Configuring an LDP PW

Before you configure an LDP PW, enable global and interface MPLS LDP on the PE. For information
about MPLS LDP configuration, see
To configure an LDP PW:
Step
1. Enter system view.
2. Enter VSI view.
3. Specify LDP signaling
for PWs, and enter
VSI LDP signaling
view.
4. Configure an LDP PW,
and enter VSI LDP
PW view.
5. Configure the
expected bandwidth
of the PW.
Configuring a BGP PW
To configure a BGP PW, perform the following configurations on PEs:
•
Configure BGP to advertise VPLS label block information.
•
Create a BGP PW.
Configuring BGP to advertise VPLS label block information
Step
1. Enter system view.
2. Enable BGP and enter BGP
view.
3. Configure the remote PE as
a BGP peer.
4. Create the BGP L2VPN
address family and enter
"Configuring LDP."
Command
system-view
vsi vsi-name [ hub-spoke ]
pwsignaling ldp
peer ip-address [ pw-id
pw-id ] [ hub |
no-split-horizon | pw-class
class-name | tunnel-policy
tunnel-policy-name ] *
bandwidth bandwidth-value
Command
system-view
bgp as-number
peer { group-name | ip-address
[ mask-length ] } as-number
as-number
address-family l2vpn
462
Remarks
N/A
N/A
By default, no PW signaling protocol is
specified.
By default, no LDP PW is configured.
If both a default PW ID in the default-pw-id
command and a PW ID in the peer command
are configured, the PW ID in the peer
command is used. If only a default PW ID is
configured, the default PW ID is used. If no
default PW ID is configured, you must provide
a PW ID in the peer command.
If a VSI is enabled with the hub-spoke
capability (the hub-spoke keyword in the vsi
command), PWs in the VSI are spoke links by
default. You can use the hub keyword in this
command to specify the LDP PW as the hub
link in the VSI.
You must specify the no-split-horizon
keyword to disable split horizon when you
configure an NPE to establish a U-PW with a
UPE.
By default, the expected bandwidth is
10000000 kbps.
Remarks
N/A
By default, BGP is disabled.
By default, no BGP peer is
configured.
By default, the BGP L2VPN
address family is not created.
