating a new hidden point measurement device.
Page 586: Gprs / Internet Devices
23.1.8 GPRS / Internet Devices Description GPRS is a telecommunication standard for transmitting data packages using the Internet Protocol. When using GPRS technology charges are made based on the amount of transferred data and not as for normal digital cellular phones where charges are made for the connection time.
Page 587 • Registration Supported GPRS / Default GPRS / Internet devices fitting into a clip-on-housing Internet devices • Siemens MC75 User defined GPRS / Internet devices Other GPRS capable devices than those listed above can be used as long as they use AT commands.
Page 588: Accessing Configure Devices / Configure Gprs Internet Devices
23.2 Accessing CONFIGURE Devices / CONFIGURE GPRS Internet De- vices Description Allows devices to be created, edited, selected and deleted. Refer to "24 Config...\Interfaces... - Controlling Devices" for more information about configuring devices. Access step-by-step Step Description Main Menu: Config...\Interfaces... Highlight the appropriate interface based on the type of device that needs to be configured.
Page 589 CONT (F1) To select the highlighted device and return to the screen from where this screen was accessed. NEW (F2) To create a new device. Refer to "23.3 Creating a New Device". EDIT (F3) To edit the highlighted device. Refer to "23.4 Editing a Device".
Page 590 Description of columns Column Description Name Names of available devices. Type Type of device defined when creating the device. Creator The creator of the device. The creator can either be Default if the device is a default, or User if the device has been created. If a Default device is edited by using EDIT (F3) then its creator is still displayed as Default.
Page 591: Creating A New Device
23.3 Creating a New Device Description Allows a new device to be configured. Access step-by-step Step Description Refer to "23.2 Accessing CONFIGURE Devices / CONFIGURE GPRS Internet Devices" to access CONFIGURE Devices / CONFIGURE GPRS Internet Devices. Highlight a device of the same type as the device to be created, from the list. NEW (F2) to access CONFIGURE New Device.
Page 592 Description of fields Field Option Description <Name:> User input Name of new device. <Type:> Output Same device type as was highlighted when NEW (F2) was used. <GPRS/ Yes or No Available for digital cellular phones and modems. Internet:> Defines the device as an Internet capable device and adds it to the list in CONFIGURE GPRS Internet Devices.
Page 593 Field Option Description <Flow None or RTS/CTS Activates hardware handshake. Control:> When the receiver/device is ready for data, it asserts the Ready To Send line indicating it is ready to receive data. This is read by the sender at the Clear To Send input, indicating it is clear to send the data.
Page 594 Description of fields Field Option Description <Init 1:> User input Initilisation sequence to initilise digital cellular phone/modem. <(cont):> User input Allows the <Init X:> or the <Connect:> string to continue onto a new line. <Init 2:> User input Initilisation sequence to initilise digital cellular phone/modem.
Page 595: Editing A Device
23.4 Editing a Device Access step-by-step Step Description Refer to "23.2 Accessing CONFIGURE Devices / CONFIGURE GPRS Internet Devices" to access CONFIGURE Devices / CONFIGURE GPRS Internet Device. Highlight the device to be edited from the list. EDIT (F3) to access CONFIGURE Edit Device. CONFIGURE The availability of options may change depending on the selected device.
Page 596: Config
Config...\Interfaces... - Controlling Devices 24.1 Digital Cellular Phones 24.1.1 Overview Description For digital cellular phones, information such as • the reference stations that can be contacted • the phone numbers of the reference stations and • the type of protocol to be used can be defined.
Page 597 Global System for Mobile Communications is a more efficient version of CDMA technology that uses smaller time slots but faster data transfer rates. It is the world’s most commonly used digital network. Next step IF using a digital THEN cellular phone of technology Refer to "24.1.2 Configuring a GSM Connection".
Page 598: Configuring A Gsm Connection
Some GSM’s ask for the iden- tification number of the Bluetooth. The identification number of Leica’s Bluetooth is 0000. The field is unavailable for RX1250 with SmartAntenna. <ID Address:> Available for <Bluetooth: Yes>. The ID address of the Bluetooth device to be used.
Page 599 Step Description Refer to chapter <Station:> The digital cellular phone reference station to be dialled. 24.10 Opening the choicelist accesses CONFIGURE Stations to Dial where new reference stations can be created and existing reference stations can be selected or edited. <Number:>...
Page 600 Step Description Refer to chapter NEAR (F2) finds the nearest reference station with a digital cellular 24.10 phone of GSM technology. Available when reference stations to dial are already created in CONFIGURE Stations to Dial. Coordinates of these stations must be known. CODES (F3) accesses CONFIGURE GSM Codes to enter the Personal Identification Number of the SIM card.
Page 601: Configuring A Cdma Connection
24.1.3 Configuring a CDMA Connection Configure CDMA The following table explains the most common settings. Refer to the stated chapter for more connection step-by- information on screens. step Step Description Refer to chapter Refer to "22.2 Accessing Configuration Interfaces" to access CONFIGURE Interfaces.
Page 602 Step Description Refer to chapter NEAR (F2) finds the nearest reference station with a digital cellular 24.10 phone of CDMA technology. Available when reference stations to dial are already created in CONFIGURE Stations to Dial. Coordinates of these stations must be known. CONT (F1) returns to CONFIGURE CDMA Connection.
Page 603 Step Description Refer to chapter <My Phone No:> Type in the mobile directory number provided by the network provider. CLEAR (F5) deletes the input of the highlighted field. CONT (F1) returns to CONFIGURE Interfaces. Config...\Interfaces... - Controlling Devices GPS1200+...
Page 604: Modems
24.2 Modems Description For modems, information such as • the reference stations that can contacted and • the phone numbers of the reference stations can be controlled. Changing the reference station to be dialled is of interest in two cases. Case 1: Two real-time reference stations, each equipped with a digital cellular phone, are set up at two locations belonging to different network providers.
Page 605 Step Description Refer to chapter CONFIGURE Modem Connection <Modem Type:> The type of modem highlighted when CONFIGURE Modem Connection was accessed. <Station:> The modem reference station to be dialled. Accesses 24.10 CONFIGURE Stations to Dial where new reference stations can be created and existing reference stations can be selected or edited.
Page 606: Radios
24.3 Radios Description For radios the channels on which the radio broadcasts can be changed. Changing channels changes the frequency at which the radio operates. The following radios support channel changing: • AT-RXM500 • Satelline 2Asx • Pacific Crest PDL •...
Page 607 Channel changing may contravene radio broadcasting regulations in certain countries. Before operating with radios, check the regulations in force in the working area. The number of channels available and the frequency spacing between channels depends on the radio used. If channel changing is to be used, when configuring the reference real-time interface, set <Ref Stn ID:>...
Page 608 Step Description Refer to chapter <Channel:> The radio channel. The channel used must be within minimum and maximum allowed input values. The minimum and maximum allowed input values for a radio depend on the number of channels supported by the radio and the spacing between the chan- nels.
Page 609 <Bluetooth:> GPS1200+ receivers detect automatically if the attached devices is bluetooth capable. Some devices ask for the identification number of the Bluetooth. The identification number of Leica’s Bluetooth is 0000. The field is unavailable for RX1250 with SmartAntenna. Config...\Interfaces... - Controlling Devices...
Page 610 Step Description Refer to chapter <ID Address:> Available for <Bluetooth: Yes>. The ID address of the Bluetooth device to be used. Refer to the device’s user manual for information about the ID address. SRCH (F4) available for <Bluetooth: Yes>, to search for all available Bluetooth devices.
Page 611: Smartgate Boxes
24.5 SMARTgate Boxes Description SMARTgate boxes contain GSM and radio devices with the integrated functionality of a SAPOS box. For SMARTgate boxes, one channel corresponds to one out off several partic- ular frequencies configured on the radio. Changing channels changes the frequency at which the radio operates.
Page 612 Configure SMARTgate The following table explains the most common settings. Refer to the stated chapter for more connection step-by- information on screens. step Step Description Refer to chapter Refer to "22.2 Accessing Configuration Interfaces" to access CONFIGURE Interfaces. In CONFIGURE Interfaces highlight an interface which has a SMARTgate box attached.
Page 613: Hidden Point Measurement Devices
<Bluetooth:> GPS1200+ receivers detect automatically if the attached devices is bluetooth capable. Some devices ask for the identification number of the Bluetooth. The identification number of Leica’s Bluetooth is 0000. The field is unavailable for RX1250 with SmartAntenna. Config...\Interfaces... - Controlling Devices...
Page 614 Step Description Refer to chapter <ID Address:> Available for <Bluetooth: Yes>. The ID address of the Bluetooth device to be used. Refer to the device’s user manual for information about the ID address. SRCH (F4) available for <Bluetooth: Yes>, to search for all available Bluetooth devices.
Page 615: Gprs / Internet Devices
24.7 GPRS / Internet Devices Description GPRS / Internet devices can be used to access the Internet from a GPS1200+ receiver. Configure Internet The following table explains the most common settings. Refer to the stated chapter for more connection step-by- information on screens.
Page 616 Step Description Refer to chapter <APN:> Available for some GPRS / Internet devices. The Access Point Name of a server from the network provider, which allows access to data services. Contact your provider to get the correct APN. Mandatory for using GPRS. CODES (F3) Available for digital cellular phones of GSM technology.
Page 617: Internet / Ethernet
24.8 Internet / Ethernet The Internet connection and the Ethernet connection is available on the GRX1200+ and GRX1200+ GNSS. Description Internet The Internet connection allows for the GPS1200+ receivers except GRX1200+/GRX1200+ GNSS to be connected to the Internet to receive real-time data. A GPRS / Internet device must be attached to the receiver.
Page 618 Configure port NET The following table explains the most common settings. Refer to the stated chapter for more step-by-step information on screens. Step Description Refer to chapter Refer to "22.2 Accessing Configuration Interfaces" to access CONFIGURE Interfaces. CONFIGURE Interfaces Highlight an interface which has an Internet / Ethernet device attached.
Page 619 Step Description Refer to chapter <IP Address:> The IP address of the selected <Server:> as config- 20.5 ured in CONFIGURE Server to Connect. For <User: Server>: Output of the IP address associated with the NET port as configured in CONFIGURE Set NET Parameter. <Host:>...
Page 620 Step Description Refer to chapter Enter the IP address ranges. CLEAR (F5) returns the fields back to their default values. CONT (F1) returns to the screen from where CONFIGURE Set NET Port was accessed. Config...\Interfaces... - Controlling Devices GPS1200+...
Page 621: Scanning Reference Stations
24.9 Scanning Reference Stations Description CONFIGURE Scan Reference Station provides information about the reference stations, with specific types of devices attached, for example a radio, from which real-time corrections are being received. This can also be useful for finding out if anyone else in the area is using a particular radio channel.
Page 622 CONFIGURE Scan Reference Station CONT (F1) To select the highlighted reference station and to continue with the subsequent screen. CH- (F2) and CH+ (F3) Available for scanning reference stations with radios attached. To switch the radio to one channel lower/higher than the current channel. The reference stations displayed change to those broadcasting on the new channel.
Page 623: Configuring The Stations To Dial
24.10 Configuring the Stations to Dial 24.10.1 Overview Description CONFIGURE Stations to Dial allows new stations to be created, provides a list of reference stations that can be dialled and allows existing stations to be edited. For digital cellular phones of any technology and for modems, the phone numbers of the device at the reference station must be known.
Page 624: Accessing Configure Stations To Dial
24.10.2 Accessing CONFIGURE Stations to Dial Access step-by-step Step Description Refer to chapter Refer to "22.2 Accessing Configuration Interfaces" to access CONFIGURE Interfaces. In CONFIGURE Interfaces highlight an interface which has a digital cellular phone of any technology or modem attached. CTRL (F4) to access CONFIGURE XX Connection.
Page 625 Description of columns Column Description Name Name of all available reference stations. Number Phone number of the station to dial. Config...\Interfaces... - Controlling Devices GPS1200+...
Page 626: Creating A New Station To Dial
24.10.3 Creating a New Station to Dial Create new station to Step Description dial step-by-step Refer to "24.10.2 Accessing CONFIGURE Stations to Dial" to access CONFIGURE Stations to Dial. NEW (F2) to access CONFIGURE New Station to Dial. CONFIGURE New Station to Dial <Name:>...
Page 627 Step Description SHIFT ELL H or SHIFT ORTH (F2) Available for local coordinates. Changes between the ellipsoidal and the orthometric height. STORE (F1) returns to the screen from where CONFIGURE New Points to Dial was accessed. Config...\Interfaces... - Controlling Devices GPS1200+...
Page 628: Editing A Station To Dial
24.10.4 Editing a Station to Dial Access step-by-step Step Description Refer to "24.10 Configuring the Stations to Dial" to access CONFIGURE Stations to Dial. EDIT (F3) to access CONFIGURE Edit Station to Dial. All following steps are identical with the creation of a new station to dial. Refer to "24.10.3 Creating a New Station to Dial".
Page 629: Configuring The Server To Connect
24.11 Configuring the Server to Connect 24.11.1 Overview Description CONFIGURE Server to Connect allows new servers to be created, provides a list of servers that can be accessed in the Internet and allows existing servers to be edited. For servers to be accessed in the Internet, the IP address or the host name (for RX1250 receivers only) and the TCP/IP port must be known.
Page 630: Accessing Configure Server To Connect
24.11.2 Accessing CONFIGURE Server to Connect Access step-by-step Step Description Refer to chapter Refer to "22.2 Accessing Configuration Interfaces" to access CONFIGURE Interfaces. In CONFIGURE Interfaces highlight an interface which has an Internet/Ethernet interface attached. CTRL (F4) to access CONFIGURE XX Connection. Open the choicelist for <Server:>...
Page 631 DEL (F4) To delete the highlighted server. MORE (F5) To change between the IP Address (for RX1250 receivers: Host) and the TCP/IP Port of the server. Description of columns Column Description Name Name of all available servers. IP Address IP addresses of all available servers. Host Host names of all available servers.
Page 632: Creating A New Server
24.11.3 Creating a New Server Create new server to be Step Description accessed step-by-step Refer to "24.11.2 Accessing CONFIGURE Server to Connect" to access CONFIGURE Server to Connect. NEW (F2) to access CONFIGURE New Server. CONFIGURE New Server <Name:> A unique name for the new server to be accessed. The name may be up to 16 characters long and may include spaces.
Page 633: Editing A Server To Connect
24.11.4 Editing a Server to Connect Access step-by-step Step Description Refer to "24.11 Configuring the Server to Connect" to access CONFIGURE Server to Connect. EDIT (F3) to access CONFIGURE Edit Server. All following steps are identical with the creation of a new server. Refer to "24.11.3 Creating a New Server".
Page 634: Tools
Tools...\Format Memory Device Description Allows the CompactFlash card, the internal memory, if fitted, and the System RAM to be formatted. All data will be erased. Refer to "Appendix B Memory Types" for more information on the types of memory devices available. Access Select Main Menu: Tools...\Format Memory Device.
