Step
14. (Optional.) Specify a
preferred value for routes
received from a peer or peer
group.
15. Apply a prefix list to filter
routes received from or
advertised to a peer or peer
group.
16. (Optional.) Configure BGP
updates advertised to an
EBGP peer or peer group to
carry only public AS
numbers.
17. Configure the router as an
RR and specify a peer or
peer group as its client.
18. Specify the maximum
number of routes BGP can
receive from a peer or peer
group.
19. Apply a routing policy to a
peer or peer group.
20. Enable route target-based
filtering of received VPNv4
routes.
21. Enable route reflection
between clients.
22. Configure a cluster ID for the
RR.
23. Configure filtering of
reflected routes.
24. Configure the SoO attribute
for a BGP peer or peer
group.

Configuring inter-AS VPN

If the MPLS backbone spans multiple ASs, you must configure inter-AS VPN.

Configuring inter-AS option A

Inter-AS option A applies to scenarios with a few VPNs.
To configure inter-AS option A, create VPN instances on PEs and ASBRs. The VPN instances on
PEs are used to allow CEs to access the network, The VPN instances on ASBRs are used to access
the peer ASBRs. An ASBR considers the peer ASBR as a CE.
Command
peer { group-name | ip-address
[ mask-length ] } preferred-value
value
peer { group-name | ip-address
[ mask-length ] } prefix-list
prefix-list-name { export |
import }
peer { group-name | ip-address
[ mask-length ] } public-as-only
peer { group-name | ip-address
[ mask-length ] } reflect-client
peer { group-name | ip-address
[ mask-length ] } route-limit
prefix-number [ { alert-only |
discard | reconnect
reconnect-time } |
percentage-value ] *
peer { group-name | ip-address
[ mask-length ] } route-policy
route-policy-name { export |
import }
policy vpn-target
reflect between-clients
reflector cluster-id { cluster-id |
ip-address }
rr-filter
extended-community-number
peer { group-name | ip-address
[ mask-length ] } soo site-of-origin
220
Remarks
clients.
By default, the preferred value is
0.
By default, no prefix list based
filtering is configured.
By default, BGP route updates
advertised to an EBGP peer or
peer group can carry both public
and private AS numbers.
By default, no RR is configured.
By default, the number of routes
that BGP can receive from a peer
or peer group is not limited.
By default, no routing policy is
applied to a peer or peer group.
By default, this feature is enabled.
By default, route reflection
between clients is enabled on the
RR.
By default, the RR uses its own
router ID as the cluster ID.
By default, the RR does not filter
reflected routes.
By default, the SoO attribute is not
configured.
