SENSOR PES1
1) Pull out the Cassette 1st.
2) Using a short screwdriver, remove the Bracket sensor from the bottom (back) of the body.
3) Remove the Sensor stopper and connector, and then remove the PES1.
PES1
Bracket sensor
Sensor stopper
5-69
5-69
Bracket sensor
