MPLS L3VPN configuration task list

Tasks at a glance
(Required.)
(Optional.)
(Optional.)
(Optional.)
(Optional.)
(Optional.)
(Optional.)
(Optional.)
(Optional.)
(Optional.)
(Optional.)

Configuring basic MPLS L3VPN

Tasks at a glance
Configuring VPN
(Required.)
(Required.)
(Optional.)
(Required.)
(Required.)
(Optional.)

Configuration prerequisites

Before you configure basic MPLS L3VPN, perform the following tasks:
1. Configure an IGP on the PEs and P devices to ensure IP connectivity within the MPLS
backbone.
2. Configure basic MPLS for the MPLS backbone.
3. Configure MPLS LDP on the PEs and P devices to establish LDP LSPs.

Configuring VPN instances

VPN instances isolate VPN routes from public network routes and routes among VPNs. This feature
allows VPN instances to be used in network scenarios in addition to MPLS L3VPNs.
All VPN instance configurations are performed on PEs or MCEs.
Configuring basic MPLS L3VPN
Configuring inter-AS VPN
Configuring nested VPN
Configuring multirole host
Configuring HoVPN
Configuring an OSPF sham link
Configuring routing on an MCE
Specifying the VPN label processing mode on the egress PE
Configuring BGP AS number substitution and SoO attribute
Configuring MPLS L3VPN FRR
Enabling SNMP notifications for MPLS L3VPN
instances:
Creating a VPN instance
Associating a VPN instance with an interface
Configuring route related attributes for a VPN instance
Configuring routing between a PE and a CE
Configuring routing between PEs
Configuring BGP VPNv4 route control
