Muratec MFX-1330 Field Engineering Manual page 50

Machine Parameter 222 ∼ 226 --- Factory use only
Machine Parameter 227
Initial
Switch
Setting
7 0 Printer registration
adjustment.
6 0
5 0
Adjusts the top margin at the
4 0
Bypass tray for printing.
3 0
2 0
The plus setting increases
1 0
the top margin and the minus
0 0
setting decreases it.
Each setting changes by
0.1 mm.
Machine Parameter 228
Initial
Switch
Setting
7 0 Printer registration
adjustment.
6 0
5 0
Adjusts the top margin for
4 0
duplex printing cassette.
3 0
2 0
The plus setting increases
1 0
the top margin and the minus
0 0
setting decreases it.
Each setting changes by
0.1 mm.
Machine Parameter 229 and 239 --- Factory use only
Adjust
Switch
127 steps
32 steps
16 steps
8 steps
Note: The surrounding margin (right / left / top /
bottom) is set in Unique Switch 52. If you want to
adjust only top margin, adjust it in this switch.
Adjust
Switch
127 steps
32 steps
16 steps
8 steps
Note: The surrounding margin (right / left / top /
bottom) is set in Unique Switch 52. If you want to
adjust only top margin, adjust it in this switch.
3-22
Usage/Comments
76543210 Settings
01111111 +12.7 mm
:
00100000 +3.2 mm
:
00010000 +1.6 mm
:
00001000 +0.8 mm
:
00000000 4 mm Initial setting
Usage/Comments
76543210 Settings
01111111 +12.7 mm
:
00100000 +3.2 mm
:
00010000 +1.6 mm
:
00001000 +0.8 mm
:
00000000 4 mm Initial setting