Page 635 Field Option Description Output For receivers without internal memory. CF Card or For receivers with CompactFlash card and internal Internal Memory memory. <Format Format Quick After formatting, data is not visible any more but still Method:> exists on the memory device and is overwritten as and when required.
Page 636: Tools
Tools...\Transfer Objects... Description This chapter describes the basic procedure for transferring objects between the Compact- Flash card, and the internal memory, if fitted, and the System RAM. Refer to "Appendix C Directory Structure of the Memory Device" for information about file types and locations of files on the CompactFlash card.
Page 637 Description of fields Field Option Description <From:> Memory device to transfer object from. CF Card Transfer from CompactFlash card. System RAM Transfer from System RAM. Available unless object to transfer is a job. Internal Memory Transfer from internal memory, if fitted. Available if the object to transfer is a job.
Page 638 Field Option Description Each new System1200 firmware will include the latest PZ-90 transformation, so that is normally not necessary to transfer a PZ-90 transformation to or from a sensor. PZ90 is the GLONASS reference frame. For a combined processing (GPS & GLONASS) a 7- parameter Helmert transformation is necessary to transform PZ90 into WGS84.
Page 639 IF all XX THEN are not to be transferred CONT (F1) transfers selected object. Tools...\Transfer Objects... GPS1200+...
Page 640: Tools
Tools...\Upload System Files... 27.1 Application Programs Description Application program uploads are possible from the CompactFlash card to the application programs memory. These files are stored in the \SYSTEM directory of the memory device and use the extension *.a*. Access Select Main Menu: Tools...\Upload System Files...\Application Programs. TOOLS Upload Application Programs...
Page 641 Description of fields Field Option Description <From:> Output Upload from CompactFlash card. <To:> Output Upload to application programs memory. <Program:> Choicelist List of program files stored on the CompactFlash card. <Version:> Output Version of the program file chosen. Next step CONT (F1) uploads the selected application program.
Page 642: System Languages
27.2 System Languages Description System language uploads are possible from the CompactFlash card to the instrument. These files are stored in the \SYSTEM directory of the active memory device and use an extension that is individual to each language. Access Select Main Menu: Tools...\Upload System Files...\System Languages.
Page 643 Field Option Description <Language:> Choicelist List of language files stored on the CompactFlash card. <Version:> Output Version of the language file. Next step CONT (F1) uploads the selected language. It is not possible to have more than three language files stored on the instrument. English is always available as the default language and cannot be deleted.
Page 644: Instrument Firmware
27.3 Instrument Firmware Description Firmware uploads are possible from the CompactFlash card to the instrument, Smart- Antenna or RX1200. These files are stored in the \SYSTEM directory of the active memory device and use the extension *.fw. SmartAntenna must always be connected to RX1250 when uploading the firmware. Connect SmartAntenna and RX1250 via cable.
Page 645 Description of fields Field Option Description <From:> Output Upload from CompactFlash card. <To:> Output Upload to the instrument or RX1200. <Firmware:> Choicelist List of firmware files stored on the CompactFlash card. The RX1200 firmware is for RX1210 and RX1210T. This software covers display, sound and communica- tion settings of the RX1210 and RX1210T.
Page 646: Overview
Tools...\Calculator 28.1 Overview Description The calculator can be used to perform the following arithmetic operations such as • addition, subtraction, multiplication and division • statistics • trigonometry, hyperbolic trigonometry and calculations with Pi • polar, rectangular and angle conversions • powers, logs, roots and exponential functions.
Page 647: Accessing The Calculator
28.2 Accessing the Calculator Access Select Main Menu: Tools...\Calculator. Press a hot key configured to access the screen TOOLS XX Calculator. Refer to "6.1 Hot Keys" for information on hot keys. Press USER. Refer to "6.2 USER Key" for information on the USER key. Press CALC in any screen when editing an input field for numeric characters, such as <Azimuth:>...
Page 648: Configuring The Calculator
28.3 Configuring the Calculator Access step-by-step Step Description Refer to "28.2 Accessing the Calculator" to access TOOLS XX Calculator. SHIFT CONF (F2) to access TOOLS Calculator Configuration. TOOLS Calculator Configura- tion CONT (F1) To accept changes and return to the screen from where this screen was accessed.
Page 649 Field Option Description Standard The principle of conventional pocket calculators. Refer to "28.1 Overview" for more information. Refer to "28.4.2 Standard Mode" for a working example. <Angle Unit:> The unit used for trigonometric functions in the calcu- lator. The selection here is independent from the angle setting in CONFIGURE Units &...
Page 650: Using The Calculator
28.4 Using the Calculator 28.4.1 RPN Mode Requirements <Operatng Mode: RPN> in TOOLS Calculator Configuration. Access Refer to "28.2 Accessing the Calculator" to access TOOLS RPN Calculator. TOOLS Refer to paragraph "Working example" for information about the operating principle. RPN Calculator The function keys F1-F6 are allocated seven times.
Page 651 Description of fields Field Option Description First field on the Output The unit used for trigonometric functions in the calcu- screen lator as configured in TOOLS Calculator Configura- tion. Degrees Radians GRAD <ΣY:> Output The result of the sum or difference of values in <Y:> using Σ+ (F1) and Σ- (F2).
Page 652 Working example Task: Calculate (3 + 5) / (7 + 6). Step Description Type in 3. ENTER Type in 5. ENTER <Y: 3>, <X: 5> + (F1) <X: 8> Type in 7. ENTER <Y: 8>, <X: 7> Type in 6. ENTER <Z: 8>, <Y: 7>, <X: 6>...
Page 653: Standard Mode
28.4.2 Standard Mode Requirements <Operatng Mode: Standard> in TOOLS Calculator Configuration. Access Refer to "28.2 Accessing the Calculator" to access TOOLS Standard Calculator. TOOLS Refer to paragraph "Working example" for information about the operating principle. Standard Calculator The function keys F1-F6 are allocated seven times.
Page 654 Field Option Description Radians GRAD <Σ:> Output The result of the sum or difference of values in the last field on the screen using Σ+ (F1) and Σ- (F2). Third to sixth Output Previously entered value field on the screen Latest operation including result # indicates that the value is cut after the third decimal.
Page 655 Step Description such that STO (F1) is visible. STO (F1) such that + (F1) is visible. Type in 7. ENTER + (F1) Type in 6. ENTER Last field on the screen displays 13.00000. Remember 13.00000. such that REC (F2) is visible. REC (F2) to recall 8.00000.
Page 656: Description Of Softkeys
28.4.3 Description of Softkeys Overview of softkeys The softkeys shown and described are those of <Operatng Mode: RPN>. Most of the softkeys are identical and their functionality is similar to that for <Operatng Mode: Standard>. The function keys F1-F6 are allocated seven times with softkeys. Using the various allocations can be accessed.
Page 657 Description of softkeys First level + (F1) To add <X:> and <Y:>. - (F2) To subtract <X:> from <Y:>. * (F3) To multiply <X:> by <Y:>. / (F4) To divide <Y:> by <X:>. +/- (F5) To change between positive and negative algebraic sign for <X:>.
Page 658 to access the Third level SIN (F1) To calculate sine of <X:>. COS(F2) To calculate cosine of <X:>. TAN (F3) To calculate tangent of <X:>. ASIN (F4) To calculate arcsine of <X:>. ACOS (F5) To calculate arccosine of <X:>. ATAN (F6) To calculate arctangent of <X:>.
Page 659 to access the Fifth level POLAR (F1) Conversion of rectangular coordinates into polar coordinates. The y coordinate must be visible in <Y:> and the x coordinate in <X:> when pressing this key. The angle is displayed in <Y:> and the distance in <X:>. RECT(F2) Conversion of polar coordinates into rectan- gular coordinates.
Page 660 e^X (F4) <X:> To calculate e Y^X (F6) <X:> To calculate <Y:> to access the Seventh level STO (F1) To store <X:> to the memory. Up to ten values can be stored. RCL (F2) To recall a value for <X:> from the memory. Up to ten values can be recalled.
Page 661: Calling And Closing The Calculator From An Input Field For Numeric Characters
28.4.4 Calling and Closing the Calculator from an Input Field for Numeric Characters COGO traverse calculation is used as example. Call and close calcu- Step Description Refer to lator step-by-step chapter Select Main Menu: Programs...\COGO to access the screen COGO COGO Begin.
Page 662 Step Description Refer to chapter Perform the calculations. 28.4.1, 28.4.2 SHIFT DONE (F4) to return to COGO Traverse Input. The calculated value is taken over for <Azimuth:>. Tools...\Calculator GPS1200+...
Page 663 Tools...\File Viewer Description Allows ASCII files on the memory device to be viewed. The ASCII file can have up to 500 KB. Refer to "Appendix C Directory Structure of the Memory Device" for more information on the contents of folders on the memory device. The \DBX directory cannot be accessed to view files.
Page 664 DEL (F4) Available for a file being highlighted. To delete the highlighted file. MORE (F5) To display information about the size of a directory or file. CFCRD (F6) or INTL (F6) Available for receivers with internal memory. To change between viewing jobs stored on the CompactFlash card or internal memory.
Page 665 THEN a directory is to highlight the directory and DIR (F2). accessed a file is to be viewed highlight the file and VIEW (F3). Refer to "TOOLS View File: File Name". TOOLS View File: File Name CONT (F1) To return to the screen from where this screen was accessed.
Page 666 Keys Function Moves left. Next step CONT (F1) returns to the screen from where TOOLS View File: File Name was accessed. Tools...\File Viewer GPS1200+...
Page 667: Tools
Tools...\Licence Keys Description A licence key can be used to activate application programs and protected options and can be used to define the expiry date of the software maintenance. Refer to "32.4 STATUS: System Information" to find out how to check the expiry date of the software maintenance. A licence key is required for: Application programs Protected options...
Page 668 Access Select Main Menu: Tools...\Licence Keys. Select an application program not yet activated. TOOLS Enter Licence Key CONT (F1) To accept changes and return to GPS1200+ Main Menu or continue with application program. SHIFT DEL (F4) To delete all licence keys on the receiver/RX1250.
Page 669 Field Option Description Manual Entry of Allows the licence key to be typed in manually. <Key:> User input Available for <Method: Manual Entry of Key>. The licence key required to activate an application program. Entry is not case sensitive. Next step CONT (F1) returns to GPS1200+ Main Menu or continues with selected application program.
Page 670: Tools
Tools...\Field to Office Description This is to transfer jobs, codelists and other System1200 related files on the CompactFlash Card with a standard and simple FTP server. FTP protocol is used to transfer between System1200, which runs SmartWorx and has an internet device connected, and the ftp server.
Page 671 TPS configuration files *.xfg CONFIG System files System.ram SYSTEM Custom ASCII file (LEICA Geo Office Export) *.cst DATA Comma seperated variables, text file format (ASCII) *.csv DATA Internet interface should be configured and connected prior to using this function. Access Select Main Menu: Tools...\Field to Office.
Page 672 Field Option Description <Host:> User input In order to get access to the Internet, a host name is required. This host name identifies the receiver in the Internet. For RX1250 receivers only. <TCP/IP Port:> User input Port to be used. Any number between 0 and 65535 is valid.
Page 673 SEND (F1) To copy the file or folder to its corresponding directory on the ftp server. Files or folders bigger than 100 KB are zipped before sending. UNZIP (F2) To unzip a file in the download directory. Avail- able if a zip file is highlighted. IMPRT (F3) To move a file from the \Download folder to the appropriate directory folder based on it's file...
Page 674 TOOLS The files located on the FTP server are displayed. Field to Office: Whenever switching to this page, a refresh action is done or it reconnects to the server if the Transfer, connection to the server was disconnected. Office page The most important keys are explained.
Page 675: Status
STATUS 32.1 STATUS Functions Description The STATUS functions help using the receiver by showing the state of many receiver func- tions. All fields are output fields. Unavailable information is indicated by -----. Access Press USER and then STAT (F3). Refer to "6.2 USER Key" for information on the USER key. STATUS Status Menu CONT (F1)
Page 676 STATUS function Description Refer to chapter Battery & Memory Information related to usage and status of 32.3 battery and memory. System Information Information related to the instrument hardware 32.4 and firmware. Interfaces... • Information related to the configuration and 32.5 use of interfaces, ports and devices.
Page 677: Status: Survey
32.2 STATUS: Survey... 32.2.1 Satellite Status Description This screen shows information related to the satellites ordered by the elevation angle. Access Select STATUS: Survey...\Satellite Status. Refer to "32.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Satellites. Refer to "6.1 Hot Keys"...
Page 678 STATUS Satellites: Rover, GPS page CONT (F1) To exit STATUS Satellites. ROV / REF (F3) To change between the signal to noise ratio values of rover and reference. Available for <R-Time Mode: Rover> config- ured in CONFIGURE Real-Time Mode. HELTH (F4) To view the numbers of satellites categorised in good, bad and unavailable.
Page 679 Description of columns Column Description The Pseudo Random Noise number (GPS), the Slot number (GLONASS) or the Space Vehicle number (Galileo) of the satellites. Elev The elevation angle in degrees. The arrows indicate if the satellite is rising or falling. Azmth The azimuth of the satellite.
Page 680 STATUS The information about the satellites at the reference shown on this page is identical with the Satellites: Reference, information shown on STATUS Satellites: Rover, GPS page. Refer to paragraph "STATUS GPS page Satellites: Rover, GPS page". Next step CONT (F1) exits STATUS Satellites. STATUS The information about the GLONASS satellites shown on this page is identical with the infor- Satellites: Rover,...
Page 681 STATUS The skyplot shows satellite information in a graphical way. Satellites below the <Cut Off Satellites: Rover, Angle:> configured in CONFIGURE Satellite Settings are marked grey. Skyplot page The part of the skyplot between the 0° elevation and the cut-off angle is marked grey. CONT (F1) To exit STATUS Satellites: Rover.
Page 682 Description of symbols Symbol Description Satellites above the <Cut Off Angle:> configured in CONFIGURE Satel- lite Settings. Satellites below the <Cut Off Angle:> configured in CONFIGURE Satel- lite Settings. Next step PAGE (F6) changes to the Almanac page. Refer to paragraph "STATUS Satellites: Rover, Almanac page".
Page 683 STATUS The almanac page shows the date of the used almanacs, the number of satellites tracked as Satellites: Rover, shown on the skyplot and the number of all satellites available above the cut off elevation Almanac page mask as shown on the skyplot. CONT (F1) To exit STATUS Satellites: Rover.
Page 684: Real-Time Status
32.2.2 Real-Time Status Description This screen shows information related to real-time data, for example the data link and the device used to transfer real-time data. The name of the screen changes depending on the configuration: Real-time rover configuration: STATUS Real-Time Input Real-time reference configuration with one STATUS Real-Time Output real-time device:...
Page 685 STATUS Real-Time, General page CONT (F1) To exit STATUS Real-Time. DATA (F4) To view the data being received. Depending on <R-Time Data:>, the shown data differ. Refer to paragraph "STATUS Real-Time Input Data". REF2 (F5) and REF1 (F5) Available for <R-Time Mode: Reference> with two real-time devices configured.
