Xconnect-group Name: ccc
Peer
10.2.2.2
# Verify that CE 1 and CE 2 can ping each other. (Details not shown.)

Configuring an intra-domain multi-segment PW

Network requirements
As shown in
tunnel between PE 1 and P, and an MPLS TE tunnel between P and PE 2.
Configure a multi-segment PW within the backbone to allow communication between CE 1 and CE 2.
The multi-segment PW includes an LDP PW between PE 1 and P, and a static PW between P and
PE 2. The two PWs are concatenated on P.
Figure 115 Network diagram
Table 44 Interface and IP address assignment
Device
CE 1
PE 1
CE 2
Configuration procedure
1. Configure CE 1.
<CE1> system-view
[CE1] interface gigabitethernet 2/0/1
[CE1-GigabitEthernet2/0/1] ip address 100.1.1.1 24
[CE1-GigabitEthernet2/0/1] quit
2. Configure PE 1:
# Configure an LSR ID.
<PE1> system-view
[PE1] interface loopback 0
PW ID/Rmt Site
-
Figure 115, there is no public tunnel between PE 1 and PE 2. There is an MPLS TE
Interface IP address
GE2/0/1 100.1.1.1/24
Loop0 192.2.2.2/32
GE2/0/2 23.1.1.1/24
GE2/0/1 100.1.1.2/24
In/Out Label Proto
202/102 Static
Device
P
PE 2
444
Flag Link ID State
M 0 Up
Interface IP address
Loop0 192.4.4.4/32
GE2/0/1 23.1.1.2/24
GE2/0/2 26.2.2.2/24
Loop0 192.3.3.3/32
GE2/0/2 26.2.2.1/24
