Step
1. Enter system view.
2. Enter BGP view.
3. Configure the MCE as an
IBGP peer.
4. Enter BGP-VPN IPv4 unicast
address family view.
5. Enable BGP to exchange
IPv4 unicast routes with the
peer.
6. Redistribute the IGP routes
of the VPN into BGP.

Configuring routing between an MCE and a PE

MCE-PE routing configuration includes these tasks:
•
Binding the MCE-PE interfaces to VPN instances.
•
Performing route configurations.
•
Redistributing VPN routes into the routing protocol running between the MCE and the PE.
Perform the following configurations on the MCE. For information about how to configure the PE, see
"Configuring routing between a PE and a
Configuring static routing between an MCE and a PE
Step
1. Enter system view.
2. Configure a static route
for a VPN instance.
3. (Optional.) Configure
the default preference
for static routes.
Configuring RIP between an MCE and a PE
Step
1. Enter system view.
2. Create a RIP process
for a VPN instance and
enter RIP view.
Command
system-view
bgp as-number
peer { group-name | ip-address
[ mask-length ] } as-number
as-number
address-family ipv4 [ unicast ]
peer { group-name | ip-address
[ mask-length ] } enable
import-route protocol
[ { process-id | all-processes }
[ allow-direct | med med-value |
route-policy route-policy-name ]
* ]
CE."
Command
system-view
ip route-static vpn-instance s-vpn-instance-name
dest-address { mask-length | mask } { interface-type
interface-number [ next-hop-address ] |
next-hop-address [ public ] [ track
track-entry-number ] | vpn-instance
d-vpn-instance-name next-hop-address [ track
track-entry-number ] } [ permanent ] [ preference
preference-value ] [ tag tag-value ] [ description
description-text ]
ip route-static default-preference
default-preference-value
Command
system-view
rip [ process-id ] vpn-instance
vpn-instance-name
234
Remarks
N/A
N/A
N/A
N/A
By default, BGP does not
exchange IPv4 unicast
routes with any peer.
By default, no routes are
redistributed into BGP.
A VPN site must advertise
VPN network addresses to
the connected MCE.
Remarks
N/A
By default, no
static route is
configured.
The default
preference is 60.
Remarks
N/A
N/A