Page 686 Field Description <GAL Used Available for Galileo receivers when <GALILEO: Yes> is configured in E1/E5a:> CONFIGURE Satellite settings. The number of satellites on E1 and E5a being used in the current position solution. <GAL Used Available for Galileo receivers when <GALILEO: Yes> is configured in E5b/ABOC:>...
Page 687 Next step PAGE (F6) changes to the Device page. Refer to paragraph "STATUS Real-Time, Device page". STATUS The content of this page differs for each type of device in use. Real-Time, Device page CONT (F1) To exit STATUS Real-Time. ACCNT (F3) Available for SMARTgate device.
Page 688 For RS232 Description of fields Field Description <Type:> The type of device. <Port:> The port to which the device is connected. <Bluetooth:> Available if device is connected via bluetooth. Indicates the state of the connection. For digital cellular phones and modems Description of fields Field Description...
Page 689 For radios Description of fields The available fields depends on the radio type. Field Description <Port:> The port to which the device is connected. <Type:> The type of device. <Channel:> The radio channel. <Actual Freq:> The actual set frequency of the radio. <Central Freq:>...
Page 690 Reference is a real reference station. Ref (Nearest) page Reference is the closest to the rover determined by for example LEICA GNSS Spider. Ref (i-MAX) page Reference information are individualised Master-Auxiliary corrections determined and sent by for example LEICA GNSS Spider. STATUS GPS1200+...
Page 691 It is different from the point ID of the reference station. <Antenna Ht:> • For <R-Time Data: Leica>, <R-Time Data: Leica 4G>, <R-Time Data: RTCM v3.1> or <R-Time Data: RTCM X v2> with <RTCM Version: 2.3>: The antenna height at the reference from the marker to the MRP.
Page 692 Field Description • For real-time messages which include antenna height and antenna type: Marker. • For real-time messages which do not include antenna Information: Phase Centre of L1. <No.of Aux The number of active auxiliary reference stations from which data is Ref:>...
Page 693 STATUS The following provides additional information on the satellite data received via real-time Real-Time Input Data message. Information of those satellites is displayed, which are used on both reference and rover. Access DATA (F4) on STATUS Real-Time, General page. CONT (F1) To return to STATUS Real-Time.
Page 694 Field Description <Sat PRN:> The PRN number (GPS), the Slot number (GLONASS) or the Space Vehicle number (Galileo) of the satellites shown with the prefix G (GPS), R (GLONASS) or E (Galileo). <Sat Time:> The GPS time of the satellite. <Phase L1:>, <Phase L2:>, The number of phase cycles from the antenna to the <Phase L5:>...
Page 695 Field Description <RRC:> Rate of change of the corrections. <IODE:> Issue Of Data Ephemeris. The identification number of the ephemeris for a satellite. Next step CONT (F1) returns to the screen from where STATUS Real-Time Input Data was accessed. STATUS GPS1200+...
Page 696: Current Position
32.2.3 Current Position Description This screen shows information related to the current antenna position and the speed of the antenna. For real-time rover configurations the baseline vector is also shown. MapView shows the current position in a graphical format. Access Select STATUS: Survey...\Current Position.
Page 697 STATUS Position, CONT (F1) Position page To exit STATUS Position. COORD (F2) To see other coordinate types. Local coordi- nates are available when a local coordinate system is active. PAGE (F6) To change to another page on this screen. SHIFT ELL H (F2) and SHIFT ORTH (F2) Available for local coordinates.
Page 698 Next step THEN the receiver is a real-time PAGE (F6) changes to the Baseline page. Refer to para- rover graph "STATUS Position, Baseline page". the receiver is not configured PAGE (F6) changes to the Speed page. Refer to paragraph for real-time "STATUS Position, Speed page".
Page 699 Next step CONT (F1) exits STATUS Position. STATUS GPS1200+...
Page 700: Logging Status
32.2.4 Logging Status Description This screen shows information related to logging of raw observations, including ring buffer. Access Select STATUS: Survey...\Logging Status. Refer to "32.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Logging. Refer to "6.1 Hot Keys"...
Page 701 Description of fields Field Description <All Static The number of static epochs recorded in the current job. Obs:> <All Moving The number of moving epochs recorded in the current job. Obs:> <Recorded The number of manually occupied points and auto points stored in the job. DB-X Pts:>...
Page 702 STATUS Logging, Ring Buffer page CONT (F1) To exit STATUS Logging. PAGE (F6) To change to another page on this screen. Description of fields Field Description <Ring Buffer No.:> The number of the active ring buffer. <No. of Files:> The number of files stored in the ring buffer. <Obs Flagged:>...
Page 703 Ref (Nearest) page Reference is the closest to the rover determined by for example LEICA GNSS Spider. Ref (i-MAX) page Reference information are individualised Master-Auxiliary corrections determined and sent by for example LEICA GNSS Spider. Ref (MAX) page Reference information are Master-Auxiliary corrections determined and sent by for example LEICA GNSS Spider.
Page 704 Field Option Description None Raw observations are not being logged at the refer- ence. Next step CONT (F1) exits STATUS Logging. STATUS GPS1200+...
Page 705: Occupation Information Status
32.2.5 Occupation Information Status Description This screen shows information related to the amount of time required at a point and the amount of time spent on a point. Access Select STATUS: Survey...\Occupation Information Status. Refer to "32.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Occupation Information (Static) or STATUS Occupation Information (Moving).
Page 706 For static mode Description of fields Field Description <Obs The percentage of collected data required for successful processing. Completed:> It is a conservative estimate based on a 10 - 15 km baseline. The criteria used to display this value depend on the settings for <Auto STOP:>, <STOP Criteria:>...
Page 707 For moving mode Description of fields Field Description <>5 Sats The time for how long five or more satellites are tracked on L1 and L2 Since:> without interruption. The counter is reset if less than five satellites were tracked. The counter is not reset after OCUPY (F1), STOP (F1) or STORE (F1).
Page 708: Status: Battery & Memory
32.3 STATUS: Battery & Memory Access Select STATUS: Battery & Memory. Refer to "32.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Battery & Memory. Refer to "6.1 Hot Keys" for information on hot keys. Press USER.
Page 709 STATUS Battery & Memory (Rover), Battery page CONT (F1) To exit STATUS Battery & Memory (Rover). REF (F5) Available when the receiver is configured as real-time rover. To view battery and memory information for the reference. PAGE (F6) To change to another page on this screen. Description of fields Field Description...
Page 710 STATUS If no information for a field is available, for example no CompactFlash card is inserted, then Battery & Memory ----- is displayed. (Rover), Memory page CONT (F1) To exit STATUS Battery & Memory (Rover). REF (F5) Available when the receiver is configured as real-time rover.
Page 711 This screen consists of the Battery and the Memory page. Both pages are similar to those Battery & Memory of the rover screen. The information that is displayed depends on the real-time message. (Reference) Leica: Transfers precise values for all fields. RTCM: Transfer of any of the information not part of the message.
Page 712: Status: System Information
32.4 STATUS: System Information Access Select STATUS: System Information. Refer to "32.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS System Information. Refer to "6.1 Hot Keys" for information on hot keys. Press USER.
Page 713 Field Description <Maintenance Expiry date of the software maintenance. End:> <Build User Iface:> Build version of the onboard software. <Build Processb:> Build version of the processor board. <Meas Engine:> The firmware version for the measurement engine. <Meas Eng Boot:> The firmware version of the boot software for the measurement engine.
Page 714: Status: Interfaces
32.5 STATUS: Interfaces... 32.5.1 Real-Time Input Description This screen shows the incoming data from the real-time device. Refer to "32.2.2 Real-Time Status" paragraph "STATUS Real-Time, Device page" for information on the fields available, depending on the configured real-time device. Access This screen is accessible for a configured and activated real-time interface.
Page 715: Ascii Input
32.5.2 ASCII Input Description This screen shows the • incoming ASCII data which is stored as a point annotation. • description of the incoming ASCII data for each point annotation field. Not used is shown for annotation fields which are not configured to receive incoming ASCII data.
Page 716 STATUS ASCII Input - XX CONT (F1) To exit STATUS ASCII Input - XX. DATA (F3) and DESCR (F3) To change between the given description for the incoming ASCII data or the last received ASCII data. Next step CONT (F1) exits STATUS ASCII Input - XX. STATUS GPS1200+...
Page 717: Tilt
32.5.3 Tilt Description This screen shows the incoming data from the tilt device. Access This screen is accessible for a configured and activated tilt interface. Select STATUS: Interfaces..Highlight Tilt. IFACE (F5). Refer to "32.1 STATUS Func- tions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Tilt Measurement.
Page 718 Next step CONT (F1) exits STATUS Tilt Measurement. STATUS GPS1200+...
Page 719: Meteo
32.5.4 Meteo Description This screen shows the incoming data from the meteo device. Access This screen is accessible for a configured and activated meteo interface. Select STATUS: Interfaces..Highlight Meteo. IFACE (F5). Refer to "32.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Meteo Measurement.
Page 720: Smartantenna
32.5.5 SmartAntenna Description This screen shows • the SmartAntenna connected. • the seconds since the last data from the SmartAntenna was received. • if the SmartAntenna is connected via Bluetooth or USB cable. This information is included in the name of the screen. Access This screen is accessible for a configured SmartAntenna interface.
Page 721: Internet
32.5.6 Internet This screen is not available for the GRX1200+ and GRX1200+ GNSS where Ethernet is used for the Internet connection. Description This screen shows • if the receiver is online on the Internet. • for how long the receiver is online. •...
Page 722: Event Input
32.5.7 Event Input Description This screen shows the incoming data from the event input interface. Access This screen is accessible for a configured and activated event input interface. Select STATUS: Interfaces..Highlight Event Input. IFACE (F5). Refer to "32.1 STATUS Functions" on how to access the STATUS menu. Press a hot key configured to access the screen STATUS Event Input.
Page 723 Field Description <Event Pulse The incrementing number of detected pulses in the event input. Count:> Events which do not fulfil the requirements configured in CONFIGURE Event Input are counted as an event pulse but not as an event. This is, for example, the case when the time between two events is shorter than defined in <Time Guard:>.
Page 724: Remote Interfaces
32.5.8 Remote Interfaces Description This screen shows all available ports and the interfaces and devices configured to these ports. Access This screen is accessible for a configured and activated remote interface. Select STATUS: Interfaces..Highlight Remote. IFACE (F5). Refer to "32.1 STATUS Functions"...
Page 725 Description of fields Column Description Port The physical port on the instrument which is being used for the interface functionality. Interface The interface configured for the ports. Device The hardware connected to the chosen port. Next step CONT (F1) exits STATUS Remote Interfaces. STATUS GPS1200+...
Page 726: Bluetooth
32.6 Bluetooth Description This screen shows • Bluetooth ports available and configured. • the device attached and connected to each Bluetooth port. • the ID address of each device. Access Select STATUS: Bluetooth. Refer to "32.1 STATUS Functions" on how to access the STATUS menu.
Page 727: Mapview Interactive Display Feature
MapView Interactive Display Feature 33.1 Overview Description MapView is an interactive display feature embedded in the firmware but used by all applica- tion programs as well as data management. MapView provides a graphical display of the survey elements which allows for a better overall understanding of how the data being used and measured relates to each other.
Page 728 • Can be used to select lines and areas. • Same as Map mode but also shows the positions of the reference stations and the rover. • Provides special functionality when staking out points. • Available as the Map page in Survey and some application programs.
Page 729: Accessing Mapview
33.2 Accessing MapView Description The MapView interactive display feature is provided as a page within all application programs and data management. It is accessed through the application program itself. Depending on the application program and from where in the application program MapView is accessed, different MapView modes are available.
Page 730 Step Description Press a hot key configured to access the screen COGO COGO Begin. Refer to "6.1 Hot Keys" for information on hot keys. Press USER. Refer to "6.2 USER Key" for information on the USER key. CONT (F1) to access COGO COGO Menu. COGO COGO Menu Highlight Intersections.
Page 731 Step Description Press USER. Refer to "6.2 USER Key" for information on the USER key. Press PROG. Highlight Survey. CONT (F1). Refer to "37.2 Accessing the Application Programs Menu" for information on the PROG key. CONT (F1) to access SURVEY Survey: Job Name. PAGE (F6) until SURVEY Survey: Job Name, Map page is active.
Page 732: Configuring Mapview
33.3 Configuring MapView Description Allows options to be set which are used as default options within MapView. These settings are stored within the configuration set and apply to all Map and Plot pages, regardless of how MapView is accessed. Any changes made in XX MapView Configuration affect the appearance of MapView in all application programs, not just the active application program.
Page 733 Description of fields Field Option Description <Show Yes or No Determines if points are displayed in MapView. Points:> <Point ID:> Yes or No Available for <Show Points: Yes>. Determines if the ID of a point is displayed. <Point Code:> Yes or No Available for <Show Points: Yes>.
Page 734 Description of fields MapView Configuration, Field Option Description Lines&Areas page <Show Lines:> Yes or No Determines if lines are displayed in MapView. <Show Line Yes or No Available for <Show Lines: Yes>. Determines if the ID:> ID of a line is displayed. <Show Line Yes or No Available for <Show Lines: Yes>.
Page 735 Next step PAGE (F6) changes to the Display page. Refer to paragraph "XX MapView Configuration, Display page". Description of fields MapView Configuration, Field Option Description Display page <Show Pt When <200 Pts or Determines if point information is shown or not. For Info:>...
Page 736 Field Option Description Point ID Point ID of the current position. Code Code of the current position. Attrib 01 User defined attribute. Attrib 02 User defined attribute. Attrib 03 User defined attribute. Attrib 04 User defined attribute. Attrib 05 User defined attribute. Quality 3D Current 3D coordinate quality of the computed posi- tion.
Page 737: Mapview Components
33.4 MapView Components 33.4.1 Softkeys Description Standard functionality is provided by a number of softkeys within MapView. These softkeys are available regardless of the mode in which MapView was accessed and always perform the same functions. Standard softkeys The softkeys described below are standard on all MapView screens. For descriptions of mode specific softkeys see appropriate chapters.
Page 738 Softkey Touch equivalent PAGE (F6) Tap on a page tab. SHIFT FIT (F3) Tap on fit touch icon. Refer to "33.4.3 Toolbar" MapView Interactive Display Feature GPS1200+...
Page 739: Screen Area
33.4.2 Screen Area Description The MapView screen area is very similar in all cases. The positions of the scale bar, the North arrow and the toolbar, if visible, do not change. Standard screen a) Toolbar b) North arrow c) Scale bar GPS12_142 Scale bar Symbol...
Page 740 Toolbar Symbol Description Touch icon toolbar. Refer to "33.4.3 Toolbar" for more information about the functionality of the touch icons in the toolbar. Point with focus Symbol Description The point that has the focus. Rover Symbol Description Available in survey mode. Position of the rover. The rover path is shown as dashed line.
