# Execute the display ip routing-table command on Router A. The output shows a static route entry
with interface Tunnel 1 as the output interface. (Details not shown.)

Establishing an inter-AS MPLS TE tunnel with RSVP-TE

Network requirements
Router A and Router B are in AS 100. Router C and Router D are in AS 200. AS 100 and AS 200 use
OSPF as the IGP.
Establish an EBGP connection between ASBRs Router B and Router C. Redistribute BGP routes
into OSPF and OSPF routes into BGP, so that AS 100 and AS 200 can reach each other.
Establish an MPLS TE tunnel from Router A to Router D. The tunnel requires a bandwidth of 2000
kbps. The maximum bandwidth of the link that the tunnel traverses is 10000 kbps, and the maximum
reservable bandwidth of the link is 5000 kbps.
Figure 34 Network diagram
Table 4 Interface and IP address assignment
Device
Router A
Router B
: No
: Disabled
: 10
: Disabled
: None
: Disabled
: -
: -
Interface IP address
Loop0 1.1.1.9/32
GE2/0/1 10.1.1.1/24
GE2/0/2 100.1.1.0/24
Loop0 2.2.2.9/32
GE2/0/1 10.1.1.2/24
POS2/2/0 20.1.1.1/24
Auto Created
Retry Interval
Reoptimization Freq
Backup LSP ID
Auto Bandwidth Freq
Max Bandwidth
Device Interface
Router C Loop0
GE2/0/1
POS2/2/0
Router D Loop0
GE2/0/1
GE2/0/2
117
: No
: 2 sec
: -
: -
: -
: -
IP address
3.3.3.9/32
30.1.1.1/24
20.1.1.2/24
4.4.4.9/32
30.1.1.2/24
100.1.2.0/24
