Figure 135 Network diagram
Loop0
1.1.1.1/32
GE2/0/1
2.1.1.1/24
GE2/0/2
3.1.1.1/24
Router A

Configuration procedure

1. Configure IP addresses and masks for interfaces as shown in
2. Create MPLS TE tunnels on Router A:
# Create two MPLS TE tunnels (Tunnel 1 and Tunnel 2) to Router D. For more information, see
"Configuring MPLS
# Display information about the two MPLS TE tunnels on Router A.
<RouterA> display mpls tunnel all
Destination
4.4.4.4
4.4.4.4
# Display tunnel interface information on Router A. The output shows that the tunnel interface is
up. This example uses Tunnel 1.
<RouterA> display interface tunnel 1
Tunnel1
Current state: UP
Line protocol state: UP
Description: Tunnel1 Interface
Bandwidth: 64kbps
Maximum Transmit Unit: 1496
Internet Address is 10.1.10.1/24 Primary
Tunnel source unknown, destination 4.4.4.4
Tunnel TTL 255
Tunnel protocol/transport CR_LSP
Loop0
2.2.2.2/32
GE2/0/2
GE2/0/1
4.1.1.1/24
2.1.1.2/24
Router B
Router C
GE2/0/1 GE2/0/2
3.1.1.2/24 5.1.1.1/24
Loop0
3.3.3.3/32
TE."
Type Tunnel/NHLFE
CRLSP Tunnel1
CRLSP Tunnel2
Loop0
4.4.4.4/32
GE2/0/1
4.1.1.2/24
GE2/0/2
5.1.1.2/24
Router D
VPN Instance
-
-
532
Figure 135. (Details not shown.)
