Muratec MFX-1330 Field Engineering Manual page 52

Machine Parameter 242 ∼ 246 --- Factory use only
Machine Parameter 247
Initial
Switch
Setting
7 0 Printer registration
adjustment.
6 0
5 0
Adjusts the bottom margin at
4 0
the Bypass tray for printing.
3 0
2 0
The plus setting decreases
1 0
the bottom margin and the
0 0
minus setting increases it.
Each setting changes by
0.1 mm..
Machine Parameter 248
Initial
Switch
Setting
7 0 Printer registration
adjustment.
6 0
5 0
Adjusts the top margin for
4 0
duplex printing cassette.
3 0
2 0
The plus setting increases
1 0
the top margin and the minus
0 0
setting decreases it.
Each setting changes by
0.1 mm.
Machine Parameter 249 and 284 --- Factory use only
Adjust
Switch
127 steps
32 steps
16 steps
8 steps
-8 steps
-16 steps
-128 steps
Note: The surrounding margin (right / left / top /
bottom) is set in Unique Switch 52. If you want to
adjust only bottom margin, adjust it in this switch.
Adjust
Switch
127 steps
32 steps
16 steps
8 steps
-8 steps
-16 steps
-128 steps
Note: The surrounding margin (right / left / top /
bottom) is set in Unique Switch 52. If you want to
adjust only top margin, adjust it in this switch.
3-24
Usage/Comments
76543210 Settings
01111111 +12.7 mm
:
00100000 +3.2 mm
:
00010000 +1.6 mm
:
00001000 +0.8 mm
:
00000000 4 mm Initial setting
:
11110111 -0.8 mm
:
11101111 -1.6 mm
:
10000000 -12.8 mm
Usage/Comments
76543210 Settings
01111111 +12.7 mm
:
00100000 +3.2 mm
:
00010000 +1.6 mm
:
00001000 +0.8 mm
:
00000000 4 mm Initial setting
:
11110111 -0.8 mm
:
11101111 -1.6 mm
:
10000000 -12.8 mm
