Muratec MFX-1330 Field Engineering Manual page 86

Memory Switch 31 - Modem
Initial
Switch
Setting
7 1 EYE-Q check level at
7200 bps
6 0
5 1 EYE-Q check level at
9600 bps
4 0
3 1 EYE-Q check level at
12000 bps
2 0
1 1 EYE-Q check level at
14400 bps
0 0
Memory Switch 32 - Modem
Initial
Switch
Setting
7 0 EYE-Q slice level
0: Disable
1: Enable
6 1 Check EYE-Q
0: No
1: Yes
5 0 Factory use only
4 0 Factory use only
3 1 EYE-Q check level at
2400 bps
2 0
1 1 EYE-Q check level at
4800 bps
0 0
Adjust
Strict-- - - - - - - - - - - -Lenient
Strict - - - - - - - - - - - -Lenient
Strict - - - - - - - - - - - -Lenient
Strict - - - - - - - - - - - -Lenient
Adjust
Setting this bit to "1" enables memory switch 32,
bits 0-3 and memory switch 31, bits 0-7 and
enables EYE-Q check adjustment.
Set at 0: Line condition status (EYE-Q) is not
checked after checking TCF.
Set at 1: Line condition status (EYE-Q) is checked
after checking TCF.
Strict - - - - - - - - - - - -Lenient
Strict - - - - - - - - - - - -Lenient
3-58
Usage/Comments
0 0 1 1
0 1 0 1
0 0 1 1
0 1 0 1
0 0 1 1
0 1 0 1
0 0 1 1
0 1 0 1
Usage/Comments
0 0 1 1
0 1 0 1
0 0 1 1
0 1 0 1
