Destinations : 6
Destination/Mask
1.1.1.9/32
2.2.2.9/32
10.1.1.0/24
10.1.1.1/32
127.0.0.0/8
127.0.0.1/32
3. Configure BGP on Router B and Router C to ensure that the ASs can communicate with each
other:
# Configure Router B.
[RouterB] bgp 100
[RouterB-bgp] peer 20.1.1.2 as-number 200
[RouterB-bgp] address-family ipv4 unicast
[RouterB-bgp-ipv4] peer 20.1.1.2 enable
[RouterB-bgp-ipv4] import-route ospf
[RouterB-bgp-ipv4] import-route direct
[RouterB-bgp-ipv4] quit
[RouterB-bgp] quit
# Configure Router C.
[RouterC] bgp 200
[RouterC-bgp] peer 20.1.1.1 as-number 100
[RouterC-bgp] address-family ipv4 unicast
[RouterC-bgp-ipv4] peer 20.1.1.1 enable
[RouterC-bgp-ipv4] import-route ospf
[RouterC-bgp-ipv4] import-route direct
[RouterC-bgp-ipv4] quit
[RouterC-bgp] quit
# Verify that the routers have learned the AS-external routes.
[RouterA] display ip routing-table
Destinations : 10
Destination/Mask
1.1.1.9/32
2.2.2.9/32
3.3.3.9/32
4.4.4.9/32
10.1.1.0/24
10.1.1.1/32
20.1.1.0/24
30.1.1.0/24
127.0.0.0/8
127.0.0.1/32
4. Configure an LSR ID, and enable MPLS, MPLS TE, and RSVP-TE:
# Configure Router A.
[RouterA] mpls lsr-id 1.1.1.9
Routes : 6
Proto Pre Cost
Direct 0 0
O_INTRA 10 1
Direct 0 0
Direct 0 0
Direct 0 0
Direct 0 0
Routes : 10
Proto Pre Cost
Direct 0 0
O_INTRA 10 1
O_ASE 150 1
O_ASE 150 1
Direct 0 0
Direct 0 0
O_ASE 150 1
O_ASE 150 1
Direct 0 0
Direct 0 0
119
NextHop Interfac
127.0.0.1 InLoop0
10.1.1.2 GE2/0/1
10.1.1.1 GE2/0/1
127.0.0.1 InLoop0
127.0.0.1 InLoop0
127.0.0.1 InLoop0
NextHop Interface
127.0.0.1 InLoop0
10.1.1.2 GE2/0/1
10.1.1.2 GE2/0/1
10.1.1.2 GE2/0/1
10.1.1.1 GE2/0/1
127.0.0.1 InLoop0
10.1.1.2 GE2/0/1
10.1.1.2 GE2/0/1
127.0.0.1 InLoop0
127.0.0.1 InLoop0
