Enable MPLS. For information about enabling MPLS, see
To enable MPLS TE:
Step
1. Enter system view.
2. Enter MPLS TE view.
3. Return to system view.
4. Enter interface view.
5. Enable MPLS TE for the
interface.

Configuring a tunnel interface

To configure an MPLS TE tunnel, you must create an MPLS TE tunnel interface and enter tunnel
interface view. All MPLS TE tunnel attributes are configured in tunnel interface view. For more
information about tunnel interfaces, see Layer 3—IP Services Configuration Guide.
Perform this task on the ingress node of the MPLS TE tunnel.
To configure a tunnel interface:
Step
1. Enter system view.
2. Create an MPLS TE tunnel
interface and enter tunnel
interface view.
3. Configure an IP address for
the tunnel interface.
4. Specify the tunnel
destination address.

Configuring DS-TE

DS-TE is configurable on any node that an MPLS TE tunnel traverses.
To configure DS-TE:
Step
1. Enter system view.
2. Enter MPLS TE view.
3. (Optional.) Configure the DS-TE
mode as IETF.
4. (Optional.) Configure the BC
model of IETF DS-TE as MAM.
5. Configure a TE class.
Command
system-view
mpls te
quit
interface interface-type
interface-number
mpls te enable
Command
system-view
interface tunnel tunnel-number
mode mpls-te
ip address ip-address
{ mask-length | mask }
destination ip-address
Command
system-view
mpls te
ds-te mode ietf
ds-te bc-model mam
ds-te te-class te-class-index
class-type
83
"Configuring basic MPLS."
Remarks
N/A
By default, MPLS TE is
disabled.
N/A
N/A
By default, MPLS TE is
disabled on an interface.
Remarks
N/A
By default, no tunnel interface is
created.
By default, a tunnel interface does
not have an IP address.
By default, no tunnel destination
address is specified.
Remarks
N/A
N/A
By default, the DS-TE mode is
prestandard.
By default, the BC model of IETF
DS-TE is RDM.
The default TE classes for IETF
mode are shown in Table 1.
