Configuration procedure
1.
Configure MPLS L3VPN on the provider carrier backbone. Enable IS-IS as the IGP, enable
LDP between PE 1 and PE 2, and establish an MP-IBGP peer relationship between the PEs:
# Configure PE 1.
<PE1> system-view
[PE1] interface loopback 0
[PE1-LoopBack0] ip address 3.3.3.9 32
[PE1-LoopBack0] quit
[PE1] mpls lsr-id 3.3.3.9
[PE1] mpls ldp
[PE1-ldp] quit
[PE1] isis 1
[PE1-isis-1] network-entity 10.0000.0000.0000.0004.00
[PE1-isis-1] quit
[PE1] interface loopback 0
[PE1-LoopBack0] isis enable 1
[PE1-LoopBack0] quit
[PE1] interface pos 2/2/1
[PE1-Pos2/2/1] ip address 30.1.1.1 24
[PE1-Pos2/2/1] isis enable 1
[PE1-Pos2/2/1] mpls enable
[PE1-Pos2/2/1] mpls ldp enable
[PE1-Pos2/2/1] mpls ldp transport-address interface
[PE1-Pos2/2/1] quit
[PE1] bgp 200
[PE1-bgp] peer 4.4.4.9 as-number 200
[PE1-bgp] peer 4.4.4.9 connect-interface loopback 0
[PE1-bgp] address-family vpnv4
[PE1-bgp-vpnv4] peer 4.4.4.9 enable
[PE1-bgp-vpnv4] quit
[PE1-bgp] quit
# Configure PE 2 in the same way that PE 1 is configured. (Details not shown.)
# On PE 1 or PE 2, execute the following commands:
Execute the display mpls ldp peer command to verify that an LDP session in Operational
state has been established between PE 1 and PE 2. (Details not shown.)
Execute the display bgp peer vpnv4 command to verify that a BGP peer relationship in
Established state has been established between PE 1 and PE 2. (Details not shown.)
Execute the display isis peer command to verify that the IS-IS neighbor relationship has
been established between PE 1 and PE 2. (Details not shown.)
2.
Configure the customer carrier network. Enable IS-IS as the IGP, and enable LDP between PE
3 and CE 1, and between PE 4 and CE 2:
# Configure PE 3.
Interface
IP address
Loop0
3.3.3.9/32
POS2/2/0
11.1.1.2/24
POS2/2/1
30.1.1.1/24
Device
PE 2
283
Interface
IP address
Loop0
4.4.4.9/32
POS2/2/0
30.1.1.2/24
POS2/2/1
21.1.1.1/24
