Step
2. Create a static CRLSP.

Displaying static CRLSPs

Execute display commands in any view.
Task
Display static CRLSP information.

Static CRLSP configuration example

Network requirements
Router A, Router B, and Router C run IS-IS.
Establish an MPLS TE tunnel over a static CRLSP from Router A to Router C to transmit data
between the two IP networks. The required bandwidth for the tunnel is 2000 kbps.
The maximum bandwidth for MPLS TE traffic is 10000 kbps, and the maximum reservable
bandwidth is 5000 kbps.
Command
•
Configure the ingress node:
static-cr-lsp ingress lsp-name
{ nexthop next-hop-addr |
outgoing-interface interface-type
interface-number } out-label
out-label-value [ bandwidth [ ct0 |
ct1 | ct2 | ct3 ] bandwidth-value ]
•
Configure a transit node:
static-cr-lsp transit lsp-name
in-label in-label-value { nexthop
next-hop-addr | outgoing-interface
interface-type interface-number }
out-label out-label-value
[ bandwidth [ ct0 | ct1 | ct2 | ct3 ]
bandwidth-value ]
•
Configure the egress node:
static-cr-lsp egress lsp-name
in-label in-label-value
Command
display mpls static-cr-lsp [ lsp-name lsp-name ] [ verbose ]
159
Remarks
Use one command according
to the position of a device on
the network.
By default, no static CRLSP
exists.
Do not configure the next hop
address as a local public IP
address when configuring the
static CRLSP on the ingress
node or a transit node.
You do not need to execute the
static-cr-lsp egress
command on the egress node
if the outgoing label configured
on the penultimate hop of the
static CRLSP is 0 or 3.
