Protocols and standards

•
RFC 4659, BGP-MPLS IP Virtual Private Network (VPN) Extension for IPv6 VPN
•
RFC 6565, OSPFv3 as a Provider Edge to Customer Edge (PE-CE) Routing Protocol
IPv6 MPLS L3VPN configuration task list
Tasks at a glance
(Required.)
(Optional.) Configuring inter-AS IPv6 VPN
(Optional.) Configuring multirole host
(Optional.) Configuring an OSPFv3 sham link
(Optional.) Configuring routing on an MCE
(Optional.) Configuring BGP AS number substitution and SoO attribute
Configuring basic IPv6 MPLS L3VPN
The key task in IPv6 MPLS L3VPN configuration is to manage the advertisement of IPv6 VPN routes
on the MPLS backbone, including management of PE-CE route exchange and PE-PE route
exchange.
To configure basic IPv6 MPLS L3VPN:
Tasks at a glance
Configuring VPN
1. (Required.)
2. (Required.)
3. (Optional.)
(Required.)
(Required.)
(Optional.) Configuring BGP VPNv6 route control
Before configuring basic IPv6 MPLS L3VPN, perform the following tasks:
1. Configure an IGP on the PEs and P devices to ensure IP connectivity within the MPLS
backbone.
2. Configure basic MPLS for the MPLS backbone.
3. Configure MPLS LDP on PEs and P devices to establish LDP LSPs.
Configuring VPN instances
By configuring VPN instances on a PE, you isolate not only VPN routes from public network routes,
but also routes between VPNs. This feature allows VPN instances to be used in network scenarios
besides MPLS L3VPNs.
All VPN instance configurations are performed on PEs or MCEs.
Configuring basic IPv6 MPLS L3VPN
instances:
Creating a VPN instance
Associating a VPN instance with an interface
Configuring route related attributes for a VPN instance
Configuring routing between a PE and a CE
Configuring routing between PEs
332