Page 741: Toolbar
33.4.3 Toolbar Description Touch icons are available in a toolbar, if <Toolbar: On> in XX MapView Configuration, Display page. The toolbar is always located on the left hand side of the screen. Some of the functions performed by the touch icons can also be replicated using a softkey in the same mode as when the touch icon appears.
Page 742: Point Symbols
33.4.4 Point Symbols Points When <Show Points: Yes> in XX MapView Configuration, points are displayed, in all modes, according to their class. Symbol Description 3D control point is a point of class CTRL with full coordinate triplet. 2D control point is a position only point of class CTRL. Adjusted point is a point of class ADJ.
Page 743: Map Mode
33.5 Map Mode 33.5.1 MapView in Map Mode Description The map mode of MapView is available as the Map page in data management and some application programs. It can be used to display, select and edit points, lines and areas. Access Refer to "33.2 Accessing MapView"...
Page 744 FOCUS (F2) or DONE (F2) To activate the focus tool and select a point without using the touch screen. Refer to "33.5.2 Selecting Points, Lines and Areas". EDIT (F3) To edit the highlighted point’s parameters. Accesses MANAGE Edit Point: Point ID. SHIFT CENTR (F4) To centre the screen around the point with the current focus, or the focus tool if DONE (F2) is...
Page 745: Selecting Points, Lines And Areas
33.5.2 Selecting Points, Lines and Areas Description Selecting a point, line or area in the map mode of MapView is possible using both the softkeys and the touch screen. The functionality of all screens and field are similar for the selecting of a point, line or area.
Page 746 Step Description Display Use the arrow keys to navigate the focus tool to the point to select. A point is available for selection when the square is centred around the point symbol. Press ENTER to select the point. The point parameter text, as defined in XX MapView Configuration, Points page, is highlighted.
Page 747 Step Description Display CONT (F1) returns to MANAGE Data: Job Name, Map page with the focus on the selected point. DONE (F2) exits the focus tool. Selecting a point using Step Description Display the touch screen step- Refer to "33.5.1 MapView in Map Mode" to access by-step MANAGE Data: Job Name, Map page.
Page 748 Step Description Display When there are multiple points within the same area and the precise selection is unclear, tapping on the point will access XX Select Point. Have multiple points been selected? • If yes, continue with step 4. • If no, continue with step 6.
Page 749: Plot Mode - Mapview Screen Area
33.6 Plot Mode - MapView Screen Area Description The plot mode of MapView is available as the Plot page in an application program and can be used to view the results of the application program. Results are shown in black, all other information, that is displayable, is shown in grey.
Page 750 Touch screen functions Touch Equivalent SHIFT FIT R (F4) Tap on fit results touch icon. Refer to "33.4.3 Toolbar" MapView Interactive Display Feature GPS1200+...
Page 751 Example of results Application Display Description displayed in MapView COGO Intersec- Intersecting lines on Plot page tion, Bearing - with known bear- Bearing ings from known points COGO line Points defining the calculation, line and those Segmentation created on the line COGO Shift, Original points in Rotate &...
Page 752 Application Display Description COGO Area Points from the Division area and the area division are black, other points are grey Hidden Point, Line between Bearing and known point and Distance hidden point Reference Line, Reference line or Edit Reference arc with target point Line as offset from refer- ence line...
Page 753 Application Display Description Reference A dashed rectangle Plane, Edit indicates the face Reference view of the plane. Plane Update Setups Points from the job in grey, setup points and updated backsight points in black MapView Interactive Display Feature GPS1200+...
Page 754: Survey Mode
33.7 Survey Mode 33.7.1 MapView in Survey Mode Description The survey mode of MapView is available as the Map page in Survey and is used to display the positions of the reference station and the rover during a survey. It can also be used to select lines and areas.
Page 755 SHIFT FACE (F1) and SHIFT PLAN (F1) Available in REFPLANE Measure Point on Plane, Map page. To change between the face and the plane view of the plane. SHIFT CENTR (F4) To centre the screen around the point with the current focus or the focus tool, if FOCUS (F2) is active.
Page 756: Mapview In Staking Out Survey Mode
33.7.2 MapView in Staking Out Survey Mode Description When staking out a point in the Stakeout or Reference Line application programs, the Map page is available. The MapView survey mode is provided for this operation, with some differ- ences. • In the Stakeout application program, active points can be selected using the touch screen, as points to be staked.
Page 757 Access step-by-step Example access for MapView in survey mode, Stakeout Step Description Select Main Menu: Programs...\Stakeout. Press PROG. Highlight Stakeout. CONT (F1). Refer to "37.2 Accessing the Application Programs Menu" for information on the PROG key. Press a hot key configured to access the screen STAKEOUT Stakeout Begin. Refer to "6.1 Hot Keys"...
Page 758 SHIFT CENTR (F4) To centre the screen around the rover. Description of fields Field Option Description <DIST:> Output Horizontal distance from the current position to the point to be staked. <CUT:> Output The negative height difference from the height of the current position to the height of the point to be staked.
Page 759: Selecting Lines And Areas
33.7.3 Selecting Lines and Areas Description Selecting a line or area in the survey mode of MapView is possible using the touch screen. The functionality of all screens and field are similar for the selecting of a line or area. The step-by-step instructions for selecting a line using the touchscreen can be applied for areas.
Page 760 Step Description • If yes, continue with step 5. • If no, continue with step 7. XX Select Line Point ID The ID of the lines within range of the line selection. Point Code The code of the lines within range of the point selection. Select the desired line.
Page 761: Update Setups
Update Setups 34.1 Terminology Description This chapter describes technical terms related to Setup. Setup Setup is an application program on TPS1200+ instruments. It can be used to orientate the TPS1200+ instrument. Backsight In a TPS survey, the instrument is set up over a point. A reading onto a fixed point of reference, usually a benchmark of some sort, is taken in order to orientate the instrument.
Page 762 Relevance for GPS An unknown backsight point can be used to set up a TPS1200+ instrument. After finishing the TPS job, the coordinates of the unknown backsight point can be determined using GPS1200+ with the CompactFlash from the TPS1200+ instrument. When assigning the same point ID of the unknown backsight point to a point measured with GPS1200+, the TPS setup and all related calculations can be updated on GPS1200+.
Page 763: Procedure Of Updating Setups
34.2 Procedure of Updating Setups Access XX CONFIRMATION: 1100 is automatically accessed when a TPS1200+ setup with an unknown backsight point exists on the CompactFlash card in a GPS1200+ receiver the same point ID of the unknown backsight point is assigned to a point measured with GPS1200+.
Page 764 GPS1200+ Update Setups with new Setups page CONT (F1) To return to XX CONFIRMATION: 1100. MORE (F5) To change between time and date of when the setup was stored. PAGE (F6) To change to another page on this screen. Description of columns Column Description Setup...
Page 765 GPS1200+ The functionality and softkeys available are described in the MapView chapter. Refer to "33.6 Update Setups with new Plot Mode - MapView Screen Area". Points from the job are displayed in grey, setup points and updated backsight points are Plot page displayed in black.
Page 766: Ntrip Via Internet
NTRIP via Internet 35.1 Overview Description Networked Transport of RTCM via Internet Protocol • is a protocol streaming real-time corrections over the Internet. • is a generic protocol based on the Hypertext Transfer Protocol HTTP/1.1. • is used to send differential correction data or other kinds of streaming data to stationary or mobile users over the Internet, allowing simultaneous PC, laptop, PDA, or receiver connections to a broadcasting host.
Page 767 NTRIP Caster HTTP Streams NTRIP Server 1 NTRIP Server x NTRIP Source 1 NTRIP Source x NTRIP Client The NTRIP Client receives data streams. This could be, for example a real-time rover receiving real-time corrections. In order to receive real-time corrections, the NTRIP Client must first send •...
Page 768 NTRIP Server The NTRIP Server transfers data streams. In order to send real-time corrections, the NTRIP Server must first send • a password • an identification name, the so-called MountPoint, where the real-time corrections come from to the NTRIP Caster. Before sending real-time corrections to the NTRIP Caster for the first time, a registration form must be completed.
Page 769 Graphic NTRiPClient NTRiPServer NTRIP and it’s role in the Internet GPS12_149 NTRIP via Internet GPS1200+...
Page 770: Configuring A Real-Time Rover For Using Ntrip Service
35.2 Configuring a Real-Time Rover for Using NTRIP Service 35.2.1 Configuring an Access to the Internet Requirements • Firmware v1.5 or higher must be loaded on the GPS1200+ receiver. • Firmware v1.42 or higher must be loaded on the RX1200. To access to the Internet with a GPS1200+ receiver, General Packed Radio System devices will normally be used.
Page 771 Step Description Refer to chapter <User ID:> Some providers ask for a user ID to allow connecting to the Internet via GPRS. Contact your provider if a user ID needs to be used. <Password:> Some providers ask for a password to allow connecting to the Internet via GPRS.
Page 772 Step Description Refer to chapter CODES (F3) Available for digital cellular phones of GSM technology. To enter the Personal Identification Number of the SIM card. If the PIN is locked for any reason, for example the wrong PIN was entered, input the Personal UnblocKing code for access to the PIN.
Page 773: Configuring To Connect To A Server
35.2.2 Configuring to Connect to a Server Requirements The configurations from the previous chapter must have been completed. Refer to "35.2.1 Configuring an Access to the Internet". Configure connect to a The following table explains the most common settings. Refer to the stated chapter for more server step-by-step information on screens.
Page 774 Step Description Refer to chapter <Server:> The server to be accessed in the Internet. Opening the 24.11 choicelist accesses CONFIGURE Server to Connect where new servers can be created and existing servers can be selected or edited. <IP Address:> The stored IP address of the selected <Server:> to be accessed in the Internet.
Page 775 Step Description Refer to chapter Highlight Real-Time. DEVCE (F5) to access STATUS Device: Internet. STATUS Device: Internet Check the Internet online status. CONT (F1) to return to STATUS Interfaces. CONT (F1) to return to GPS1200+ Main Menu. NTRIP via Internet GPS1200+...
Page 776: Using The Ntrip Service With A Real-Time Rover
35.2.3 Using the NTRIP Service with a Real-Time Rover Requirements The configurations from the previous chapter must have been completed. Refer to "35.2.2 Configuring to Connect to a Server". Use NTRIP service step- Step Description by-step Select Main Menu: Config...\Interfaces..In CONFIGURE Interfaces highlight Real-Time.
Page 777 Step Description • First column MountPoint: The abbreviations for the MountPoints. • Second column Identifier: The city where the MountPoint is located. Highlight a MountPoint about which more information is required. This information helps to configure the receiver to use the selected MountPoint as a reference. INFO (F3) to access CONFIGURE MountPoint: XX.
Page 778 Step Description Detailed information about the location of the MountPoint is displayed. PAGE (F6) to access CONFIGURE MountPoint: XX, Miscell page. CONFIGURE MountPoint: XX, Miscell page <Generator:> The hard- or software generating the data stream. <Compress:> The name of the compression / encryption algorithm. <Info:>...
Page 779: Configuring A Grx1200+/Grx1200+ Gnss For Connecting A Ntrip Server
35.3 Configuring a GRX1200+/GRX1200+ GNSS for Connecting a NTRIP Server Description A NTRIP Server is built into the GRX1200+/GRX1200+ GNSS. It is part of the instrument firmware. Using one of the three NET ports, a GRX1200+/GRX1200+ GNSS can be set up as a real- time reference connected to the Internet.
Page 780 Step Description Refer to chapter Enter the TCP/IP Port number for the port that is open on the caster for a connection from the NTRIP server. Enter the access details (mountpoint and password) for the NTRIP Server to connect to the NTRIP Caster. For a Real-Time out data stream, activate the Auto connect on start check box.
Page 781: Reference Station
The GRX1200+ Series • are designed to operate for specific reference station applications using the web interface or a remote control software, for example LEICA GNSS Spider reference station soft- ware. • support internal logging of raw observations which can be downloaded via FTP push or using an external remote control software package such as LEICA GNSS Spider.
Page 782 • Support of DynDNS • Support of RTK multiplexing (up to 20 RTK clients) • Ring buffer logging • One Ethernet port including three logical NET ports • One port to output PPS • One port to input event messages •...
Page 783: Application Programs - General
Application Programs - General 37.1 Overview Description Application programs are software packages supporting specific tasks. Available are: • COGO • RoadRunner • Determine Coordinate System • Stakeout • DTM Stakeout • Survey • DXF Export • Survey Cross Section • DXF Import •...
Page 784 Customised application programs can be developed locally using the GeoC++ development programs environment. Information on the GeoC++ development environment is available on request from the Leica Geosystems representative. Customised application programs always run in the language they were developed in. Application Programs - General...
Page 785: Accessing The Application Programs Menu
37.2 Accessing the Application Programs Menu Description The application programs menu contains all loaded application programs including Survey. They are listed in the order in which they were loaded. Selecting an option in the menu starts the application program assigned to the option. Configurations and measurements that can be performed depend on the application program.
Page 786 Next step Select an option in the menu to open the application. Refer to the chapter on the individual application programs. Four application programs can be open at one time. XX Begin is shown for the application program opened first, but not for the following application programs. Application Programs - General GPS1200+...
Page 787: Cogo
COGO 38.1 Overview Description COGO is an application program to perform coordinate geometry calculations such as • coordinates of points. • bearings between points. • distances between points. The calculations can be made from • existing point data in the job, known distances or known azimuths. •...
Page 788 Distances and azimuths Type of distances: The choices are • Ground • Grid • Ellipsoidal Type of azimuths: The azimuths are grid azimuths relative to the local grid. Coding of COGO points • Thematical coding is available in COGO XX Results after the COGO calculation. Thematical coding of COGO points is identical to coding manually occupied points.
Page 789: Accessing Cogo
38.2 Accessing COGO Access Select Main Menu: Programs...\COGO. Press PROG. Highlight COGO. CONT (F1). Refer to "37.2 Accessing the Application Programs Menu" for information on the PROG key. Press a hot key configured to access the screen COGO COGO Begin. Refer to "6.1 Hot Keys"...
Page 790 COGO CONT (F1) COGO Begin To accept changes and access the subsequent screen. The chosen settings become active. CONF (F2) To configure the COGO application program. Accesses COGO Configuration. Refer to "38.3 Configuring COGO". CSYS (F6) To select a different coordinate system. Not available for <Use Auto CrdSys: Yes>...
Page 791 Field Option Description Output Codes have already been stored in the selected <Job:>. If codes had been copied from a System RAM codelist, then the name of the codelist is displayed. If codes have not been copied from a System RAM codelist but typed in, then the name of the active job is displayed.
Page 792 COGO The COGO menu lists all COGO calculation methods and the option to end COGO. COGO Menu CONT (F1) To select the highlighted option and to continue with the subsequent screen. SHIFT CONF (F2) To configure the COGO application program. Accesses COGO Configuration.
