HP HPE FlexNetwork MSR Router Series Configuration Manual page 377

Table 32 Interface and IP address assignment
Device
CE 1
PE 1
ASBR-PE1
Configuration procedure
1. Configure an IGP on each MPLS backbone to ensure IP connectivity within the backbone.
This example uses OSPF. Be sure to advertise the route to the 32-bit loopback interface
address of each router through SPF. Use the loopback interface address of a router as the
router's LSR ID. (Details not shown.)
# Execute the display ospf peer command to verify that each ASBR-PE has established an
OSPF adjacency in Full state with the PE in the same AS, and that the PEs and ASBR-PEs in
the same AS have learned the routes to the loopback interfaces of each other. Execute the
ping command to verify that the PEs and ASBR-PEs in the same AS can ping each other.
(Details not shown.)
2. Configure basic MPLS and enable MPLS LDP on each MPLS backbone to establish LDP LSPs:
# Configure basic MPLS on PE 1, and enable MPLS LDP for both PE 1 and the interface
connected to ASBR-PE 1.
<PE1> system-view
[PE1] mpls lsr-id 1.1.1.9
[PE1] mpls ldp
[PE1-ldp] quit
[PE1] interface pos 2/2/0
[PE1-Pos2/2/0] mpls enable
[PE1-Pos2/2/0] mpls ldp enable
[PE1-Pos2/2/0] quit
# Configure basic MPLS on ASBR-PE 1, and enable MPLS LDP for both ASBR-PE 1 and the
interface connected to PE 1.
<ASBR-PE1> system-view
[ASBR-PE1] mpls lsr-id 2.2.2.9
[ASBR-PE1] mpls ldp
[ASBR-PE1-ldp] quit
[ASBR-PE1] interface pos 2/2/0
[ASBR-PE1-Pos2/2/0] mpls enable
[ASBR-PE1-Pos2/2/0] mpls ldp enable
[ASBR-PE1-Pos2/2/0] quit
# Configure basic MPLS on ASBR-PE 2, and enable MPLS LDP for both ASBR-PE 2 and the
interface connected to PE 2.
<ASBR-PE2> system-view
[ASBR-PE2] mpls lsr-id 3.3.3.9
[ASBR-PE2] mpls ldp
[ASBR-PE2-ldp] quit
Interface IP address
GE2/0/1 2001:1::1/96
Loop0 1.1.1.9/32
GE2/0/1 2001:1::2/96
POS2/2/0 172.1.1.2/24
Loop0 2.2.2.9/32
POS2/2/0 172.1.1.1/24
POS2/2/1 2002:1::1/96
Device
CE 2
PE 2
ASBR-PE2
367
Interface IP address
GE2/0/1 2001:2::1/96
Loop0 4.4.4.9/32
GE2/0/1 2001:2::2/96
POS2/2/0 162.1.1.2/24
Loop0 3.3.3.9/32
POS2/2/0 162.1.1.1/24
POS2/2/1 2002:1::2/96
