3.21 Sensor input test

This mode can confirm the sensor status. When the sensor operates, the value next to sensor name changes
0 to 1. For example, when open the 1st paper cassette, the CAS1:0 change to CAS1:1.
1. Press MENU, *, 2, 2.
2. Press or to display the desired sensor.
CAS1:0 JAM1:0 PES1:1
CAS2:0 JAM2:0 PES2:0
DS1 :0 DS2 :0 HS
TXIL:0 APS :0
Code Sensor
name
CAS1 OPEN1 0:1st cassette is close
1:1st cassette is open
JAM1 JAMC1 0: 1st side cover is close
1: 1st side cover is open
PES1 PES 0: No paper in 1st cassette
1: Detect paper is 1st cassette
CAS2 OPEN2 0:2nd cassette is close
1:2nd cassette is open
JAM2 JAMC2 0: 2nd side cover is close
1: 2nd side cover is open
PES2 PES2 0: No paper in 2nd cassette
1: Detect paper is 2nd cassette
HPES TRAYS 0:No paper in bypass tray
1:Detect paper in bypass tray
C2U ----- 0: No 2nd cassette
1: 2nd cassette is attached
CVSW ----- 0: Front cover is close
1: Front cover is open
PSS PSS 0: No paper
1: Detect paper
PDS PDS 0: No paper
1: Detect paper jam
SWB DPS 0:No paper
1:Detect paper
3. Press STOP to return to standby mode.
Note: CAS2, JAM2 and PES2 do not change, when there is no second cassette attached.
SWB does not change, when the machine has no duplex printing unit.
HPES:1 C2U :0 CVSW:1
PSS :0 PDS :0 SWB :1
:0 TMP BAT THR TS1 TS2
000 000 000 000 000
Status
3-116
DREX:1 DRNW:0 DVNW:0
Code Name
DREX -----
DRNW -----
DVNW -----
DS1 DS1
DS2 DS2
HS Home Sensor 0: Mirror outer than HS
TXIL TXIL
APS -----
TEMP -----
BATT -----
THRM -----
TS1 -----
TS2 -----
Status
0: No drum
1: Detect drum
0: Drum new
1: Drum used
0: Developing unit new
1: Developing unit used
0: No document
1: Document existing
0: No document
1: Document existing
1: Mirror inner than HS
0: Scanner cover is close
1: Scanner cover is open
0: Platen cover is closed
1: Platen cover is open
Show the internal
temperature of machine.
Show the voltage of the
SDRAM backup battery.
Show the temperature of
Heater roller.
Show the remaining toner
level.
Show the remaining toner
level.