Page 793 COGO menu options Description Refer to chapter • a bearing and a distance from a known point and an offset point. To calculate the direction, the distance and the 3D coordinate differences between a known point and a given arc. The arc can be defined using •...
Page 794 COGO menu options Description Refer to chapter • the azimuth/bearing and the distance from a known point. Offset optional. • the angle and the distance from a known point. Offset optional. Points with full coordinate triplets and position only points can be used. Intersections To calculate the position of an intersection point 38.6...
Page 795 COGO menu options Description Refer to chapter • two known points that define the line, a distance along the line and an offset. • a distance along a bearing from a known point and and offset. To calculate new points on a line using •...
Page 796 COGO menu options Description Refer to chapter • the length of an arc and two tangents, each of it defined by a point and the intersection point of the tangents. • the length of a chord and two tangents, each of it defined by a point and the intersection point of the tangents.
Page 797 COGO menu options Description Refer to chapter Shift, Rotate & Scale To calculate the coordinates of new points using the 38.10 (Match Pts) shifts, rotation and scale computed from selected points. Points with full coordinate triplets, position only points and height only points can be used. Area Division To divide an area by a 38.11...
Page 798: Configuring Cogo
38.3 Configuring COGO Access Select Main Menu: Programs...\COGO. In COGO COGO Begin press CONF (F2) to access COGO Configuration. Press PROG. Highlight COGO. CONT (F1). In COGO COGO Begin press CONF (F2) to access COGO Configuration. Press SHIFT CONF (F2) in COGO COGO Menu. Refer to "38.2 Accessing COGO". Press SHIFT CONF (F2) in COGO XX.
Page 799 Description of fields Field Option Description <Distance The type of distances and offsets to be accepted as Type:> input or shown as output, and used in the calculation. Grid Distances are calculated as the trigonometric distance between the position of two points. The distance field is <HDist-Grid:>.
Page 800 Field Option Description Ellipsoid Known P1 First known point P2 Second known point Unknown Ground distance Ellipsoid distance Grid distance TPS12_170 <Use Offsets:> Yes or No Activates the use of offsets in the COGO calculations. Input fields for the offsets are available in COGO XX. <Store Pts MEAS or CTRL Defines the point class of COGO calculated and...
Page 801 Field Option Description <Compute Ht:> Defines the height being used within TPS Obs - TPS Obs Intersection. Using Average Using an average of the two observations. Use Upper Height Using the upper height. Use Lower Height Using the lower height. Next step PAGE (F6) changes to the Residuals page.
Page 802 Field Option Description None No distribution is made. Residuals remain with their asso- ciated points. 1/Distance Distributes the residuals according to the distance between each control point and the newly transformed point. Multiquad- Distributes the residuals using a multiquadratic interpola- ratic tion approach.
Page 803 Field Option Description <File Name:> Choicelist Available for <Write Logfile: Yes>. The name of the file to which the data should be written. A logfile is stored in the \DATA directory of the active memory device. The data is always appended to the file. Opening the choicelist accesses XX Logfiles where a name for a new logfile can be created and an existing logfile can be selected or deleted.
Page 804: Cogo Calculation - Inverse Method
38.4 COGO Calculation - Inverse Method 38.4.1 Inverse Point - Point Description The direction, the distance and the coordinate differences between the two known points can be calculated depending on the data available for the known points. Points with full coordi- nate triplets, position only points and height only points can be used.
Page 805 Access Refer to "38.2 Accessing COGO" to access COGO Inverse Input. COGO inverse calcula- The following table explains the most common settings. Refer to the stated chapter for more tion point - point step- information on screens. by-step Step Description Refer to chapter Refer to "38.2 Accessing COGO"...
Page 806 Step Description Refer to chapter The horizontal distance values which are displayed depend on the configuration for <Distance Type:> in COGO Configuration, Parameters page. ----- is displayed for unavailable information, for example if a position only point is used, <Δ Height:> cannot be calculated. <Azimuth:>...
Page 807 Step Description Refer to chapter Are more inverse COGO calculations to be made? • If yes, repeat steps 2. to 7. • If no, continue with step 8. SHIFT QUIT (F6) to exit COGO calculation. COGO GPS1200+...
Page 808: Inverse Point - Line
38.4.2 Inverse Point - Line Description The direction, the distance and the coordinate differences between a known point and a given line can be calculated depending on the data available for the known points. Points with full coordinate triplets, position only points and height only points can be used. Elements that must be known are •...
Page 809 Diagram Known P0 Start point P1 End point P2 Offset point Unknown P3 Base point d1 Offset-XX GPS12_119 d2 ΔLine-XX Access Refer to "38.2 Accessing COGO" to access COGO Inverse Pt - Line Input. COGO Inverse Pt - Line Input, Input page CALC (F1) To calculate COGO point.
Page 810 SURVY (F5) To manually occupy a point for the COGO calculation. Available if <Start Point:> or <End Point:> is highlighted. SHIFT CONF (F2) To configure the COGO application program. SHIFT MODIF (F4) To mathematically modify the values. Available if <Azimuth:> or <HDist-Grid:> is highlighted. Description of fields Field Option...
Page 811 Field Option Description <HDist-Grid:> User input Available for <Method: Pt/Brg/Dist>. The horizontal distance from the start point to the end point of the line. <Inverse to:> The method by which the inverse will be calculated. Known Point Inverse to a known point. All points from COGO Data: Job Name can be selected.
Page 812 COGO Inverse Pt - Line Result, Result page STORE (F1) To store result and to return to COGO Inverse Pt - Line Input. COORD (F2) To view other coordinate types. PAGE (F6) To change to another page on this screen. SHIFT ELL H (F2) and SHIFT ORTH (F2) To change between the ellipsoidal and the orthometric height.
Page 813 Next step PAGE (F6) changes to the Plot page. COGO The functionality of the Plot page is similar to COGO Traverse Results, Plot page. Inverse Pt - Line Result, Plot page Next step STORE (F1) stores the result and returns to COGO Inverse Pt - Line Input, Input page. COGO GPS1200+...
Page 814: Inverse Point - Arc
38.4.3 Inverse Point - Arc Description The direction, the distance and the coordinate differences between a known point and a given arc can be calculated depending on the data available for the known points. Points with full coordinate triplets, position only points and height only points can be used. Elements that must be known are •...
Page 815 Diagram Known P0 Start point P1 End point P2 Offset point Unknown P3 Base point Offset-XX ΔArcDist-XX GPS12_121 Access Refer to "38.2 Accessing COGO" to access COGO Inverse Pt - Arc Input. COGO Inverse Pt - Arc Input, CALC (F1) Input page To calculate COGO point.
Page 816 SURVY (F5) To manually occupy a point for the COGO calculation. Available if <Start Point:>, <Second Point:>, <End Point:> or <Offset Point:> is highlighted. SHIFT CONF (F2) To configure the COGO application program. SHIFT MODIF (F4) To mathematically modify the values. Available if <Radius:>, <Arc Length:>...
Page 817 Field Option Description <Start Point:> Choicelist The start point of the arc. All points from COGO Data: Job Name can be selected. Available for <Method: 3 Points> and <Method: 2 Points/Radius>. <Second Choicelist All points from COGO Data: Job Name can be Point:>...
Page 818 Field Option Description <Chord User input The length of the chord. Available for <Method: 2 Length:> Tgnts/Chrd Lngt>. <ΔArcDist- User input Horizontal distance along the arc from start point to Grid:> base point. <ΔOffset- User input Offset from base point to offset point. Positive to the Grid:>...
Page 819 COGO Inverse Pt - Arc Result, Result page STORE (F1) To store result and to return to COGO Inverse Pt - Line Input. COORD (F2) To view other coordinate types. PAGE (F6) To change to another page on this screen. SHIFT ELL H (F2) and SHIFT ORTH (F2) To change between the ellipsoidal and the orthometric height.
Page 820 Field Option Description <Arc Length:> Output Computed length of arc. Next step PAGE (F6) changes to the Plot page. COGO The functionality of the Plot page is similar to COGO Traverse Results, Plot page. Inverse Pt - Arc Result, Plot page Next step STORE (F1) stores the result and returns COGO Inverse Pt - Arc Input, Input page.
Page 821: Inverse Point - Current Position
38.4.4 Inverse Point - Current Position Description The direction, the distance and the coordinate differences between the two known points can be calculated depending on the data available for the known points. Points with full coordi- nate triplets, position only points and height only points can be used. Elements that must be known are •...
Page 822 COGO inverse calcula- The following table explains the most common settings. Refer to the stated chapter for more tion point - current posi- information on screens. tion step-by-step Step Description Refer to chapter Refer to "38.2 Accessing COGO" to access COGO Inverse. COGO Inverse Pt - Current Pos, Inverse page SHIFT CONF (F2) to configure the COGO application program.
Page 823 Step Description Refer to chapter The horizontal distance values which are displayed depend on the configuration for <Distance Type:> in COGO Configuration, Parameters page. ----- is displayed for unavailable information, for example if a position only point is used, <Δ Height:> cannot be calculated. <Azimuth:>...
Page 824 Step Description Refer to chapter The calculated distance between the known point and the current position is indicated. SHIFT QUIT (F6) does not store the calculated results and exits COGO calculation. STORE (F1) to store the result. For <Write Logfile: Yes> in COGO Configuration, Logfile page the result is written to the logfile.
Page 825: Cogo Calculation - Traverse Method
38.5 COGO Calculation - Traverse Method 38.5.1 Overview Description Elements that must be known are • the coordinates of one point. • the direction from the known point to the COGO point. • the distance from the known point to the COGO point. •...
Page 826 Diagram COGO traverse calculation with offset for a single point Known P0 Known point α Direction from P0 to P1 Distance between P0 and P1 Positive offset to the right Negative offset to the left Unknown P1 COGO point without offset P2 COGO point with positive offset P3 COGO point with negative offset GPS12_106...
Page 827 Unknown P1 First COGO point P2 Second COGO point P3 Third COGO point - sideshot P4 Fourth COGO point COGO GPS1200+...
Page 828: Traverse With Azimuth/Bearing
38.5.2 Traverse with Azimuth/Bearing COGO traverse calcula- The following table explains the most common settings. Refer to the stated chapter for more tion with information on screens. azimuth/bearing step- Step Description Refer to by-step chapter Refer to "38.2 Accessing COGO" to access COGO Traverse Input. COGO Traverse Input, Input page SHIFT CONF (F2) to configure the COGO application program.
Page 829 Step Description Refer to chapter <Offset:> Available for <Use Offsets: Yes> in COGO Configura- tion, Parameters page. The offset of the COGO point from the line of direction. A positive offset is to the right, a negative offset is to the left.
Page 830 Step Description Refer to chapter The values for the azimuth, the distance and the offset can be math- 38.13 ematically modified. SHIFT MODIF (F4) when <Azimuth:>, <HDist-XX:> or <Offset:> is highlighted. To add, subtract, multiply and divide values. Is the COGO point a foresight? •...
Page 831 Step Description Refer to chapter <Ortho Ht:> or <Local Ell Ht:> are input fields. The height of the known point used in the COGO calculation is suggested. A height value to be stored with the calculated point can be typed in. The calculated coordinates are displayed.
Page 832 Step Description Refer to chapter COGO Traverse Results, Plot page 33.6 An arrow points from the known point to the calculated COGO point. SHIFT QUIT (F6) does not store the COGO point and exits COGO calculations. STORE (F1) to store the result and return to COGO Traverse Input, Input page.
Page 833: Traverse With Angle Right
38.5.3 Traverse with Angle Right Access Refer to "38.2 Accessing COGO" to access COGO Traverse Input. COGO CALC (F1) Traverse Input, To calculate the COGO point. Input page INV (F2) To calculate the values for the distance and the offset from two existing points. Available if <HDist-XX:>...
Page 834 Description of fields Field Option Description <Method:> Angle Right The direction from the known point to the COGO point is an angle. <From:> Choicelist The point ID of the known point for the COGO calcu- lation. <Backsight:> Choicelist The point ID of a point used as backsight. <Angle Right:>...
Page 835: Cogo Calculation - Intersections Method
38.6 COGO Calculation - Intersections Method 38.6.1 Intersection with Bearing - Bearing Description The COGO intersection calculation bearing - bearing calculates the intersection point of two lines. A line is defined by a point and a direction. Elements that must be known are •...
Page 836 Diagram Known P0 First known point P1 Second known point α1 Direction from P0 to P2 α2 Direction from P1 to P2 Unknown P2 COGO point GPS12_064 COGO intersection The following table explains the most common settings. Refer to the stated chapter for more calculation with bearing information on screens.
Page 837 Step Description Refer to chapter Select the point stored in the job. SURVY (F5) when <1st Point:> is highlighted. To manually occupy 45.3 a point for the COGO calculation. For all point fields, the MapView interactive display on the Map page 33.5 can be used to select the desired point.
Page 838 Step Description Refer to chapter For <Write Logfile: Yes> in COGO Configuration, Logfile page the result of the COGO inverse calculation is written to the logfile. The values for the azimuth and the offset can be selected from 38.12 previous COGO inverse calculations. LAST (F4) when <Azimuth:>...
Page 839 Step Description Refer to chapter <Point ID:> The identifier for the COGO point depending on the point 19.1 ID template configured for <Survey Pts:> in CONFIGURE ID Templates. The point ID can be changed. <Ortho Ht:> or <Local Ell Ht:> are input fields. The height of the first point used in the COGO calculation is suggested.
Page 840 Step Description Refer to chapter Type in a code if required. PAGE (F6) changes to the Plot page. COGO Brng - Brng Results, Plot page 33.6 Arrows point from the known points to the calculated COGO point. SHIFT QUIT (F6) does not store the COGO point and exits COGO calculation.
Page 841: Intersection With Bearing - Distance
38.6.2 Intersection with Bearing - Distance Description The COGO intersection calculation bearing - distance calculates the intersection point of a line and a circle. The line is defined by a point and a direction. The circle is defined by the centre point and the radius.
Page 842 Diagram Known P0 First known point P1 Second known point α Direction from P0 to P2 Radius, as defined by the distance from P1 to Unknown P2 First COGO point P3 Second COGO point GPS12_065 COGO intersection The following table explains the most common settings. Refer to the stated chapter for more calculation with bearing information on screens.
Page 843 Step Description Two results are calculated. COGO Brng - Dist Results, Result1 page <Point ID:> The identifier for the first result of the COGO point 19.1 depending on the point ID template configured for <Survey Pts:> in CONFIGURE ID Templates. The point ID can be changed. <Ortho Ht:>...
Page 844 Step Description Pressing PAGE (F6) twice changes to the Plot page. 33.6 Both COGO points and known points are displayed. SHIFT QUIT (F6) does not store the COGO points and exits COGO calculations. RSLT1 (F3) or RSLT2 (F3) to view the first and second result. COGO Brng - Dist Results, Result1 page Is the first result to be stored? •...
