Step
7. Configure the CE as a client
of the RR.
8. (Optional.) Enable route
reflection between clients.
9. (Optional.) Configure the
cluster ID for the RR.
2. Configure the CE:
Step
1. Enter system view.
2. Enter BGP view.
3. Configure the PE as an IBGP
peer.
4. Create the BGP IPv6 unicast
family and enter its view.
5. Enable IPv6 unicast route
exchange with the specified
peer or peer group.
6. (Optional.) Configure route
redistribution.

Configuring routing between PEs

Step
1. Enter system view.
Command
peer { group-name | ipv6-address
[ prefix-length ] } reflect-client
reflect between-clients
reflector cluster-id { cluster-id |
ip-address }
Command
system-view
bgp as-number
peer { group-name | ipv6-address
[ prefix-length ] } as-number
as-number
address-family ipv6 [ unicast ]
peer { group-name | ipv6-address
[ prefix-length ] } enable
import-route protocol
[ { process-id | all-processes }
[ allow-direct |med med-value |
route-policy route-policy-name ]
* ]
Command
system-view
340
Remarks
By default, no RR or RR
client is configured, and the
PE does not advertise routes
learned from the IBGP peer
CE to other IBGP peers,
including VPNv6 IBGP
peers. The PE advertises
routes learned from the CE
to other IBGP peers only
when you configure the
IBGP peer CE as a client of
the RR.
Configuring an RR does not
change the next hop of a
route. To change the next
hop of a route, configure an
inbound policy on the
receiving side.
By default, route reflection
between clients is enabled.
By default, the RR uses its
own router ID as the cluster
ID.
If multiple RRs exist in a
cluster, use this command to
configure the same cluster
ID for all RRs in the cluster to
avoid routing loops.
Remarks
N/A
N/A
By default, no BGP peer is
created.
By default, the BGP IPv6
unicast family is not created.
By default, BGP does not
exchange IPv6 unicast
routes with any peer.
A CE must redistribute its
routes to the PE so the PE
can advertise them to the
peer CE.
Remarks
N/A
