Muratec MFX-1330 Field Engineering Manual page 110

Unique Switch 32 - Modem
Initial
Switch
Setting
7 0 Factory use only
6 0 Factory use only
5 0 Factory use only
4 1 Factory use only
3 0 Factory use only
2 1 ANSam output time
0: 3 sec
1: 4 sec
1 0 Factory use only
0 1 Factory use only
Unique Switch 33 --- Factory use only
Unique Switch 34 - Modem
Initial
Switch
Setting
7 0 Symbol rate adjustment
0: Yes
1: No
6 0 Symbol rate adjustment. Adjust the symbol rate selected by the link.
Switch 6 5 4
5 0
4 0
3 0 No use
2 0 No use
1 0 No use
0 0 No use
Unique Switch 35 ∼ 36 --- Factory use only
Adjust
The time limit to output the ANSam (A sinewave
signal at 2100 Hz amplitude-modulated). Sets to
"1" when the V.8 handshake is hard to achieve.
Adjust
When re-transmission occurs frequently, set to "0".
When set to 1, the re-transmission may become
not to be occurred.
FLAT 2Link 3Link 4Link
0 0 0 : 3429 3429 3200
0 0 1 : 3429 3200 3200
0 1 0 : 3429 3200 3000
0 1 1 : 3200 3200 3000
1 0 0 : 3200 3200 3000
3-82
Usage/Comments
Usage/Comments
5Link 6Link 7Link
3000 3000 3000 2800
3000 3000 3000 2800
3000 3000 3000 2800
3000 3000 3000 2800
3000 3000 3000 2800