Page 845 Step Description • If yes, repeat steps 1. to 7. 38.6.1, <Method:> in COGO Intersection Input, Input page can be 38.6.3 or changed. Refer to the relevant chapters for other COGO intersec- 38.6.4 tion calculation method than <Method: Brng - Dist>. •...
Page 846: Intersection With Distance - Distance
38.6.3 Intersection with Distance - Distance Description The COGO intersection calculation distance - distance calculates the intersection point of two circles. The circles are defined by the known point as the centre point and the distance from the known point to the COGO point as the radius. Elements that must be known are •...
Page 847 Diagram Known P0 First known point P1 Second known point Radius, as defined by the distance from P0 to Radius, as defined by the distance from P1 to Unknown P2 First COGO point P3 Second COGO point GPS12_066 COGO intersection The following table explains the most common settings.
Page 848 Step Description Refer to chapter • <Offset:> is unavailable. The remaining procedure is identical to a COGO intersection calcula- tion with bearing - distance. The screen is called COGO Dist - Dist Results. Follow the steps 2. to 8. in paragraph "COGO intersection calculation 38.6.2 with bearing - distance step-by-step".
Page 849: Intersection With By Points
38.6.4 Intersection with By Points Description The COGO intersection calculation by points calculates the intersection point of two lines. A line is defined by two points. Elements that must be known are • the coordinates of four points. • offsets of the lines if required and configured. The coordinates of the known points •...
Page 850 Diagram Known P0 First known point P1 Second known point P2 Third known point P3 Fourth known point Line from P0 to P1 Line from P2 to P3 Unknown P4 COGO point GPS12_107 COGO intersection The following table explains the most common settings. Refer to the stated chapter for more calculation with by information on screens.
Page 851 Step Description Refer to chapter <1st Point:> The point ID of the known start point of the first line for the COGO calculation. <2nd Point:> The point ID of the known end point of the first line for the COGO calculation. Select the points stored in the job.
Page 852 Step Description Refer to chapter Upon pressing STORE (F1) in COGO Inverse, the result from the COGO inverse calculation is copied to the field which was highlighted when INV (F2) was pressed. For <Write Logfile: Yes> in COGO Configuration, Logfile page the result of the COGO inverse calculation is written to the logfile.
Page 853 Step Description Refer to chapter The remaining procedure is identical to a COGO intersection calcula- tion with bearing - bearing. The screen is called COGO By Points Results. On the Plot page two solid lines are displayed. Follow the steps 5. to 13. in paragraph "COGO intersection calcula- 38.6.1 tion with bearing - bearing step-by-step".
Page 854: Intersection With Tps Observation - Tps Observation
38.6.5 Intersection with TPS Observation - TPS Observation Description The COGO intersection calculation TPS observation - TPS observation calculates the inter- section point of two lines. A line is defined by a TPS station and a TPS measurement from this station. Elements that must be known are •...
Page 855 Diagram Known P0 First known point (TPS station) P1 Second known point (TPS station) α1 Direction from P0 to P2 α2 Direction from P1 to P2 Unknown P2 COGO point GPS12_170 COGO intersection The following table explains the most common settings. Refer to the stated chapter calculation with TPS for more information on screens.
Page 856 Step Description Refer to chapter <TPS Measmnt:> The point ID of the TPS measurement which is the known end point of the first line for the COGO calculation. <Azimuth:> The azimuth related to the known end point of the first line for the COGO calculation.
Page 857 Step Description Refer to chapter LAST (F4) when <Azimuth:> is highlighted. To recall previous results from COGO inverse calculations. Upon pressing CONT (F1) in COGO Last Inverse Calculations, the selected result is copied to the field. COGO GPS1200+...
Page 858: Cogo Calculation - Line Calculations Method
38.7 COGO Calculation - Line Calculations Method 38.7.1 Line Calculation - Base Point Description The COGO line calculation base point calculates the base point, station and offset of a point in relation to a line. Elements that must be known are •...
Page 859 Diagram P0 <Start Point:> P1 <End Point:> P2 <Offset Point:> P3 Base point <Offset-XX:> GPS12_119 <ΔLine-XX:> Line management is not available for COGO line calculations. Access Refer to "38.2 Accessing COGO" to access COGO Line Calculations Input. COGO Line Calculations Input, Input page CALC (F1) To calculate COGO point.
Page 860 SURVY (F5) To manually occupy a point for the COGO calculation. Available if <Start Point:> or <End Point:> is highlighted. SHIFT CONF (F2) To configure the COGO application program. SHIFT MODIF (F4) To mathematically modify the values. Available if <Azimuth:>, <ΔLine-XX:> or <HDist-XX:> is highlighted.
Page 861 Field Option Description <End Point:> Choicelist Available for <Method: 2 Points>. The end point of the line. All points from COGO Data: Job Name can be selected. <Azimuth:> User input Available for <Method: Pt/Brg/Dist>. The azimuth of the line. <HDist-XX:> User input Available for <Method: Pt/Brg/Dist>.
Page 862 Next step THEN <Task: Calc Base CALC (F1) accesses COGO Base Point Results. Refer to para- Point> graph "COGO XX Point Results, Result page". <Task: Calc Offset CALC (F1) accesses COGO Offset Point Results. Refer to para- Point> graph "COGO XX Point Results, Result page". <Task: Segmenta- CALC (F1) accesses COGO Define Segmentation.
Page 863 SHIFT INDIV (F5) and SHIFT RUN (F5) To change between entering an individual point ID different to the defined ID template and the running point ID according to the ID template. Refer to "19.1 ID Templates". Description of fields Field Option Description <Point ID:>...
Page 864 Next step PAGE (F6) changes to the Code page. COGO The functionality of the Code page is similar to COGO Traverse Result, Code page. XX Point Results, Code page Next step PAGE (F6) changes to the Plot page. COGO The functionality of the Plot page is similar to COGO Traverse Results, Plot page. XX Point Results, Plot page Next step...
Page 865: Line Calculation - Offset Point
38.7.2 Line Calculation - Offset Point Description The COGO line calculation offset point calculates the coordinates of a new point after input of station and offset values in relation to a line. Elements that must be known are • coordinates of two points. •...
Page 866 Step Description Refer to chapter COGO Line Calculations Input, Input page SHIFT CONF (F2) to configure the COGO application program. 38.3 COGO Line Calculations Input, Input page 38.7.1 <Task: Calc Offset Point> CALC (F1) calculates the results. COGO Offset Point Results, Result page 38.7.1 STORE (F1) stores the results.
Page 867: Line Calculation - Segmentation
38.7.3 Line Calculation - Segmentation Description The COGO line calculation segmentation calculates the coordinates of new points on a line. Elements that must be known are • coordinates of the start and the end point of the line • a bearing and distance from a known point that define the line AND EITHER •...
Page 868 Line divided by <Method: Segment Length> P0 <Start Point:> P1 <End Point:> GPS12_145 <Seg Length:> Remaining segment COGO line calculation The following table explains the most common settings. Refer to the stated chapter for more segmentation step-by- information on screens. step Step Description...
Page 869 Step Description Refer to chapter <No. of Segs:> For <Method: No. of Segments> type in the number of segments for the line. For <Method: Segment Length> type in the segment length for the line. A remaining segment may result from this method.
Page 870 Step Description Refer to chapter <Last Segment Lgth:> Available for <Method: Segment Length>. The length of the remaining segment. STAKE (F5) to access the Stakeout application program and stake out the calculated COGO point. SHIFT QUIT (F6) or ESC return to COGO Segmentation Results, Result page.
Page 871: Cogo Calculation - Arc Calculations Method
38.8 COGO Calculation - Arc Calculations Method 38.8.1 Arc Calculation - Arc Center Description The COGO arc calculation arc center calculates the coordinates of the centre of the arc. Elements that must be known are • coordinates of three points •...
Page 872 Access Refer to "38.2 Accessing COGO" to access COGO Arc Calculations Input. COGO The softkeys are similar to line calculation. Refer to "38.7.1 Line Calculation - Base Point" for Arc Calculations Input, information on softkeys. Input page Description of fields Field Option Description...
Page 873 Field Option Description 2 Tgnts/Chrd Lngt Defines the arc using two tangents and the chord of the arc. <Start Point:> Choicelist The start point of the arc. All points from COGO Data: Job Name can be selected. Available for <Method: 3 Points>...
Page 874 Field Option Description <Arc Length:> User input The length of the arc. Available for <Method: 2 Tgnts/Arc Lngt>. <Chord User input The length of the chord. Available for <Method: 2 Length:> Tgnts/Chrd Lngt>. <ΔArcDist- User input Horizontal distance along the arc from start point to XX:>...
Page 875 COGO Refer to paragraph "38.7.1 Line Calculation - Base Point" for information on softkeys. XX Results, Result page Description of fields Field Option Description <Point ID:> User input The identifier for the COGO point depending on the point ID template configured for <Survey Pts:> in CONFIGURE ID Templates.
Page 876 Next step PAGE (F6) changes to the Code page. COGO The functionality of the Code page is similar to COGO Traverse Results, Code page. XX Results, Code page Next step PAGE (F6) changes to the Plot page. COGO The functionality of the Plot page is similar to COGO Traverse Results, Plot page. XX Results, Plot page Next step...
Page 877: Arc Calculation - Base Point
38.8.2 Arc Calculation - Base Point Description The COGO arc calculation base point calculates the coordinates of the base point, station and offset of a point in relation to an arc. Elements that must be known are • coordinates of three points •...
Page 878 Diagram P0 <Start Point:> P1 <End Point:> P2 <Offset Point:> P3 Base point <ΔOffset-XX:> <ΔArcDist-XX:> GPS12_121 Arc management is not available for COGO arc calculations. COGO arc calculation The following table explains the most common settings. Refer to the stated chapter for more base point step-by-step information on screens.
Page 879 Step Description Refer to chapter CALC (F1) calculates the results. COGO Base Point Results, Result page 38.8.1 STORE (F1) stores the results. COGO GPS1200+...
Page 880: Arc Calculation - Offset Point
38.8.3 Arc Calculation - Offset Point Description The COGO arc calculation offset point calculates the coordinates of a new point after input of arc and offset values in relation to an arc. Elements that must be known are • coordinates of three points. •...
Page 881 Step Description Refer to chapter COGO Arc Calculations Input, Input page. SHIFT CONF (F2) to configure the COGO application program. 38.3 COGO Arc Calculations Input, Input page. 38.8.1 <Task: Calc Offset Point> CALC (F1) calculates the results. COGO Offset Point Results, Result page 38.8.1 STORE (F1) stores the results.
Page 882: Arc Calculation - Segmentation
38.8.4 Arc Calculation - Segmentation The COGO arc calculation segmentation and the functionality of all screens and fields are similar to those for COGO line calculation segmentation. Refer to "38.7.3 Line Calculation - Segmentation". Exceptions to line New field and option in COGO Define Segmentation calculation segmenta- Field Option...
Page 883: Cogo Calculation - Shift, Rotate & Scale (Manual) Method
38.9 COGO Calculation - Shift, Rotate & Scale (Manual) Method Description The COGO calculation shift, rotate & scale (manual) applies shifts and/or rotation and/or scale to one or several known points. The values for shifts and/or rotation and/or scale are typed in manually.
Page 884 Diagram P1’ P2’ Shift Height Easting P1 Known point P1’ Shifted point P2 Known point P2’ Shifted point GPS12_155 Rotation Height Easting P0 <Rotation Pt:> P1’ P1 Known point P2’ P1’ Rotated point P2 Known point P2’ Rotated point GPS12_156 COGO GPS1200+...
Page 885 Scale Height Easting P1 <Rotation Pt:>, can be held fixed, all other points are then scaled from here P4’ P5’ P2 Known point P2’ Scaled point P3 Known point P3’ Scaled point P4 Known point P4’ Scaled point P2’ P3’ P5 Known point P5’...
Page 886 COGO Listed are points which have been selected for shifting, rotating and/or scaling. Shift, Rotate & Scale, Points page CALC (F1) To perform the shift, rotation and scale calcula- tion and to continue with the subsequent screen. Calculated COGO points are not yet stored.
Page 887 PAGE (F6) To change to another page on this screen. SHIFT REM A (F4) To remove all points from the list. The points itself are not deleted. SHIFT RANGE (F5) To define a range of points from the active job to be added to the list.
Page 888 COGO Select Points by Range CONT (F1) To add the points within the selected range to the list in COGO Shift, Rotate & Scale, Points page and to return to the screen from where this screen was accessed. NEXT (F3) To add the points within the selected range to the list in COGO Shift, Rotate &...
Page 889 Field Option Description • Alphanumeric point ID’s in both fields: The left most character of both entries is used as the basis for the range. The standard ASCII numerical range is used. Points with alphanumeric point ID’s falling within the range are selected. Example: <From Pt ID: a9>, <To Pt ID: c200>...
Page 890 COGO Shift, Rotate & Scale, Shift page CALC (F1) To perform the shift, rotation and scale calcula- tion and to continue with the subsequent screen. Calculated COGO points are not yet stored. INV (F2) To calculate the amount of shift in Easting, Northing and height from two existing points.
Page 891 SHIFT MODIF (F4) To mathematically modify the values. Available if <Δ Easting:>, <Δ Northing:> or <Δ Height:> is highlighted. Description of fields Field Option Description <Method:> The method by which the shift in Δ Easting, Δ Northing and Δ Height will be determined. Enter ΔE,ΔN,ΔHt Defines the shift using coordinate differences.
Page 892 Field Option Description <Δ Northing:> User input or output The amount of shift in North direction. <Δ Height:> User input or output The amount of shift in height. Next step PAGE (F6) accesses COGO Shift, Rotate & Scale, Rotate page. Refer to "COGO Shift, Rotate &...
Page 893 Field Option Description <Rotation:> User input or output The amount by which the points will be rotated. Next step PAGE (F6) accesses COGO Shift, Rotate & Scale, Scale page. Refer to "COGO Shift, Rotate & Scale, Scale page". COGO The softkeys are the same as on the Shift page. Refer to paragraph "COGO Shift, Rotate & Shift, Rotate &...
Page 894 Field Option Description <Scale From Scaling is performed by multiplying the original coor- Pt:> dinates of the points by <Scale:>. <Scale:> is applied to the coordinate difference of all points relative to <Rotation Pt:> selected on the Rotation page. The coordinates of <Rotation Pt:> will not change.
Page 895 Description of fields Field Option Description <Pts Output The number of selected points having been shifted, Selected:> rotated and/or scaled. <Store Job:> Choicelist The calculated COGO points will be stored in this job. All jobs from Main Menu: Manage...\Jobs can be selected.
Page 896 THEN the calculated COGO PAGE (F6) accesses COGO Shift, Rotate & Scale Store, Plot points are to be page. Original points are displayed in grey, calculated COGO points viewed graphically are displayed in black. the calculated COGO STORE (F1) accesses COGO Shift, Rotate & Scale Results, points are to be Result page.
