Muratec MFX-1330 Field Engineering Manual page 45

Machine Parameter 161
Initial
Switch
Setting
7 0 Printer registration
adjustment.
6 0
5 0
Adjusts the right margin at
4 0
the 2nd cassette for printing.
3 0
2 0
The plus setting decreases
1 0
the right margin and the
0 0
minus setting increases it.
The setting changes by
16 dots (0.6773 mm).
Machine Parameter 162 ∼ 166 --- Factory use only
Machine Parameter 167
Initial
Switch
Setting
7 1 Printer registration
adjustment.
6 1
5 1
Adjusts the right margin at
4 1
the Bypass tray for printing.
3 1
2 0
The plus setting decreases
1 0
the right margin and the
0 1
minus setting increases it.
The setting changes by
16 dots (0.6773 mm).
Machine Parameter 168
Initial
Switch
Setting
7 0 Printer registration
adjustment.
6 0
5 0
Adjusts the right margin for
4 0
duplex printing cassette.
3 0
2 1
The plus setting decreases
1 1
the right margin and the
0 1
minus setting increases it.
The setting changes by
16 dots (0.6773 mm).
Machine Parameter 169 and 179 --- Factory use only
Adjust
See table on page 3-18.
Note: The surrounding margin (right / left / top /
bottom) is set in Unique Switch 52. If you want to
adjust only right margin, adjust it in this switch.
Adjust
See table on page 3-18.
Note: The surrounding margin (right / left / top /
bottom) is set in Unique Switch 52. If you want to
adjust only right margin, adjust it in this switch.
Adjust
See table on page 3-18.
Note: The surrounding margin (right / left / top /
bottom) is set in Unique Switch 52. If you want to
adjust only right margin, adjust it in this switch.
3-17
Usage/Comments
Usage/Comments
Usage/Comments
