Muratec MFX-1330 Field Engineering Manual page 48

Machine Parameter 182 ∼ 186 --- Factory use only
Machine Parameter 187
Initial
Switch
Setting
7 0 Printer registration
adjustment (Vertical) at the
6 0
Bypass tray for printing.
5 0
4 0
Adjusts the start point to
3 0
print.
2 0
1 0
The plus setting increases
0 0
the top margin and the minus
setting decreases it.
Each setting changes by
0.1 mm.
Note: See Machine
Parameter 197 for the rotate
printing.
Machine Parameter 188
Initial
Switch
Setting
7 0 Printer registration
adjustment (Vertical) for
6 0
duplex printing cassette.
5 0
4 0
Adjusts the start point to
3 0
print.
2 0
1 0
The plus setting increases
0 0
the top margin and the minus
setting decreases it.
Each setting changes by
0.1 mm.
Note: See Machine
Parameter 197 for the rotate
printing.
Machine Parameter 189 and 219 --- Factory use only
Adjust
Switch
127 steps
32 steps
16 steps
8 steps
Note: Set this switch after setting the margin to
"0 mm" in Unique Switch 052. Then, after setting
this switch, set the margin to the initial setting (4
mm) in Unique Switch 52.
Adjust
Switch
127 steps
32 steps
16 steps
8 steps
Note: Set this switch after setting the margin to
"0 mm" in Unique Switch 052. Then, after setting
this switch, set the margin to the initial setting (4
mm) in Unique Switch 52.
3-20
Usage/Comments
76543210 Settings
01111111 +12.7 mm
:
00100000 +3.2 mm
:
00010000 +1.6 mm
:
00001000 +0.8 mm
:
00000000 0 mm Initial setting
Usage/Comments
76543210 Settings
01111111 +12.7 mm
:
00100000 +3.2 mm
:
00010000 +1.6 mm
:
00001000 +0.8 mm
:
00000000 0 mm Initial setting