Page 897: Cogo Calculation - Shift, Rotate & Scale (Match Pts) Method
38.10 COGO Calculation - Shift, Rotate & Scale (Match Pts) Method Description The COGO calculation shift, rotate & scale (match pts) applies shifts and/or rotation and/or scale to one or several known points. The shifts and/or rotation and/or scale are calculated from selected points using a 2D Helmert tranformation.
Page 898 Access Refer to "38.2 Accessing COGO" to access COGO Match Common Points (n). COGO This screen provides a list of points chosen from the active job. The points are used for the Match Common Points determination of the 2D Helmert transformation. The number of points matched is indicated in the title, for example COGO Match Common Points (3).
Page 899 RESID (F6) To display a list of the matched points used in the transformation calculation and their associ- ated residuals. Refer to paragraph "Fix param- eters". SHIFT PARAM (F5) To define the parameters to be used in the 2D transformation. Description of columns Column Description...
Page 900 Next step THEN the transformation is CALC (F1). The calculated shift, rotation and scale values are to be computed displayed in COGO Shift, Rotate & Scale. They cannot be edited. The remaining functionality of the calculation is very similar to COGO calculation shift, rotate &...
Page 901 Step Description <Match Type:> The type of match to be made between the points selected in <Source Pt:> and <Target Pt:>. Position & Height, Position Only, Height Only or None. Select the points to be matched. SURVY (F5). To manually occupy a point and store it in the active job. CONT (F1) returns to COGO Match Common Points (n) and adds a new pair of matched points to the matched points list.
Page 902 Next step THEN a field displays the parameter highlight the field. Enter the value of the parameter. ----- needs to be fixed to FIX (F4). a value a field displays the parameter highlight the field. ADJST (F4). a value needs to be calcu- lated all parameters CONT (F1) to return to COGO Match Common...
Page 903: Cogo Calculation - Area Division
38.11 COGO Calculation - Area Division 38.11.1 Overview Description The COGO calculation area division divides an area by a defined line, by percentage or by the size of a subarea. The area division methods are listed in the table below. Elements that must be known for the calculation depend on the area division method.
Page 904 Divide by Using Elements required Swing line Rotation point • Size of new area in percentage • Rotation point of the swing line Area Parallel line • Size of new area • Two points defining the line Perpendicular line • Size of new area •...
Page 905 P0 <Point A:> of defined line P1 <Point B:> of defined line P2 First new COGO point P3 Second new COGO point <HDist-XX:> GPS12_160 Area division method <Divide:> <Using:> <Shift:> By Defined Line Perpendic Line By Distance By Percentage Perpendic Line By Area Perpendic Line COGO...
Page 906 P0 <Point A:> of defined line P1 <Point B:> of defined line P2 First new COGO point P3 Second new COGO point <HDist-XX:> GPS12_161 Area division method <Divide:> <Using:> <Shift:> By Defined Line Parallel Line Through Point COGO GPS1200+...
Page 907 P0 <Point A:> of defined line P1 <Point B:> of defined line P2 <Through Point:>; in this case it is a known point of the existing border P3 New COGO point <HDist-XX:> GPS12_164 Area division method <Divide:> <Using:> <Shift:> By Defined Line Perpendic Line Through Point COGO...
Page 908 P0 <Point A:> of defined line P1 <Point B:> of defined line P2 <Through Point:>; in this case it is a known point of the existing border P3 New COGO point <HDist-XX:> GPS12_165 Area division method <Divide:> <Using:> <Shift:> By Percentage Swing Line By Area Swing Line...
Page 909 P0 First new COGO point P1 Second new COGO point P2 <Rotation Pnt:> α <Azimuth:> GPS12_163 COGO GPS1200+...
Page 910: Choosing An Area To Be Divided
38.11.2 Choosing an Area to be Divided Access Refer to "38.2 Accessing COGO" to access COGO Choose Area to be Divided. COGO Choose Area to be Divided CONT (F1) To accept the changes and access the subse- quent screen. Description of fields Field Option Description...
Page 911 Field Option Description Survey New Area To survey points that do not exist in the job yet. The points will be added to a new area. <Area ID:> Choicelist For <Area to Use: Select Existing>. To select the area to be divided. User input For <Area to Use: Survey New Area>.
Page 912 COGO Points to be added to the new area can be surveyed. Survey: Job Name, Survey page OCUPY (F1) To start measuring the point to be added to the area. The position mode icon changes to the static icon. (F1) changes to STOP. STOP (F1) To end measuring the point.
Page 913 SHIFT INIT (F2) To select an initialisation method and to force a new initialisation. Available for configuration sets allowing phase fixed solutions. Refer to "45.6 Initialisation for Real-Time Rover Opera- tions". SHIFT INDIV (F5) and SHIFT RUN (F5) To change between entering an individual point ID different to the defined ID template and the running point ID according to the ID template.
Page 914 Field Option Description <Antenna Ht:> User input The default antenna height as defined in the active configuration set is suggested. Refer to "2 Antenna Heights". Changing the antenna height here does not update the default antenna height as defined in the active configuration set.
Page 915: Dividing An Area
38.11.3 Dividing an Area Access Refer to "38.11.2 Choosing an Area to be Divided" to access COGO Define How to Divide Area. COGO After each change of parameters in this screen, the values in the output fields are recalcu- Define How to Divide lated and updated.
Page 916 SHIFT CONF (F2) To configure the COGO application program. Description of fields Field Option Description <Divide By:> This field defines how the size of the sub area is defined. Percentage The size of the sub area is given in %. Area The size of the sub area is given in m Defined Line...
Page 917 Field Option Description When dividing the area using a parallel or perpendicular line, a reference line is defined by <Point A:> and <Point B:>. The direction of the new dividing line is always the same as the direction of the reference line. The sub area is always to the left of the new dividing line.
Page 918 Field Option Description <Rotation Choicelist Available for <Using: Swing Line>. The point around Pnt:> which the new border will rotate by <Azimuth:>. <Azimuth:> Output Available for <Using: Swing Line>. The angle of the new border from <Rotation Pnt:> to the new COGO point.
Page 919: Results Of The Area Division
38.11.4 Results of the Area Division Access CALC (F1) in COGO Define How to Divide Area. COGO Results of Area Divi- sion, Result page CONT (F1) To accept the calculation and to continue with the subsequent screen. Calculated COGO points are not yet stored. PAGE (F6) To change to another page on this screen.
Page 920 COGO The points defining the area and the calculated COGO points are shown in black. Results of Area Divi- sion, Next step Map page CONT (F1) accesses COGO Area Division Results. COGO The coordinates of the intersection points of the new border with the original area are Area Division Results, displayed.
Page 921 Description of fields Field Option Description <Point ID:> User input The identifier for the COGO point depending on the point ID template configured for <Survey Pts:> in CONFIGURE ID Templates. <Ortho Ht:> or User input A height value to be stored with the calculated point <Local Ell Ht:>...
Page 922: Working Example
38.11.5 Working Example Description Application: Divide an area by a defined, parallel line. The new border has to run through a known point with the point ID 100. Working technique: Real-time kinematic. Goal: The points forming the original area are to be picked. The area division is to be calculated.
Page 923 Field procedure step- Step Description by-step Main Menu: Programs...\COGO COGO COGO Begin Select a job and a configuration set with the settings mentioned above. CONF (F2) to configure the COGO application program. CONT (F1) to access COGO COGO Menu. Highlight Area Division. CONT (F1) to access COGO Choose Area to be Divided.
Page 924 Step Description <Divide By: Defined Line> <Using: Parallel Line> <Point A:> and <Point B:> Select the first and the second point of the line which is used as the reference for the new border. The new border will run parallel to this line.
Page 925 Step Description STAKE (F5) to access the Stakeout application program and stake out the calcu- lated COGO point. SHIFT ELL H (F2) and SHIFT ORTH (F2). Available for local coordinates. Changes between the ellipsoidal and the orthometric height. SHIFT INDIV (F5) for an individual point ID independent of the ID template. SHIFT RUN (F5) changes back to the next ID from the configured ID template.
Page 926: Selecting A Result From Previous Cogo Inverse Calculations
38.12 Selecting a Result from Previous COGO Inverse Calculations Description Azimuths, distances and offsets required within the COGO traverse and intersection calcu- lations can be selected from previously calculated inverse results. Select a result from Step Description previous COGO inverse Refer to "38.2 Accessing COGO"...
Page 927 Step Description HDist-XX: The horizontal distance between the two known points. Date and Time when the COGO inverse calculation was stored. VIEW (F3) to view all calculated values for the highlighted COGO inverse calcula- tion. This includes the height difference, the slope distance, the grade and the coordinate differences between the two known points.
Page 928: Modifying Values For Azimuths, Distances And Offsets
38.13 Modifying Values for Azimuths, Distances and Offsets Description The values for the azimuth, the distance and the offset required within the COGO traverse and intersection calculation can be mathematically modified. Access step-by-step Step Description Refer to "38.2 Accessing COGO" to access COGO Traverse Input or COGO Intersection Input.
Page 929 CONT (F1) To accept the modified value and to return to the screen from where this screen was accessed. The modified value is copied into the field which was initially highlighted in COGO XX Input, Input page. Description of fields Field Option Description...
Page 930 Field Option Description • Maximum: 3000 • ----- performs a division by 1. <Add:> User input The number to be added. • For azimuths Minimum: 0 Maximum: Full circle • For distances and offsets Minimum: 0 m Maximum: 30000000 m •...
Page 931 Next step CONT (F1) accepts the modified value and returns to the screen from where this screen was accessed. Example: Calculations Step User input Value as calculated Value as displayed for an azimuth <Azimuth: 250.0000> g <Multiply: 2> <Azimuth: 100.0000> g <Divide: 3>...
Page 932: Determine Coordinate System - General
Determine Coordinate System - General 39.1 Overview Description GPS measured points are always stored based on the global geocentric datum known as WGS 1984. Most surveys require coordinates in a local grid system, for example, based on a country’s official mapping datum or an arbitrary grid system used in a particular area such as a construction site.
Page 933 Transformation parameters A transformation consists of a number of shifts, rotations and scale factors, depending on the type of transformation used. Not all of these parameters are always required. These param- eters may already be known, or may need to be computed. Description of transformations Three different transformations are provided: •...
Page 934 Transformation Characteristic Description Requirements • The positions and heights are known in WGS 1984 and in the local system for at least three points. Four points or more are recom- mended in order to obtain higher redundancy. • Parameters of the local ellipsoid. •...
Page 935 Transformation Characteristic Description Onestep Principle Transforms coordinates directly from WGS 1984 to local grid and vice versa without knowledge about the local ellipsoid or the map projection. Procedure: 1. The WGS 1984 coordinates are projected onto a temporary Transverse Mercator projection. The central meridian of this projection passes through the centre of gravity of the common control points.
Page 936 Transformation Characteristic Description A site where the coordinates of the control points are based on a purely local grid. The coordinate values within this grid are totally arbitrary and are in no way connected with any ellipsoid or map projection. Obvi- ously a Classic 3D transformation cannot be used here, as cartesian coordinates cannot be calculated from such a grid.
Page 937 Transformation Characteristic Description Points and trans- The transformation parameters determined depend formation parame- on the number of available points with position infor- ters mation. • One point: Classic 2D with shift in X and Y. • Two points: Classic 2D with shift in X and Y, rota- tion about Z and scale.
Page 938 Transformation Characteristic Description Advantage • Errors in height do not propagate into errors in position since the height and position transforma- tions are separated. • If local heights have low accuracy or do not exist, a transformation of position can still be calculated and vice versa.
Page 939 Transformation Characteristic Description Twostep Principle Combines the advantages of the Onestep and the Classic 3D transformation. It allows treating position and height separately, but is not restricted to smaller areas. Procedure: 1. The WGS 1984 coordinates of the common control points are shifted closely to the local datum using a given Classic 3D pre-transforma- tion.
Page 940 Transformation Characteristic Description • Parameters of a pre-transformation. Area Virtually any area as long as the local coordinates are accurate. Points and trans- Identical with the Onestep transformation. formation parame- ters Points and height Identical with the Onestep transformation. transformation Advantage •...
Page 941 Transformation Characteristic Description The first step of a Twostep transformation avoids any distortions due to the fact that the preliminary grid coordinates are built on a different ellipsoid than the local points. The second step ensures that the influence of the scale factor of the map projection is equally taken into account before the final 2D transformation is computed.
Page 942 calculated. Depending on the type of transformation used, details about the map projection, the local ellipsoid and a local geoidal model may also be needed. Requirements for • The control points used for the transformation should surround the area for which the control points transformation is to be applied.
Page 943 Coordinate system deter- Characteristic Description mination method Transformation to use • Onestep or Twostep when information about the necessary rotations and scale factor is known. • Classic 3D when the rota- tions are to be set to zero and the scale factor to one.
Page 944: Accessing Determine Coordinate System
39.2 Accessing Determine Coordinate System Access Select Main Menu: Programs...\Determine Coordinate System. Press PROG. Highlight Determine Coordinate System. CONT (F1). Refer to "37.2 Accessing the Application Programs Menu" for information on the PROG key. Press a hot key configured to access the screen DET C SYS Determine Coord System Begin.
Page 945 Description of fields Field Option Description <Name:> User input A unique name for the coordinate system. The name may be up to 16 characters in length and may include spaces. Input is mandatory. Entering the name of a coordinate system will allow that existing system to be updated.
Page 946 Next step THEN <Method: the DET C SYS CONF (F2) to access DET C SYS Configuration. Normal> application Refer to "39.3.1 Configuring Determine Coordinate program needs System - Normal". configuring <Method: One the DET C SYS CONF (F2) to access DET C SYS Configuration. Pt Localistn>...
Page 947: Configuring Determine Coordinate System
39.3 Configuring Determine Coordinate System 39.3.1 Configuring Determine Coordinate System - Normal Description The configuration of DET C SYS, normal method, allows options to be set which are used as the default options within the Determine Coordinate System application program when using the normal method.
Page 948 CONT (F1) To accept changes and return to the screen from where this screen was accessed. FIX (F4) or ADJST (F4) Available for Classic 3D page unless <Transf Model:> is highlighted. To define which parameters are computed or fixed in the Classic 3D transformation.
Page 949 Field Option Description <Default Orthometric or The default height type to be used when determining Height Mode:> Ellipsoidal the coordinate system. <Default Pos & Height, Pos Options available depend on the choice made for Match:> Only, Height Only <Default Transformation:>. Point parameters to be or <None>...
Page 950 Field Option Description 1/Distance Distributes the residuals according to the distance between each control point and the newly trans- formed point. Multiquadratic Distributes the residuals using a multiquadratic inter- polation approach. Next step PAGE (F6) changes to the Classic 3D page. Refer to paragraph "DET C SYS Configuration, Classic 3D page".
Page 951 Description of fields Field Option Description <Transf Bursa Wolf or The transformation model to be used. Refer to Model:> Molodensky-Bad standard surveying literature for details on the models. <Shift dX:> User input Shift in X direction. <Shift dY:> User input Shift in Y direction.
