Muratec MFX-1330 Field Engineering Manual page 34

Machine Parameter 013
Initial
Switch
Setting
7 1 Leading edge document
margin adjustment (ADF)
6 0
5 0
Adjusts the leading edge
4 1
margin from Document
3 0
Sensor 2 (DS2) to the start of
2 0
scanning the position.
1 0
0 1
1 step = 2 / 600 dpi
Note: These values
are factory set and should
not be adjusted unless
instructed by a Muratec
technical representative.
Machine Parameter 014
Initial
Switch
Setting
7 0 Trailing edge document
margin adjustment (ADF)
6 0
5 0
Adjusts document feed after
4 0
the trailing edge of a
3 1
document passes Document
2 0
Sensor 2 (DS2).
1 1
0 0
1 step = 2 / 600 dpi
Note: These values
are factory set and should
not be adjusted unless
instructed by a Muratec
technical representative.
Adjust
Switch
127 steps 01111111
(0.0847 mm)
-127steps
Adjust
Switch
127 steps 01111111
(0.0847 mm)
-127steps
3-6
Usage/Comments
76543210 Settings
+10.76 mm
:
00100000 +2.71 mm
:
00010000 +1.36 mm
:
00001000 +0.68mm
:
00000000 15.6 mm
:
10001000 -0.68 mm
:
10010000 -1.36 mm
:
10100000 -2.71 mm
:
100111111 -5.34 mm
:
11111111 -10.76 mm
Usage/Comments
76543210 Settings
+10.76 mm
:
00100000 +2.71 mm
:
00010000 +1.36 mm
:
00010011 +0.93 mm
:
00001000 +0.68mm
:
00000000 15.6 mm
:
10001000 -0.68 mm
:
10010000 -1.36 mm
:
10100000 -2.71 mm
:
11111111 -10.76 mm
Initial setting
Initial setting
