Configuring an AC

An AC can be one of the following types on a PE:
•
Layer 3 Ethernet interface—Transparently forwards received packets to the bound VSI.
•
Layer 3 Ethernet subinterface—Forwards received packets to the bound VSI. In this mode,
VLANs are unique on a per-interface basis rather than on a per-device basis.
•
VLAN interface—Forwards all packets received from the VLAN to the bound VSI. In this mode,
VLANs are globally unique.
NOTE:
When VLANs are globally unique, packets with the same VLAN ID are forwarded by the same VSI
regardless of the receiving interfaces. If VLANs are unique on a per interface basis, packets with the
same VLAN ID from different interfaces can be forwarded by different VSIs.
To create a Layer 2 link between a PE and a CE, configure the AC interface that connects the PE to
the CE.
An AC interface can be a Layer 3 Ethernet interface (including physical Layer 3 Ethernet interface,
Layer 3 virtual Ethernet interface, and VE-L2VPN interface), VLAN interface, or Layer 3 Ethernet
subinterface.
For more information about Ethernet interfaces, see Interface Configuration Guide. For more
information about Layer 3 virtual Ethernet interfaces, see Layer 2—WAN Configuration Guide. For
more information about VE-L2VPN interfaces, see
backbone." For more information about VLAN interfaces, see Layer 2—LAN Switching Configuration
Guide.
Configuring a VSI
Step
1. Enter system view.
2. Create a VSI and enter VSI
view.
3. (Optional.) Configure a
description for the VSI.
4. (Optional.) Set the default
PW ID for the VSI.
5. Set an MTU for the VSI.
6. (Optional.) Enable the VSI.
"Configuring L2VPN access to L3VPN or IP
Command
system-view
vsi vsi-name [ hub-spoke ]
description text
default-pw-id default-pw-id
mtu mtu
undo shutdown
460
Remarks
N/A
By default, no VSI is created.
If you specify the hub-spoke keyword
for a VSI, the VSI supports the
hub-spoke network model.
By default, no description is configured
for a VSI.
By default, no default PW ID is
configured for the VSI.
By default, the MTU of a VSI is 1500
bytes.
By default, a VSI is enabled.