Page 952 THEN all parameters CONT (F1) to return to DET C SYS Determine are configured Coord System Begin. Determine Coordinate System - General GPS1200+...
Page 953: Configuring Determine Coordinate System - One Point Localisation
39.3.2 Configuring Determine Coordinate System - One Point Localisation Description The configuration of DET C SYS, one point localisation method, allows options to be set which are used as the default options within the Determine Coordinate System application program when using the one point localisation method. These settings are stored within the active configuration set.
Page 954 CONT (F1) To accept changes and return to the screen from where this screen was accessed. PAGE (F6) To change to another page on this screen. Description of fields Field Option Description <Default Normal or One Pt Method used to determine the coordinate system. Method:>...
Page 955 Field Option Description <Default Orthometric or The default height mode to be used when deter- Height Mode:> Ellipsoidal mining the coordinate system. Next step PAGE (F6) changes to the Onestep page. Refer to paragraph "DET C SYS Configuration, Onestep page". DET C SYS Description of fields Configuration,...
Page 956 Field Option Description User Entered Height scale factor can be manually typed in. Known WGS84 Pt Height scale factor defined by a known point on the WGS 1984 datum. Known WGS84 Ht Height scale factor defined by the known height of a point on the WGS 1984 datum.
Page 957 Field Option Description Two WGS84 Rotation defined by two points on the WGS 1984 Points datum. Refer to "41.2 Determine Coordinate System - Onestep Transformation" paragraph "DET C SYS Step 4: Determine Rotation" for a diagram. <Default The default method for determining the scale factor to Scale:>...
Page 958 Next step CONT (F1) returns to DET C SYS Determine Coord System Begin. Determine Coordinate System - General GPS1200+...
Page 959: Determine Coordinate System - Normal
Determine Coordinate System - Normal 40.1 Overview Description The Determine Coordinate System application program allows a new coordinate system to be determined or a coordinate system to be updated. The coordinate system is defined by the transformation used to convert coordinates from one geodetic datum to another. Onestep, Twostep or Classic 3D transformations are available.
Page 960: Determining A New Coordinate System
40.2 Determining a New Coordinate System Access step-by-step Step Description Refer to "39.2 Accessing Determine Coordinate System" to access DET C SYS Determine Coord System Begin. Select <Method: Normal>. CONT (F1) to access DET C SYS Step 1: Choose Transform Type. DET C SYS Step 1: Choose Trans- form Type...
Page 961 Description of fields Field Option Description <Transfrm User input A unique name for the transformation. The name may Name:> be up to 16 characters in length and may include spaces. If a coordinate system is being updated then its name is displayed. <Transfrm The type of transformation to be used when deter- Type:>...
Page 962 If a coordinate system was chosen to be edited in DET C SYS Determine Coord System Begin, pressing CONT (F1) accesses DET C SYS Step 3: Match Points (n). Pressing ESC does not re-access DET C SYS Determine Coord System Begin but accesses DET C SYS Step 2: Choose Parameters and DET C SYS Step 1: Choose Transform Type.
Page 963 For <Transfrm Type: Twostep> Description of fields Field Option Description <Pre Trans- Choicelist The pre-transformation to use for the preliminary 3D form:> transformation. All 3D transformations from MANAGE Transformations can be selected. <Ellipsoid:> Choicelist The ellipsoid to use in the transformation. All ellip- soids from MANAGE Ellipsoids can be selected.
Page 964 Field Option Description Output The ellipsoid being used by a fixed projection when selected in <Projection:>. <Projection:> Choicelist The projection to use in the transformation. All projec- tions from MANAGE Projections can be selected. <Geoid Choicelist The geoid model to use in the transformation. Geoid Model:>...
Page 965 CALC (F1) To confirm the selections, compute the trans- formation and continue with the subsequent screen. NEW (F2) To match a new pair of points. This pair is added to the list. A new point can be manually occupied. Refer to "40.4.2 Selecting a New Pair of Matching Points".
Page 966 SHIFT PARAM (F5) To configure Classic 3D transformation parameters for <Transfrm Type: Classic 3D> or 2D & Height transformation parameters for <Transfrm Type: Onestep> and <Transfrm Type: Twostep> in DET C SYS Step 1: Choose Transform Type. Refer to "39.3.1 Configuring Determine Coordinate System - Normal"...
Page 967 Next step CALC (F1) computes the transformation and continues to DET C SYS Step 4: Check Resid- uals. Refer to paragraph "DET C SYS Step 4: Check Residuals". If a coordinate system to be updated contains a point that was deleted from the active job and a new point was created in that job with the same point ID but different coordinates, the coordinates of the old point will still be used for the calculation.
Page 968 Description of columns Column Description WGS84 Pts The point ID of the points chosen from <WGS84 Pts Job:>. East The Easting residual. If positions were not used in the transformation calculation then ----- will be displayed. North The Northing residual. If positions were not used in the transformation calculation then ----- will be displayed.
Page 969 DET C SYS This screen consists of the Summary page and the Coord System page. The Coord Step 5: Store Coord System page contains different fields, depending on what transformation type was chosen System, in DET C SYS Step 1: Choose Transform Type. The explanations for the softkeys given Summary page below are valid for all pages.
Page 970 Field Option Description <Matched Output Number of matched points, as defined in DET C SYS Pts:> Step 3: Match Points (n). <Easting:> Output Largest Easting residual from the transformation calculation. <Northing:> Output Largest Northing residual from the transformation calculation. <Height:> Output Largest Height residual from the transformation calculation.
Page 971 For <Transfrm Type: Twostep> Description of fields Field Option Description <Residuals:> None, The method by which the residuals of the control 1/Distance points will be distributed throughout the transforma- Multiquadratic tion area. Refer to "39.3.1 Configuring Determine Coordinate System - Normal" paragraph "DET C SYS Configuration, Residuals page".
Page 972 For <Transfrm Type: Classic 3D> Description of fields Field Option Description <Residuals:> None, The method by which the residuals of the control 1/Distance points will be distributed throughout the transforma- Multiquadratic tion area. Refer to "39.3.1 Configuring Determine Coordinate System - Normal" paragraph "DET C SYS Configuration, Residuals page".
Page 973: Updating A Coordinate System
40.3 Updating a Coordinate System Access step-by-step Step Description Refer to "39.2 Accessing Determine Coordinate System" to access DET C SYS Determine Coord System Begin. Select <Method: Normal>. Enter the name of a coordinate system in <Name:>. CSYS (F6) to select a coordinate system. CONT (F1) to access DET C SYS Step 3: Match Points (n).
Page 974: Matching Points
40.4 Matching Points 40.4.1 Overview Description Before calculating a transformation, it must be defined which points in <WGS84 Pts Job:> and <Local Pts Job:> are to be matched. Pairs of matched points are displayed in one line in DET C SYS Step 3: Match Points (n). New pairs of matched points can be created, existing pairs of matched points can be edited and pairs of matched points can be deleted.
Page 975: Selecting A New Pair Of Matching Points
40.4.2 Selecting a New Pair of Matching Points Match points step-by- Step Description step Refer to "40.2 Determining a New Coordinate System" to access DET C SYS Step 3: Match Points (n). NEW (F2) to access DET C SYS Choose Matching Points. DET C SYS Choose Matching Points <WGS84 Point:>...
Page 976: Editing A Pair Of Matching Points
40.4.3 Editing a Pair of Matching Points Edit matching points Step Description step-by-step Refer to "40.2 Determining a New Coordinate System" to access DET C SYS Step 3: Match Points (n). DET C SYS Step 3: Match Points (n) Highlight the pair of matching points to be edited. EDIT (F3) to access DET C SYS Edit Matching Points.
Page 977: Transformation Results
40.5 Transformation Results 40.5.1 Accessing Transformation Results Access step-by-step Step Description The results of a transformation can be displayed during the process of determining or updating a coordinate system. Refer to "40.2 Determining a New Coordinate System". Follow the instructions to access DET C SYS Step 4: Check Residuals.
Page 978: Results For Onestep And Twostep Transformations
40.5.2 Results for Onestep and Twostep Transformations DET C SYS Results of the transformation between the WGS 1984 datum and the local datum are shown Transformation for each of the transformation parameters. This screen consists of the Position page and Results, the Height page.
Page 979 Field Option Description <Rotation:> Output Rotation of transformation. <Scale:> Output Scale factor used in transformation. Either true scale or ppm. <Rot Orig X:> Output Position in the X direction of the origin of rotation. <Rot Orig Y:> Output Position in the Y direction of the origin of rotation. Next step PAGE (F6) changes to the Height page.
Page 980: Results For Classic 3D Transformation
40.5.3 Results for Classic 3D Transformation DET C SYS Results of the transformation between the WGS 1984 datum and the local datum are shown Transformation for each of the transformation parameters. This screen consists of the Parameters page and Results, the Rotn Origin page.
Page 981 Field Option Description <Rotation Y:> Output Rotation around the Y axis. <Rotation Z:> Output Rotation around the Z axis. <Scale:> Output Scale factor used in transformation. Either true scale or ppm. Next step PAGE (F6) changes to the Rotn Origin page. Refer to paragraph "DET C SYS Transforma- tion Results, Rotn Origin page".
Page 982: Determine Coordinate System - One Point Localisation
Determine Coordinate System - One Point Localisation 41.1 Accessing Determine Coordinate System - One Point Localisation Access step-by-step Step Description Refer to "39.2 Accessing Determine Coordinate System" to access DET C SYS Determine Coord System Begin. Select <Method: One Pt Localistn>. CONT (F1) to access DET C SYS Step 1: Choose Transform Type.
Page 983 Description of fields Field Option Description <Transfrm User input A unique name for the coordinate system. The name Name:> may be up to 16 characters in length and may include spaces. <Transfrm Onestep, Twostep The type of transformation to be used when deter- Type:>...
Page 984: Determine Coordinate System - Onestep Transformation
41.2 Determine Coordinate System - Onestep Transformation Access step-by-step Step Description Refer to "41.1 Accessing Determine Coordinate System - One Point Localisation" to access DET C SYS Step 1: Choose Transform Type. DET C SYS Step 1: Choose Transform Type <Transfrm Type: Onestep>...
Page 985 Description of fields Field Option Description <Geoid Choicelist The geoid model to be used in the transformation. Model:> Geoid models from MANAGE Geoid Models can be selected. Next step CONT (F1) continues to DET C SYS Step 3: Choose Common Point. DET C SYS Step 3: Choose Common Point...
Page 986 Description of fields Field Option Description <Match Type:> How the horizontal and vertical shifts of the transfor- mation should be computed. Pos & Height Position and height are taken from the same pair of matching points. Pos Only Position is taken from one pair of matching points. The height can be taken from another pair of matching points.
Page 987 DET C SYS This screen contains different fields, depending on the <Method:> selected. The explana- Step 4: Determine Rota- tions for the softkeys given below are valid as indicated. tion CONT (F1) To confirm the selections and to continue with the subsequent screen.
Page 988 Description of common fields Field Option Description <Method:> Use WGS84 Method by which the rotation angle for the transfor- North, mation is determined. User Entered, Convergnce Angle or Two WGS84 Points For <Method: Use WGS84 North> Description of fields Field Option Description <Rotation:>...
Page 989 For <Method: Convergnce Angle> WGS 1984 coordinate system Local coordinate system, <Coord System:> Geodetic North Grid North Point on WGS 1984 datum, <WGS84 Point:> Meridian α Convergence angle, <Rotation:> GPS12_109 Description of fields Field Option Description <Coord Choicelist Coordinate system to provide the direction of grid System:>...
Page 990 Field Option Description <Rotation:> Output The rotation of the transformation calculated as 0.00000 minus the computed convergence angle. The field is updated as <Coord System:> and <WGS84 Point:> are changed. For <Method: Two WGS84 Points> WGS 1984 coordinate system Local coordinate system Line between two WGS 1984 points.
Page 991 Description of fields Field Option Description <Point 1:> Choicelist First point to use for computation of <Azimuth:>. All points from <WGS84 Pts Job:> chosen in DET C SYS Determine Coord System Begin can be selected. <Point 2:> Choicelist Second point to use for computation of <Azimuth:>. All points from <WGS84 Pts Job:>...
Page 992 DET C SYS This screen contains different fields, depending on the <Method:> selected. The explana- Step 5: Determine Scale tions for the softkeys given below are valid as indicated. The scale is calculated using the formula (r + h)/r where r is the distance from the centre of the ellipsoid to the WGS 1984 point selected in DET C SYS Step 3: Choose Common Point and h is the height of this point above the WGS 1984 ellipsoid.
Page 993 For <Method: User Entered> Description of fields Field Option Description <Scale:> User input Allows the scale factor to be typed in manually. For <Method: Known WGS84 Pt> Description of fields Field Option Description <WGS84 Choicelist WGS 1984 point from which the scale factor will be Point:>...
Page 994 Next step CONT (F1) continues to DET C SYS Step 6: Store Coord System. DET C SYS Step 6: Store Coord System STORE (F1) To store the coordinate system to the DB-X, attach the system to <WGS84 Pts Job:> that was selected in DET C SYS Determine Coord System Begin and return to GPS1200+ Main Menu.
Page 995 Field Option Description <Scale:> Output Scale factor of transformation. <Rot Orig X:> Output Position in the X direction of the origin of rotation. <Rot Orig Y:> Output Position in the Y direction of the origin of rotation. Next step STORE (F1) stores the coordinate system and returns to GPS1200+ Main Menu. Determine Coordinate System - One Point Localisa- GPS1200+ tion...
Page 996: Determine Coordinate System - Twostep Transformation
41.3 Determine Coordinate System - Twostep Transformation 41.3.1 Twostep Transformation Access step-by-step Step Description Refer to "41.1 Accessing Determine Coordinate System - One Point Localisation" to access DET C SYS Step 1: Choose Transform Type. DET C SYS Step 1: Choose Transform Type <Transfrm Type: Twostep>...
Page 997 Description of fields Field Option Description <Pre Trans- Choicelist The pre-transformation to be used for the preliminary form:> 3D transformation. All 3D transformations from MANAGE Transformations can be selected. <Ellipsoid:> Choicelist The ellipsoid to be used in the transformation. All ellipsoids from MANAGE Ellipsoids can be selected.
Page 998 DET C SYS Step 3: Choose Common Point CONT (F1) To confirm the selections and to continue with the subsequent screen. SURVY (F5) Available for <WGS84 Point:> being high- lighted. To manually occupy a point and store it in <WGS84 Pts Job:>. Description of fields Field Option...
Page 999 Field Option Description <WGS84 Choicelist The point ID of the horizontal and/or vertical control Point:> point chosen from <WGS84 Pts Job:>. All WGS 1984 points from MANAGE Data: Job Name can be selected. <Known Choicelist The point ID of the horizontal and/or vertical control Point:>...
Page 1000 DET C SYS This screen contains different fields, depending on the <Method:> selected. The explana- Step 4: Determine Rota- tions for the softkeys given below are valid as indicated. tion CONT (F1) To confirm the selections and to continue with the subsequent screen.
